Williams Sound DLR 60 2.0 Manuale utente
DLR 60 2.0
Digi-Wave™Rechargeable Digital Receiver
QUICK SETUP GUIDE
MAN178B
DLR 60 2.0 Rechargeable Digital Receiver
Safety Information
HEARING SAFETY
CAUTION!
This product is designed to amplify sounds to a high
volume. To protect your hearing and the hearing of
others:
1. Make sure the unit is OFF or the volume is turned
down before putting on the earphones.
2. Set volume level at the minimum setting you need to
hear.
3. Do not allow children or other unauthorized persons
to have access to this product.
BATTERY SAFETY
CAUTION!
Do not attempt to recharge alkaline or other non-
rechargeable batteries, which may explode, release
dangerous chemicals, cause burns, or cause other
serious harm to the user or product. To reduce the risk
of re or burns, do not crush, puncture, short contacts,
or expose to temperatures above 140F (60C). Replace
only with battery types designated for this product.
Recycle or dispose of properly.
MEDICAL DEVICE SAFETY
CAUTION!
Before using this product with a pacemaker or other
implantable medical device, consultant your physician
or the manufacturer of the device to make sure that you
are using this product in accordance with their safety
guidelines.
DLR 60 2.0 Rechargeable Digital Receiver
Operating Instructions
DLR 60 2.0 compatible with Williams Sound DLT 100
and DLT 100 2.0 models only.
1. One DLT 100/2.0 assigned as the Master must be on.
2. Insert two AAA batteries into the DLR. Be sure
to observe correct polarity. If NiMH rechargeable
batteries are being used, change the battery type
switch from "ALK" to "NiMH". Failure to match
battery type with the switch may cause damage
to the unit.
3. Power on by holding the power button for 3 sec.
4. If the DLT 100/2.0 is in one-way/interpretation mode,
the DLR will seek an active DLT. Press the ^or v
button to seek the active DLT channel. In two-way
mode, group must be selected.
5. To change group, push the ^or vbutton until the
correct group is displayed. It can take up to 5
seconds for the DLR to sync with the DLT.
6. The antenna symbol will ash if not synched with a
DLT 100/2.0. When synched, the antenna symbol
stays on and signal strength bars show up.
7. If the units are synched, briey push the power button
to show group assigned, 0 to 99.
8. To change volume level, press "vol+" or "vol-" button.
Display will show "VOLUME" and number "0"-"30".
DLR 60 2.0 Rechargeable Digital Receiver
9. Users can listen using the speaker on the back of the
DLR - or by plugging in stereo or mono earphones
into the jack (which defeats the speaker operation).
10. Low battery is indicated by no bars inside the battery
symbol on the display, and the battery symbol ashes.
11. The DLR will automatically power down after 5
minutes if not synched with a DLT.
12. The RED LED blinks when charging; the GREEN LED
glows solid when charged (use NiMH batteries only).
A467
RED LED GREEN LED
CH/GROUP
CHANGE
VOLUME
ADJUST
POWER
HEADPHONE
JACK
SPEAKER
BATTERY
STRENGTH
BATTERY TYPE
SWITCH
LANYARD
SLOT
CHARGING / DOCKING
CONNECTOR
STRENGTH DLT#1
STRENGTH DLT#2
NUMERIC DISPLAY
NUMERIC TYPE
DIGIWAVE 2.0
ANTENNA
SYMBOL
Controls and Connectors
DLR 60 2.0 Rechargeable Digital Receiver
Specications
Battery type (2) AAA, Alkaline or NiMH
Battery life Alkaline Disposable: Up to 27 hrs
NiMH Rechargeable: Up to 21 hrs
Groups (Channels) Up to 15 simultaneous groups
(1-way mode)
Up to 4 simultaneous groups
(2-way mode)
Operating frequencies 2.4GHz (ISM band)
Range Up to 100ft outdoors and 200ft indoors*
Speaker Internal speaker (disabled when
headphone jack is engaged)
Indicators LCD (Group, channel, volume level,
battery status, mode)
Red LED-charging, Green LED-charged
Approvals FCC, Industrie Canada, CE, C-tick,
RoHS, WEEE
Warranty 2 years parts and labor (90 days on most
accessories).
*Depending on environmental conditions
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Recycling Instructions
Help Williams Sound protect the environment!
Please do not dispose of equipment or used
batteries in the household trash. Take the
equipment to an electronics recycling center or
return to the factory. Take batteries to a retail or
community recycling location.
DLR 60 2.0 Rechargeable Digital Receiver
Limited Warranty
Williams Sound products are engineered, designed and
manufactured under carefully controlled conditions to
provide you with many years of reliable service. Williams
Sound warrants the DLR 60 2.0 receiver against
defects in materials and workmanship for two (2) years.
During the rst two years from the purchase date, we
will promptly repair or replace the DLR 60 2.0 receiver.
Earphones, headphones, cables, carry cases, and all
other accessory products carry a 90-day warranty.
WILLIAMS SOUND HAS NO CONTROL OVER THE
CONDITIONS UNDER WHICH THIS PRODUCT IS
USED. WILLIAMS SOUND, THEREFORE, DISCLAIMS
ALL WARRANTIES NOT SET FORTH ABOVE, BOTH
EXPRESS AND IMPLIED, WITH RESPECT TO THE
DLR 60 2.0 RECEIVER, INCLUDING BUT NOT LIMITED
TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE.
WILLIAMS SOUND SHALL NOT BE LIABLE TO ANY
PERSON OR ENTITY FOR ANY MEDICAL EXPENSES
OR ANY DIRECT, INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY ANY USE, DEFECT, FAILURE
OR MALFUNCTION OF THE PRODUCT.
DLR 60 2.0 Rechargeable Digital Receiver
This device complies to “RSS-Gen Issue 2 June 2007”
for Industry Canada and FCC part 15.105(b) for the
United States.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
This device complies with ICES-003 class B. Test data
is available from the manufacturer on request.
This device complies with FCC part 15.105 (b)
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment. This equipment is a handheld device and
should be maintained with a minimum safety distance
of 20cm from the antenna. This transmitter must not be
co-located or operated in conjunction with any other
antenna or transmitter.
Note: FCC regulations, section 15.21, requires the
user to comply with the rules of transmitter operation.
Any changes or modications made by the user not
expressly approved for compliance may result in
the loss of all privileges and authority to operate the
equipment.
Printed in the USA · ©2013 Williams Sound · All Rights Reserved. MAN178B
10300 Valley View Rd • Eden Prairie, MN 55344
800-328-6190 / 952-943-2252 • FAX: 952-943-2174
www.williamssound.com
Preliminary
Customer Service
If you experience difculty with your system, call Toll-
Free for Customer Assistance:
1-800-843-3544 (U.S.A.) or
+1 952 943 2252 (Outside the U.S.A.)
If it is necessary to return the system for service, your
Customer Service Representative will give you a Return
Authorization Number (RA) and shipping instructions.
This is a quick setup guide. For a
detailed user manual, please visit
our website.
