Winix NK105 Manuale utente

NK105

User Manual

xPlease read and follow all safety rules and instructions in

this manual before operating.

xThe product warranty is printed on the back of this guide,

so please keep it in a safe place for future use.

xThis product is manufactured for use only in USA/CA

Model

WINIX AIR CLEANER

Use & Care

Guide

English

NK105

CONTENTS

Set Up

Where to use 7

Filter Anatomy 8

Installing the filters 10

Safety Instructions

Safety and Cautions 12

Operation

Initial Operation 13

Modes of Operation 14

Features and Settings 15

WINIX SMART (Wi-Fi) 17

Care and Maintenance

Filter Care 18

Cleaning Care 22

Troubleshooting

Frequently Asked Questions 23

Unit Specifications 25

Product Warranty 26

This product is suitable for 120V only.

4-Stage Air Purification 5

Controls 6

English

NK105

VOC Smart Sensor

PACKAGE

CONTENTS

Back panel

Power cord with plug

(This product is suitable for

120V only.)

360o All-in-One True HEPA

Filter

➊ Pre-Filter

➋ True HEPA

➌ CD Carbon Filter

➍ PlasmaWave®

4-STAGE AIR PURIFICATION

Unit 360

All-in-One True

HEPA Filter

User Manual

English

NK105

CONTROLS

Reset Button

After replacing a filter,

press the RESET button

for at least 5 seconds.

PlasmaWave® Indicator

Indicates whether

PlasmaWave® is enabled or

disabled.

Mode Button

- Press to cycle through manual fan speeds (Low, Medium, High, Turbo).

- Pressing will also cycle through Auto and Sleep Modes.

- When sleep mode is selected the Air Quality Indicator light will be turned off.

- Press and hold for at least 3 seconds to enable or disable PlasmaWave®.

Power Button

Turns the unit

on or off.

Light Sensor

Detects the

amount of

ambient light

within the

environment,

to adjust the

brightness

of the LED

indicators.

Wi-Fi Button

Enables or disables

the Wi-Fi feature.

Change Filter Indicator

LED light indicates when it is time to

change the filter.

Air Quality Indicator

Color-coded LED indicates

one of three levels of air

quality.

Air Outlet Vent

Wi-Fi Indicator

Indicates whether Winix

Smart feature is enabled or

disabled.

English

NK105

WARNING Follow these instructions to reduce the risk of serious

injury or death and to reduce risk of damaging the unit.

WHERE TO USE

Do not use around mist or fumes from

industrial oil or around large quantities of

metallic dust

Do not install in any sort of motor or

transport vehicle (trucks, boats, ships, etc.)

Do not place near any flammable materials

(aerosols, fuel, gases etc.)

Do not place below any electrical outlet

Do not place around heating elements

Do not place in an area with excessive

amounts of noxious gases

Do not have unit facing into wind or draft

Do not place in excessively humid areas

where unit may become wet

Allow 12 ~ 18 in. of space between TVs, radios, and other electronic products

electromagnetic interference from certain electronics may cause product malfunction.

Place indoors away from direct sun light

direct exposure may cause product malfunction or failure.

Only place on hard, flat surfaces

flimsy or slanted surfaces may result in abnormal noise and vibrations.

This unit is not intended to be used to preserve documents or in art conservation.

English

NK105

360o All-in-One True HEPA Filter

➊ Pre-Filter ➋ True HEPA ➌ CD Carbon Filter

English

NK105

360o All-in-One True HEPA Filter ANATOMY

➊ Pre-Filter

➋ True HEPA

➌ CD Carbon Filter

➊ Pre-Filter designed to catch larger airborne particles

found indoors.

➋ True HEPA captures 99.97%* of airborne allergens

including; pollen, mold spores, dust, pet dander, microbes,

and smoke. *particles as small as 0.3 microns in size

➌ CD Carbon Filter reduces VOCs and household odors

from cooking, pets, and smoke.

• The 360o All-in-One True HEPA Filter is one unit and the

individual components of the filter cannot be purchased

separately.

Note

English

NK105

INSTALLING FILTERS

This product comes with all required filters. The protective plastic wrap

must be removed from the filter before use.

※ Operating the unit without removing the plastic wrap may result in

product failure.

※ Unplug and make sure the unit is turned off before installing filter.

③ Remove the 360

All-in-One True

HEPA filter from the unit. Remove the

plastic wrap from the filter.

• Operating the unit without removing

filters from plastic wrap may cause

abnormal noise, deformation, or fire as a

result of overheating.

① Remove the back panel by grasping

handle and pulling back, towards

yourself.

Latch

• Refer to pages 18 - 20 for details on how to replace filters.

Note

② Once the back panel is removed, grasp

the handle near the bottom of the unit,

and pull towards yourself to lower and

release the filter.
