Wacom GRAPHIRE4 - OTHER Manuale utente

Quick Start Guide

사용자 안내서사용자 안내서

使用手冊

UM-0322

Graphire 4 Userʼs Guide

Wacom Co., Ltd.

Printed in China

EnglishEnglish 中文（繁體）中文（繁體）한국어한국어한국어한국어

EnglishEnglish 中文（繁體）中文（繁體）한국어한국어

English

Contents

Before use .......................................................................... 1

Conﬁrm the contents of the box ............................................... 1

Installing the Tablet Driver to your PC ............................ 2

Operation instructions for the Graphire 4 ....................... 5

How to use the Pen .................................................................. 5

How to use the ExpressKeys ................................................... 7

Online Manual details .............................................................. 7

Obtaining Technical Support ............................................ 8

Before use

Conﬁrm the contents of the box

Conﬁrm that the main component and peripherals are all included.

■ Graphire Tablet (main component) ■ Graphire Pen

(hereinafter “Pen”)

■ Application Software (CD-ROM)* ■ Tablet Drivers (CD-ROM)

■ Quick Start Guide

(this instruction booklet)

■ Application Installation Guide

* The number of application software CD-ROMs included may differ according

to the model purchased.

G4_EN.indd 1 05.7.19 3:17:11 PM

Installing the Tablet Driver to your PC

❶

Turn on your PC.



• When installing the Tablet Driver onto a PC that has other drivers for a

WACOM tablet, please uninstall the old drivers before installing the Tablet

Driver included with this Graphire 4 tablet. See the appropriate user

instructions of the old Tablet Drivers to uninstall.

• It is recommended that you close all other applications before starting Setup.

❷ Connect the tablet USB connector to the PC USB port.

• The status indicator will light up blue.

The following instructions may differ according to PC and OS version. Find the

OS version for your PC and turn to the corresponding page.

• Windows XP/2000/Me go to page 2.

• Windows 98SE go to page 3.

• Mac OS X (10.2.8 or higher) go to page 4.

Driver installation for Windows XP/2000/Me

❶

Insert the Tablet Drivers CD-ROM into the CD-ROM drive.

If the installation screen does not appear, double-click the CD-ROM icon or

open the CD-ROM drive and double-click Install.exe (or Install).

❷ Click on Install Tablet.

❸ Read the End User License Agreement and click Accept.

• Installation of the Tablet Drivers will begin.

❹ Click OK after the installation has ﬁnished.

❺ Click the Technical Notes after the installation screen

reappears.

❻ Click the on the installation screen.

G4_EN.indd 2 05.7.19 3:17:11 PM

EnglishEnglish 中文（繁體）中文（繁體）한국어한국어

To uninstall the Tablet Driver

When uninstalling the Tablet Driver from your PC follow the instructions below.

(These instructions are the same for Windows XP/2000/Me/98SE/98.)

* Users of Windows XP/2000 with system administrator settings in place

(administrator or administrator account) should log in with the administrator

user name to uninstall the drivers.

1. Click the Start button in Windows to open the Control Panel.

2. Double-click on Add or Remove Programs (or Add/Remove Programs).

3. Click on Tablet.

4. Click on Remove (or Change/Remove Programs) and follow the prompts

to complete uninstalling the Tablet Drivers.

5. Restart the PC.

For Windows 98SE users

❶ The Add New Hardware wizard will be displayed.

Follow the prompts, selecting the default options. If prompted to install drivers for the

USB Human Interface Device, insert the Windows 98SE CD, click OK, and enter the

location of the Windows CAB ﬁles (e.g., D:\WIN98). Note that the ﬁles may be located

on your hard disk in the C:\WINDOWS\OPTIONS\CABS folder.

❷ The following instructions are the same as Windows

XP/2000/Me. See steps 2–6 (on page 2) for driver installation.

G4_EN.indd 3 05.7.19 3:17:11 PM

For Mac OS X users

❶ Insert the Tablet Drivers CD-ROM into the CD-ROM drive.

If the installation screen does not appear, double-click the TABLET CD and double-

click Install.

❷ Click on Install Tablet.

