Winegard Air 360 Plus AR2-360, AR360AM, AR2360C, AR-360K Quick Start Guide

OPERATION

Run a channel scan to receive maximum

programming. A scan will find any new channels

that have been added in your area, plus find any

channels that have changed or moved since the

last scan. Steps to perform a channel scan vary

between televisions/compatible devices; below are

general guidelines to follow.

1Ensure the antenna power supply

(wall plate) is in the “ON” position and

the green indicator light is illuminated.

2Using the television remote, select MENU

and then SETTINGS.

3Select CHANNEL SETUP.

4Select ANTENNA or AIR depending on

your TV. Make sure you are not on CABLE.

5Select CHANNEL SEARCH or CHANNEL

SCAN. Keep in mind that steps to perform a

channel scan may vary. If the wording from

your TV differs from the options shown,

refer to your TV user manual for help.

NOTE: Running a channel scan is NOT the same

as pressing Channel UP/DOWN on your

remote.

TIP: To receive maximum programming and keep

your channel line-up up-to-date, it is a good

idea to run a channel scan monthly, anytime

a channel is lost, and anytime you change

locations.

OMNIDIRECTIONAL HDTV/AM/FM ANTENNA + WIFI + 4G EXTENDER*(AM/FM on select models only)

NEXTGEN TV™Ready

(ATSC 3.0)

*When paired with compatible

Winegard Gateway (GW-1000 or GW-PRO1)

Rev 10-22 2452449

NEXTGEN TV is a trademark of Consumer Technology Association. AT&T and the Globe Logo are owned by AT&T Intellectual

Property.Verizon Wireless is a trademark of Verizon Trademark Services, LLC. T-Mobile, the magenta color, and the digits

design are registered and/or unregistered trademarks of Deutsche Telekom AG. All trademarks, registered trademarks and

logos are the property of their respective owners and are not affiliated with Winegard Company.

SCAN

FOR

WARRANTY

OR CALL

800-288-8094

Winegard Company 2736 Mt. Pleasant St. |Burlington, IA

PRODUCT

INFORMATION

For help, email help@winegard.com or call 1-800-288-8094

Winegard Air 360 Plus AR2-360, AR360AM, AR2360C, AR-360K Quick Start Guide

Rev 10-22 2452449

NEXTGEN TV is a trademark of Consumer Technology Association. AT&T and the Globe Logo are owned by AT&T Intellectual

Property.Verizon Wireless is a trademark of Verizon Trademark Services, LLC. T-Mobile, the magenta color, and the digits

design are registered and/or unregistered trademarks of Deutsche Telekom AG. All trademarks, registered trademarks and

logos are the property of their respective owners and are not affiliated with Winegard Company.

SCAN

FOR

WARRANTY

OR CALL

800-288-8094

Winegard Company 2736 Mt. Pleasant St. |Burlington, IA

PRODUCT

INFORMATION

For help, email help@winegard.com or call 1-800-288-8094

WINEGARD GATEWAY

APPROVED WINEGARD

SATELLITE ANTENNAS*

DISH Playmaker, Pathway X1,

Carryout G2+ and G3

GW-1000

GW-PRO1

CERTIFIED BY AT&T, VERIZON AND TMOBILE

NO CONTRACT DAY PLANS

Ceiling

Cap

Simple

DIY Hook up

The Winegard Gateway is compatible with the Winegard Air 360 Plus

ONLY. It is the accompanying piece to take your Air 360 Plus to the next

level in connectivity.

• Upgrade Your Air 360 Plus to a Live Hotspot for WiFi and 4G LTE – Easily

access WiFi and 4G LTE networks and securely rebroadcast to all of your

devices.

• Maximizes Speed & Range – Stay connected with improved speeds in

remote locations where WiFi or cellular options are nonexistent or very

weak.

• GPS Increases Security – Easily ﬁnd your RV at a crowded campsite and

monitor your RV’s IoT from anywhere.

• Flexible Data Plans with Bring Your Own SIM Option – Choose between

Winegard FreedomGO, AT&T, Verizon Wireless, or T-Mobile.

For more information please visit www.winegard.com/gateway

or visit your local RV Dealer.

The satellite antenna connection is recommended for Winegard domed

satellite TV antennas.

The following satellite products have been tested with Keystone RV’s

exclusive KeyTV Plug-and-Play technology. Attempting to use with any

other satellite may not work.

INSTALLATION REQUIREMENTS:

• The satellite antenna must be installed at a minimum of 6 feet away

from the Air 360 Plus.

• Coax with weatherproof connectors should be used when connecting

to the satellite F-Jack on the Air 360 Plus.

• If removing a satellite antenna, the factory installed F-Jack cap should

be reattached to avoid water intrusion and/or corrosion.

• Some antennas require a power inserter to be installed inside the RV

between the KeyTV and the Air 360 Plus.

• The Playmaker and Pathway may require the purchase of a Winegard

power inserter (Winegard Model PI-GM60) if the coax cable run to the

satellite antenna exceeds our recommended length (25’).

*Only AR-260K models
