Whistler TITAN Manuale utente
User Guide
RADAR DETECTOR
1
Dear Whistler Customer,
If you have questions concerning the operation of this Whistler
product please call:
Customer Service
1-800-531-0004
Monday - Friday • 8:00 am - 5:00 pm CT or visit our website
www.whistlergroup.com
Please keep the receipt in a safe place. You may register your
product online at www.whistlergroup.com. For warranty
verication purposes, a copy of your dated store receipt must
still accompany any unit sent in for warranty work. If the unit
is returned without a dated store receipt, an out-of-warranty
service charge applies.
NOTE: Your warranty period begins at the time of purchase.
The warranty is validated only by the dated store receipt!
Please record the serial number of the unit in the space provid-
ed in the accessories section of the guide.
To fully acquaint yourself with the operation of your Whistler
detector and to better understand the dierences between
detecting radar, laser, and safety radar signals, we recommend
reading this entire guide or visiting our Help center & FAQ page
on our website www.whistlergroup.com.
Enjoy your Whistler detector and please drive safely.
Sincerely,
The Whistler Group, Inc.
WELCOME
2
TABLE OF CONTENTS
Feature Description ............................................................... 4-6
Installation ............................................................................. 7-9
Mounting Guidelines/Windshield Mounting
Power Cord Connection/Fuse Replacement
General Operation............................................................. 10-15
Power On Self-Test and Volume
Audio Level Adjustment
Integrated Real Voice®
Feature Engaged Conrmation
Setting Saver
Understanding the Display
Signal Strength Display
Teach / Tutorial Mode
Highway / City / City 1 / City 2 / Auto City
Quiet / XK Location Quiet
Dim / Dark Modes / Auto Dim
Stay Alert / Alert Priority
Menu Options .................................................................... 16-18
S1 / S2 Functions (works with INTELLICORD 2.0)
User (Custom Modes)
Alert LED
Battery Voltage Alert / Vehicle Battery Saver Mode
Tone / AQ / Language / RSID Voice / Voice
X / K / Ka Band / Sensitivity / Frequency Display Options
Ka Band Segmentation
Ka POP / K and Ka Filter / TFSR
MRCD / MRCT
Laser Signature ID (LSID)
Segmented Selectable Laser Receiver
3
GPS / DB / USER Alerts.................................................... 19-22
GPS / SPDVOL / AQ SPD / AQ VOL / LSQ / C-SPD / O-SPD
Auto Learn XK / Auto Unlearn XK / Delete
Updating DATABASE ............................................................. 23
Updating FIRMWARE............................................................. 24
Updating DSP......................................................................... 25
Radar Features....................................................................... 26
GPS Features......................................................................... 27
Factory Reset .................................................................... 28-29
Option Select Mode........................................................... 30-32
Troubleshooting................................................................. 33-34
Care and Maintenance
Legal Notices.......................................................................... 35
Are Detectors Legal?
FCC ........................................................................................ 36
Radar/Laser Alerts.................................................................. 37
Radar Alerts
Laser Audio/Visual Alerts
Pulse Protection®
POP Mode
Speed Monitoring .............................................................. 38-41
Laser Facts
Laser Tips
Radar Facts
Other Speed Detection Systems
Radar Detector Detectors
Warranty Information ......................................................... 42-45
Specications ......................................................................... 46
TABLE OF CONTENTS
4
FEATURE DESCRIPTION
3
5
4
16
17
1
2
8
9
7
13
14
15
10
12
6
11
5
FEATURE DESCRIPTION
1. Bracket Release Button - provides quick and easy
release of the mounting bracket.
2. Speaker - provides distinct audio warnings.
3. Mounting Bracket Location - slot holds mounting bracket
rmly.
4. Radar Antenna - high-eciency antenna receives radar
signals.
5. Front Laser - provides increased sensitivity and eld of
view for leading-edge laser detection.
6. City Button - reduces the annoyance of false alerts
typically encountered in the city.
Press and hold 2 seconds to enter RU Alert.
Press when in Menu to reverse Menu order.
7. Quiet Button - press to quiet a radar/laser alert.
Press twice when alerting X or K band, to store XK
location quiet.
Press during an XK quiet event to clear stored XK location
quiet.
Press during power up to enable or disable the Power On
audio self-test.
Press when in Menu to enable, disable or select the
condition of the displayed feature.
6
FEATURE DESCRIPTION
8. Power / Volume Control - Press in to turn unit on/o.
Move toward or away from you adjusts the audio level.
Edits select Menu items.
Press and hold 3 seconds to store a USER LOC waypoint.
9. Dim / Dark - engages Dim/Dark modes.
Pressing when in Menu will toggle selection.
Pressing when in RU Alert will Exit RU Alert.
10. Menu Button - enters/advances Option Select Mode.
11. OLED Text Display - provides better contrast, brightness
and color/shows alerts detected, signal strength, and
modes of operation.
12. GPS Antenna - provides Trac Camera alerts as well as
other speed selective settings.
13. Power Port - connection for the power cord.
14. USB Port - connection to a PC Only for FW, DSP, and
Database updates.
15. External Audio Port - 2.5 mm size port for external audio
(16-ohm speaker).
16. Intellicord S1/S2 Function - Short press = S1 function,
Long press = S2 function.
17. Intellicord USB Output - 2A to charge mobile devices.
7
INSTALLATION
Mounting Guidelines
• Do not mount unit behind wipers, ornaments, mirrored
sunscreens, etc. These obstructions have metal surfaces
which can aect radar and laser signals and reduce critical
warning time.
• Some windshields have an Instaclear™ or Electriclear™
type coating which may aect radar. Consult your
dealer or the vehicles owner’s guide to determine if your
windshield has this coating.
• To reduce the possibility of theft, conceal your unit when
not in use.
Notice to Drivers in California and Minnesota:
State law prohibits drivers in California and Minnesota from
using suction mounts on their windshields while operating
motor vehicles. Dashboard mounting options should be used.
(See California Vehicle Code Section 26708(a); Minnesota
Statutes 2005, Section 169.71).
Check local laws for compliance.
Important: Some vehicles may have a plastic safety coating
on the inside of the windshield. The windshield bracket may
leave permanent marks. Check the vehicles owner's guide or
ask your dealer before applying suction cup mount.
8
Windshield Mounting
• Clean the selected area of the windshield for mounting
using a quality glass cleaner.
• Install the 2 suction cups and rubber bumper onto the
bracket by tting them into their holes.
• Press the suction cup rmly onto the windshield.
• If necessary, the unit may be leveled by bending the
windshield bracket.
Important: Remove the detector before bending.
• Slide detector onto bracket until it locks in place.
• Press release button on left side to remove.
NOTE:
• Remove detector from bracket when not in use.
• To allow air to pass below the unit, do not place directly on
dashboard.
INSTALLATION
Rubber
Bumper
9
Power Cord Connection
• Plug the small end of the power cord into the unit’s power
port.
• Plug the large end into the vehicle’s cigarette lighter/12V
accessory socket.
NOTE: Cord ts tightly into detector. When installing the cord,
expect some resistance.
The power plug USB port can be used to power or charge a
mobile device. The output for the USB port is 2A.
Fuse Replacement
The lighter/12V accessory socket plug is equipped with a
replaceable 4-amp fuse located behind the silver tip. To replace
the fuse, carefully unscrew the tip of the plug.
Important: Unscrew slowly. The tip contains a spring which
may y out when disassembling. Insert the new fuse with the spring
and screw on the tip. With use, screw cap on plug may loosen.
Retighten occasionally.
INSTALLATION