• Password veriﬁcation screen appears.

❸ Enter the password and click OK.

❹ Follow the prompts to install the driver.

❺ Click the on the installation screen after installing the

driver.

To uninstall the Tablet Driver

When uninstalling the Tablet Driver from your computer follow the instructions

below.

1. Click Applications in the Go menu, and double-click Tablet.

2. Double-click Remove Tablet and select the method for uninstalling (only one

option may be displayed).

• Remove all preference ﬁles:

Deletes all user Tablet preferences including the user initiating the

uninstall.

• Remove Tablet Software:

Deletes Tablet Drivers and related software.

3. Enter the password and click OK.

• A dialog will appear after uninstalling is completed.

4. Click OK.

G4_EN.indd 4 05.7.19 3:17:11 PM

EnglishEnglish 中文（繁體）中文（繁體）한국어한국어

Operation instructions for the Graphire 4

How to use the Pen

Moving the pointer

Move the pointer on the screen by

floating the pen tip over the active

area.

Clicking

Lightly tap the pen tip onto the active

area.

Right-clicking (for Windows users)

Lightly touch the pen tip onto the active area and press the lower side switch for

right-clicking. (Settings at time of purchase).

Double-clicking

● Lightly tap the pen tip twice in the

same place on the active area.

● Lightly touch the pen tip onto the active area and press the lower side switch

for Macintosh users, or the upper side switch for Windows users. (Settings at

time of purchase).

G4_EN.indd 5 05.7.19 3:17:13 PM

Dragging

Lightly press the pen tip onto an

icon or folder and move it without

separating the pen tip from the active

area.

Using pressure-sensitivity

The thickness of lines and depth of color is controlled by applying force on the

pen tip. (Only applicable for software compatible with pen pressure-sensitivity

functions).

Using the eraser

Eraser function

Move the eraser end of the pen over

the active area to erase pictures and

handwritten text. (Only applicable for

software compatible with pen-eraser

functions).

Apply pressure to control the size of

the eraser.

Text erase function

Select a portion of text with the

eraser and release to delete. (Only

applicable for software compatible

with text data).

あいうえおかきく

あいうえお

G4_EN.indd 6 05.7.19 3:17:14 PM

EnglishEnglish 中文（繁體）中文（繁體）한국어한국어

How to use the ExpressKeys

The Graphire 4 comes with ExpressKeys to save function shortcuts to, and a

wheel for easy scrolling. Save often used functions to the ExpressKeys in order

to switch between tasks in one click while using the pen. Great for improving task

efﬁciency.

Default settings: Press the keys to move FORWARD (right key) or BACK (left key)

within your Internet browser.

ExpressKey (Right)

Use saved functions by a simple click

(refer to diagram below).

Wheel

Scrolls the screen.

ExpressKey (Left)

Use saved functions by a simple

click (refer to diagram below).

Active area

Online Manual details

Refer to the Online Manual for detailed instructions on how to use the Graphire 4.

Select the Online Manual by pressing the Start button, All

Programs (or Programs), Tablet then Userʼs Manual.

A mouse is not included with this product. Please skip the Online Manual

instructions referring to a mouse.

G4_EN.indd 7 05.7.19 3:17:15 PM

Obtaining Technical Support

If you have any problem with Graphire4, ﬁrst check the appropriate setup chapter

in this guide to make sure the unit is installed correctly. Then review the online

Help, your problem may be described there and you can try the solution offered.

You can also check the product Frequently Asked Questions on the Wacom web

site.

FAQ: http://club.wacom.co.jp/wacom-en/servlet/support.user.Swusr101Sv00

Support Staff

If you think your Graphire4 tablet is not working properly, contact the Wacom

authorized distributors in your area (Check your area distributor on the Wacom

web site: http://www.wacom.com.sg/distributor/dist_index.html), or contact us as

the following:

Asia/Paciﬁc & Oceania

By Inquiry Form: http://club.wacom.co.jp/support-en/servlet/support.user.

Swusr200Sv00

Tel: ++81-3-5309-1588

Fax: ++81-3-5309-1514

G4_EN.indd 8 05.7.19 3:17:15 PM
