Westinghouse WSFSB1601BU Manuale utente

16" Pedestal fan /

16" Ventilateur sur pied

Instruction Manual / Manuel d’instructions

WSFSB1601BU

WSFSB1601BU_Pedestal Fan_2L.indd 1WSFSB1601BU_Pedestal Fan_2L.indd 1 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

WSFSB1601BU_Pedestal Fan_2L.indd 2WSFSB1601BU_Pedestal Fan_2L.indd 2 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

CONTENT

SAFETY INFORMATION

IMPORTANT SAFEGUARDS....................................................................... 4

POLARIZED PLUG......................................................................................... 7

HOW TO USE

DESCRIPTION OF PARTS ........................................................................... 8

BEFORE FIRST USE ...................................................................................... 9

OPERATING INSTRUCTIONS..................................................................... 13

CLEANING AND CARE

STORAGE INSTRUCTIONS......................................................................... 14

DISPOSAL............................................................................................... 15

INFORMATION AND SERVICE........................................................... 15

WSFSB1601BU_Pedestal Fan_2L.indd 3WSFSB1601BU_Pedestal Fan_2L.indd 3 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

SAFETY INFORMATION

Read this instruction manual carefully before using the appliance.

It contains important information for your safety as well as for the

use and maintenance of the appliance. Keep these instructions for

future reference and pass them on to possible new owners of the

appliance.

1. Use the appliance only for its intended purpose and as

described in this manual. Improper use may result in an electric

shock, ﬁre or serious injury and may void the warranty. In the

event of improper use or incorrect operation, we do not accept

any liability for resulting damages.

2. This appliance is intended for household use only and not for

commercial, industrial or outdoor use.

3. This appliance is intended to be used in households and similar

applications such as:

- sta kitchen areas in shops, oces and other working

environments;

- farmhouses;

- by clients in hotels, motels, and other residential type

environments;

- bed and breakfast type environments.

4. To prevent the risk of an electrical shock, do not place the fan

near a window, immerse the appliance, plug or cord in water, or

spray the fan with liquids.

5. Do not operate the appliance with a damaged cord, or plug,

after a malfunction or if dropped or damaged in any manner. If

the appliance, cord or plug are damaged in any way, do not use

the appliance and contact the retail outlet, the manufacturer, or

an authorized service center.

IMPORTANT SAFEGUARDS

DANGER

DANGER – Immediate hazards

which WILL result in severe

personal injury or death

WARNING

WARNING – Hazards or unsafe

practices which COULD result in

severe personal injury or death

WARNING

When using electrical appliances, basic safety precautions

should always be followed, including the following

CAUTION

CAUTION – Hazards or unsafe

practices which COULD result in

minor personal injury

WSFSB1601BU_Pedestal Fan_2L.indd 4WSFSB1601BU_Pedestal Fan_2L.indd 4 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

SAFETY INFORMATION

6. This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

7. Close supervision must be provided when the appliance is used

by or near children. When the appliance is not in use, make sure

it is stored in a location that is inaccessible to children.

8. Children should be supervised to ensure that they do not

play with the appliance.

9. Never leave the appliance unattended while it is in

operation.

10. Always unplug the appliance from the mains outlet when it is

unattended, not in use, when moving the appliance from one

location to another, before removing the cover and before

cleaning.

11. The appliance should not be operated by an external timer

switch or remote control.

12. Place the appliance on a ﬂat, dry, heat-resistant and stable

surface.

13. Before ﬁrst use, make sure the power voltage matches the

information on the appliance rating label.

14. Do not under any circumstances attempt to dismantle or repair

the fan blade or motor. For servicing and repairs, contact the

retail outlet, the manufacturer, or an authorized service center.

15. Do not operate the appliance or any parts near explosive and/

or ﬂammable fumes, open ﬂames, cooking or other heating

appliances or ﬂammable materials (such as curtains, textiles or

walls).

16. Do not let the cord hang over sharp edges, the edge of a table

or counter or touch any hot objects.

17. Do not cover the cord with soft furnishings such as, carpets,

rugs, throws or runners. Never place the cord under furniture or

appliances. Arrange the cord in a location where it cannot be

easily caught on or tripped over.

18. To disconnect the appliance from the mains, grip the plug and

pull it out from the wall outlet. Do not pull the cord.

WSFSB1601BU_Pedestal Fan_2L.indd 5WSFSB1601BU_Pedestal Fan_2L.indd 5 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

SAFETY INFORMATION

19. The use of attachments is not recommended and may be

hazardous.

