Westinghouse WSFTDXS32BK Manuale utente

32” OScillating Tower Fan

Ventilateur vertical oscillant 32’’

Instruction Manual / Manuel d’instructions

WSFTDXS32BK

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 1 9/12/2019 17:35:53

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 2 9/12/2019 17:35:53

CONTENT

SAFETY INFORMATION

IMPORTANT SAFEGUARDS....................................................................... 4

POLARIZED PLUG......................................................................................... 6

BATTERY........................................................................................................... 7

HOW TO USE

ASSEMBLY........................................................................................................ 8

PARTS DESCRIPTIONS ............................................................................... 9

OPERATION INSTRUCTIONS .................................................................... 9

CLEANING AND MAINTENANCE...................................................... 11

DISPOSAL............................................................................................... 11

INFORMATION AND SERVICE........................................................... 11

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 3 9/12/2019 17:35:53

SAFETY INFORMATION

1. Read this manual thoroughly before first use. It contains

important information for your safety as well as for the use

and maintenance of the equipment. Keep these instructions for

future reference. Pass them on to possible new owners of the

appliance.

2. Use the appliance only for its intended purpose. Improper use

may lead to hazards.

3. This appliance is intended for normal household use only. It is

not intended for outdoor use.

4. Do not use the appliance for any purpose other than described

in this manual.

5. The appliance is NOT recommended to use with electrical

extension cords, this will greatly increase risks of fire and or

electrical shock.

6. Keep the appliance and its power cord out of the reach of

children when it is in operation.

7. Children should be supervised to ensure that they do not play

with the appliance.

8. Never operate the appliance unattended.

9. Never insert your fingers, pencils or any other objects through

the fan covers when the fan is running. Never drop or insert

objects into any of the fan’s openings.

10. Do not under any circumstances attempt to repair the

appliance yourself. For serving and repairs, contact our after-

sales service team to arrange a repair or replacement.

11. The use of accessory attachments is not recommended by the

appliance manufacture as it may cause injuries.

IMPORTANT SAFEGUARDS

DANGER

DANGER – Immediate hazards

which WILL result in severe

personal injury or death

WARNING

WARNING – Hazards or unsafe

practices which COULD result in

severe personal injury or death

WARNING

When using electrical appliances, basic safety precautions

should always be followed, including the following

CAUTION

CAUTION – Hazards or unsafe

practices which COULD result in

minor personal injury

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 4 9/12/2019 17:35:53

SAFETY INFORMATION

12. Before first use, make sure the power voltage matches the

information on the rating label of appliance.

13. If the power cord is damaged, it must be replaced by the

manufacturer, an authorized service agent or a similarly

qualified person.

14. Do not let the power cord hang over the edge of table counters

or allow it to touch hot surfaces.

15. The power plug is used as the disconnect device. Please be

sure that the power plug is in operable condition.

16. Removing the power plug is the only way to separate the

appliance completely from power supply.

17. Disconnect from power supply by pulling the power plug

instead of the power cord.

18. Always attach the power cord to the appliance ﬁrst, then plug

the power cord into the wall outlet. To disconnect, power off

your appliance first then remove the power cord from the wall

outlet.

19. Disconnect the power plug before moving it from one location

to another, or when the appliance is not in use, in case of

malfunctions and prior to each cleaning.

20. Place the appliance on a flat, dry and stable surface.

21. Always make sure the plug is inserted into the wall outlet

properly.

22. Make sure you use the appliance when it stands vertically from

its base.

23. Do not operate this appliance near flammable materials (e.g.

curtains, textiles, walls) and never cover it. Ensure that there is

always a sufficient safe distance from flammable materials.

24. Warning: Do not use this appliance near water or heavy

moisture; e.g. in a damp basement or beside a swimming pool

or bathtub.

25. In order to reduce the risk of fire and electric shock, do not

expose the appliance to fire (fireplace, grill, candles, cigarettes

and so on) or water (water drops, water splashes, vases, tubs,

ponds and so on).

26. Clean the appliance on a regular basis to maintain it in a good

condition.

27. No liability shall be incurred by non-compliance with these

instructions or any other improper use or mishandling.

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 5 9/12/2019 17:35:54

RETAIN THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

SAFETY INFORMATION

POLARIZED PLUG

This appliance has a polarized plug (one blade

is wider than the other). To reduce the risk of

electric shock, this plug is intended to fit in a

polarized outlet only one way. If the plug does

not fit fully in the outlet, reverse the plug, if it

still does not fit, contact a qualified electrician.

Do not modify the plug in any way.

DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS

SAFETY FEATURE IN ANY WAY.

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 6 9/12/2019 17:35:54

RETAIN THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

SAFETY INFORMATION

BATTERY

WARNING – CHEMICAL BURN AND CHOKING HAZARD. KEEP

BATTERIES AWAY FROM CHILDREN.

This product contains a lithium button/ coin cell battery in the

remote control unit. If a new or used lithium button/ coin battery

is swallowed or enters the body, it can cause severe internal burns

and can lead to death in as little as 2 hours. Always completely

secure the battery compartment. If the battery compartment does

not close securely, stop using the remote control unit. Remove the

batteries, and keep it away from children. If you think batteries

might have been swallowed or placed inside any part of the body,

seek immediate medical attention.

CAUTION

• Do not install backwards or short circuit the batteries.

• Do not attempt to dismantle or charge the batteries. Keep

away from fire.

• Follow battery manufacturers instructions when installing new

batteries.

• The cells shall be disposed of properly, including keeping them

away from children; even used cells may cause injury.

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 7 9/12/2019 17:35:54

HOW TO USE

ASSEMBLING THE TOWER FAN

1. Loosen the base holder (F) and take it off from the bottom of

the fan housing (D).

2. Place the power cord through the centre of two base panels

(A) and (B).

3. Snap the two base panels (A) and (B) together by fixing one

base panel into the slots of another base panel.

4. Attached the the base to the fan housing, put the base holder

(F) back and tighten it.

•

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 8 9/12/2019 17:35:54

PARTS DESCRIPTIONS

1 Control panel 4 Back cover

2 Front cover 5 Power wire

3 Base

OPERATION INSTRUCTIONS

After connecting the tower fan to the power supply, you can

operate it with the control panel (1) or remote control buttons.

Note: Make sure the tower fan is turned on before you can use all

functions.

HOW TO USE

WSFTDXS32BK_32 Oscillating Tower Fan_2L.indd 9 9/12/2019 17:35:54

Button Functions

Press to turn the tower fan on or off.

Press to adjust the fan speed (low, mid, high).

Press to change the fan to different working modes

(normal, natural, sleep).

Each press will increase the working time timer of the

tower fan for half an hour (from 0.5 hours to 7.5 hours).

Press to start or stop oscillating.

Status of the light indicators

The light indicators will show you the current status of wind speed,

working mode and timer.

Speed Mode Timer

Low Natural 0.5H 0.5 hour

Mid Sleep 1H 1 hour

High Normal 2H 2 hours

4H 4 hours

Replace the remote control battery

When the remote control buttons do not respond properly, the

battery may have run out. Replace with a new 3V Lithium battery

(Model: CR2025).

HOW TO USE
