TOP AND CONSOLE PARTS

For Models: LER4624BW2, LER4624BN2, LER4624BQ2

(White) (Almond) (Desinger White)

2−95 Litho in U.S.A. (dhb) Part No. 4377380

ELECTRIC DRYER

TOP AND CONSOLE PARTS

LITERATURE AND OPTIONAL PARTS

For Models: LER4624BW2, LER4624BN2, LER4624BQ2

(White) (Almond) (Desinger White)

4377380

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

3397545

Panel, Rear

Console

688805

Clip

3390646

Screw,

8−18 x 5/16

Cap, End (L.H.)

3358531

White

3358532

Almond

689180

Clip, Retainer

3353145

Screw, Console

3388706

Resistor

Cap, End (R.H.)

3358516

White

3358517

Almond

3390647

Screw, 8−18 x 1/2

339392

Screen, Lint

Cover, Lint Screen

688150

White

689310

Almond

339229

Hinge, R.H.

339230

Hinge, L.H.

688983

Screw, 8−18 x 5/8

693995

Screw, Hex Head

Top

3396022

White

3396023

Almond

3395683

Connector

(Motor)

3394427

Clip, Harness

3397269

Connector, Timer

3392250

Timer, 60 Hz.

357213

Nut, Push−In (2)

3399653

Harness, Wiring

3395382

Switch,

Push−To−Start

3396145

Timer Knob

Assembly

3396146

FOR MODEL

LER4624BQ2

3396293

Bracket, Control

Panel, Control

3397192

FOR MODEL

LER4624BW2

3397193

FOR MODEL

LER4624BN2

3397194

FOR MODEL

LER4624BQ2

690853

Wire, Ground

3396160

Knob, Push

To Start

3396161

FOR MODEL

LER4624BQ2

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

LITERATURE PARTS

LIT3396303

Guide, Use & Care

LIT3397597

Instructions,

Installation

LIT3401728

Label, Wiring

Diagram

OPTIONAL PARTS NOT INCLUDED

PAINT, TOUCH−UP (1/2oz.)

72017

White

72107

Almond

PAINT, PRESSURIZED SPRAY

(13 oz.)

350930

White

350956

Almond

350938

Primer, Gray

PAINT, BULK (1 qt.)

799344

White (Uncut)

978883

Almond (Uncut)

Following May Be Purchased

DO−IT−YOURSELF

REPAIR MANUALS

LIT677818

Dryer

CABINET PARTS

For Models: LER4624BW2, LER4624BN2, LER4624BQ2

(White) (Almond) (Desinger White)

4377380

CABINET PARTS

For Models: LER4624BW2, LER4624BN2, LER4624BQ2

(White) (Almond) (Desinger White)

4377380

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

3393008

Screw, 10−16 x 1/2

230131

Cable, Door (2)

3396795

Cover, Terminal

Block

694091

Screw

3396807

Panel, Rear

339493

Screw

688160

Screw, 8−15 x 1/2

347207

Switch, Door

98129

Screw,

6−20 x 1−3/8 (2)

691581

Lever, Door Switch

693995

Screw, Rear Panel

Mounting

337186

Spring, Door

660975

Plug

3392100

Foot, Dryer (4)

343641

Screw,

10−16 x 1/2

Cabinet

(Includes Illus.

Nos. 5,7,16,29,

41, & 57)

3399580

White

3399581

Almond

98234

Clip, Ground

690363

Lock, Front

Top (2)

Upper Front

Panel Assembly

337464

White

689525

Almond

685203

Clip, Felt Pad

690081

Catch, Door

238456

Hinge, Door (R.H.)

238460

Hinge, Door (L.H.)

3394083

Clip, Front

Panel (2)

98997

Clip, Harness

696144

Strike, Door

695953

Door, Rear

Door Front

348737

White

689485

Almond

Handle, Door

690270

White

690271

Almond

349462

Seal & Bearing

Assembly

279393

Terminal Block

Kit For

Terminal Block

690261

Block, Terminal

337182

Guide, Cable(L.H.)

337183

Guide, Cable(R.H.)

238088

Hinge, Top (2)

691366

Idler & Pulley

Assembly

660996

Belt, Drive

348780

Base, Motor

172455

Bolt,

5/16−18 x 3/4

3401143

Pulley, 60 Hz.

3395652

Motor Assembly

60 Hz.

660658

Clamp, Motor

343481 (Alt.)

685441 (Alt.)

3390734

Seal, Door

697776

Screw, 10−32 x 1/2

(External Ground)

279318

Terminal, Tinned

& Brass (3)

(Includes Illus. 40)

BULKHEAD PARTS

For Models: LER4624BW2, LER4624BN2, LER4624BQ2

(White) (Almond) (Desinger White)

4377380

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

694283

Lint Chute Assembly

3388703

Washer, Support

90767

Screw, 8 x 3/8

3399848

Thermal, Cut−Off

(Hi−Limit

Thermostat Illus.

No.15 Included)

347139

Seal, Lint

Chute

3392247

Pad, Blower

Housing

694089

Wheel, Blower

695081

Housing, Blower

3398161

Clip

343641

Screw, 10−16 x 1/2

3397566

Box, Heater

3390291

Thermostat,

High Limit 250 F

(121.1 C) (60 Hz.)

3392123

Seal, Blower

Shaft

3398064

Element, Heater

(For 240 Volt

Installation)

693300 (Alt.)

693298 (Alt.)

693062 (Alt.)

279457

Wire Kit (For

Heater Element

Wiring Harness

Repair)

3392519

Fuse, Thermal

660039

Thermostat,

150 F / 66C

690997

Ring, Tri

3399506

Shaft, L.H.

3399507

Shaft, R.H.

3397588

Roller, Support

348197

Washer, Support

3359452

Nut, 3/8−16

3397264

Bulkhead

3394508

Ring, Bearing

97787

Screw, 11−16 x 7/8

337449

Seal, Rear Drum

3396775

Drum Assembly

342847

Baffle, Drum

3394133

Bracket, Support

90296

Clip

339956

Seal

3400800

Screw, 8−18 x 3/4

696302

Shield, Exhaust