20. Never cover the appliance. Ensure there is sucient ventilation.

21. Avoid contact with the fan’s moving parts. Never insert ﬁngers,

pencils or other similar objects through the mesh cover.

22. Do not operate the appliance if the fan housing is not properly

ﬁxed in place, has been removed or is damaged.

23. The appliance must be assembled completely before use.

24. Keep hair or loose clothing away from the appliance when it

is in use, as there is a danger that they can be caught in the

appliance and cause injury.

25. Do not point the airﬂow directly at people for a long time.

26. Warning: To reduce the risk of electric shock, do not use

the appliance near a body of water such as a swimming pool,

bathtub, vase or pond, or in humid environments such as a

damp basement. Do not expose it to dripping or splashing

water. Do not immerse the appliance in water or any other

liquid or place it under running water (see CLEANING AND

CARE).

27. The use of accessories or ﬁttings other than the original parts

supplied with this appliance may result in an injury, ﬁre or

damages and will void the warranty.

28. To avoid the risk of injuries, make sure your hands are

completely dry before using the appliance.

29. After cleaning, ensure the appliance and parts are completely

dry before using it again.

30. RISK OF SUFFOCATION! KEEP OUT OF REACH OF

CHILDREN – Keep all packaging materials out of the reach of

babies and children.

31. Do not manually try to rotate the fan as this may damage it.

32. The optimum operating temperature range of the appliance is

32°F to 104°F (0°C to 40°C).

WARNING: To reduce the risk of a ﬁre or electrical shock DONOT

USE the appliance with any SOLID-STATE SPEED CONTROL

DEVICE.

WSFSB1601BU_Pedestal Fan_2L.indd 6WSFSB1601BU_Pedestal Fan_2L.indd 6 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

SAFETY INFORMATION

POLARIZED PLUG

The appliance has a polarized plug (one blade is

wider than the other). To reduce the risk of

electric shock, this plug is intended to ﬁt into a

polarized outlet only one way. If the plug does

not ﬁt fully into the wall outlet, reverse the plug.

If it still does not ﬁt, contact a qualiﬁed

electrician.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR ATTEMPT TO

DEFEAT ITS SAFETY FEATURE IN ANY WAY.

RETAIN THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

WSFSB1601BU_Pedestal Fan_2L.indd 7WSFSB1601BU_Pedestal Fan_2L.indd 7 11/3/2021 4:56:09 PM11/3/2021 4:56:09 PM

HOW TO USE

DESCRIPTION OF PARTS

2 3 4 65

WSFSB1601BU_Pedestal Fan_2L.indd 8WSFSB1601BU_Pedestal Fan_2L.indd 8 11/3/2021 4:56:10 PM11/3/2021 4:56:10 PM

1. Front cover

2. Blade cap

3. Fan blade

4. Plastic nut

5. Rear cover with handle

6. Motor shaft

7. Oscillation knob

8. Motor

9. Control panel – 0 (on/o),

speed level 1, 2 or 3

10. Locking screw

11. Extendable pole

12. Locking collar

13. Base

14. Screw with lever and metal

disc

15. Power cord and plug

NOTE: All images shown are for illustrative purposes only and may

not be an exact representation of the appliance model.

BEFORE FIRST USE

• Unpack and remove all packaging materials from the appliance

and accessories.

• Check for damage that may have occurred during transport.

If any parts are damaged or missing, do not use the appliance

and return it to your retail outlet immediately.

ASSEMBLING THE FAN WITH PEDESTAL

1. Take the extendable pole (11) and turn the screw with lever (14)

counterclockwise until the metal disc (14) and screw with lever

(14) are loose enough to be removed from the extendable pole

(11). Then slot the extendable pole (11) onto the hole on the top

of the base (13). Put the metal disc (14) over the hole on the

underside of the base (13) and insert the screw with lever (14)

and turn clockwise until it is securely ﬁxed into place. Turn the

base (13) upright and place on the ﬂoor.

HOW TO USE

WSFSB1601BU_Pedestal Fan_2L.indd 9WSFSB1601BU_Pedestal Fan_2L.indd 9 11/3/2021 4:56:10 PM11/3/2021 4:56:10 PM

2. Turn the locking screw (10) on the bottom of the motor /

control button panel (8/9) counterclockwise to loosen the

screw and then place the motor (8) onto the extendable

pole (11). Secure into place by turning the locking screw (10)

clockwise.

HOW TO USE
