Winmate W04FA3S-EHT1 Manuale utente

Please read these instructions carefully before using this product, and save this manual for future use

E-Series HMI

Ubuntu 16.04

W04FA3S-EHT1

W07FA3S-EHT1

W10FA3S-EHH2

W15FA3S-EHA2

Quick Start Guide

V1.0

For more information on this

and other Winmate products,

please visit our website at:

www.winmate.com

Document part number: 9152111I102O

- 2 -

CONTENTS

INTRODUCTION ...........................................................................- 8 -

Features - 8 -

Package Contents - 9 -

Product Overview - 10 -

GETTING STARTED...................................................................- 14 -

Turning On Your Device - 14 -

Connecting to Other Devices - 15 -

Turning Off Your Device - 19 -

OPERATING THE DEVICE.........................................................- 20 -

Start Menu - 20 -

Linux Terminal - 21 -

System Information - 22 -

Brightness Adjustment - 23 -

Ethernet Settings - 24 -

Changing Serial Port Settings - 27 -

Exit the System - 28 -

INSTALLATION ..........................................................................- 29 -

Wiring Requirements - 29 -

Mounting Solution - 30 -

SPECIFICATIONS.......................................................................- 32 -

Hardware Specifications - 32 -

APPENDIX ..................................................................................- 34 -

Appendix A: Cleaning the Monitor - 34 -

Appendix B: Winmate Software Development Kit - 35 -

Appendix C: Ubuntu Command Code - 36 -

- 3 -

FCC Statement

This device complies with part 15 FCC rules.

Operation is subject to the following two

conditions:

This device may not cause harmful

interference.

This device must accept any interference

received including interference that may cause

undesired operation.

This equipment has been tested and found to comply with the

limits for a class "B" digital device, pursuant to part 15 of the FCC

rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a

commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which

case the user will be required to correct the interference at him

own expense.

- 4 -

European Union

Electromagnetic Compatibility Directive

(2014/30/EU)

EN55024: 2010/ A1: 2015

oIEC61000-4-2: 2009

oIEC61000-4-3: 2006+A1: 2007+A2: 2010

oIEC61000-4-4: 2012

oIEC61000-4-5: 2014

oIEC61000-4-6: 2014

oIEC61000-4-8: 2010

oIEC61000-4-11: 2004

EN55032: 2012/AC:2013

EN61000-3-2:2014

EN61000-3-3:2013

Low Voltage Directive (2014/35/EU)

EN 60950-1:2006/A11:2009/A1:2010/A12:2011/

A2:2013

This equipment is in conformity with the requirement of the

following EU legislations and harmonized standards. Product also

complies with the Council directions.

- 5 -

No part of this document may be reproduced, copied, translated, or

transmitted in any form or by any means, electronic or mechanical,

for any purpose, without the prior written permission of the original

manufacturer.

Trademark Acknowledgement

Brand and product names are trademarks or registered trademarks

of their respective owners.

Disclaimer

Winmate Inc. reserve the right to make changes, without notice, to

any product, including circuits and/or software described or

contained in this manual in order to improve design and/or

performance. We assume no responsibility or liability for the use of

the described product(s) conveys no license or title under any patent,

representations or warranties that these products are free from

patent, copyright, or mask work right infringement, unless otherwise

specified. Applications that are described in this manual are for

illustration purposes only. We make no representation or guarantee

that such application will be suitable for the specified use without

further testing or modification.

Warranty

Winmate Inc. warranty guarantees that each of its products will be

free from material and workmanship defects for a period of one year

from the invoice date. If the customer discovers a defect, we will, at

his/her option, repair or replace the defective product at no charge to

the customer, provide it is returned during the warranty period of one

year, with transportation charges prepaid. The returned product must

be properly packaged in its original packaging to obtain warranty

service. If the serial number and the product shipping data differ by

over 30 days, the in-warranty service will be made according to the

shipping date. In the serial numbers the third and fourth two digits

give the year of manufacture, and the fifth digit means the month (e.

g., with A for October, B for November and C for December).

For example, the serial number 1W16Axxxxxxxx means October of

year 2016.

- 6 -

Customer Service

We provide a service guide for any problem by the following steps:

First, visit the website of our distributor to find the update information

about the product. Second, contact with your distributor, sales

representative, or our customer service center for technical support if

you need additional assistance.

You may need the following information ready before you call:

Product serial number

Software (OS, version, application software, etc.)

Description of complete problem

The exact wording of any error messages

In addition, free technical support is available from our engineers

every business day. We are always ready to give advice on

application requirements or specific information on the installation and

operation of any of our products.

- 7 -

Safety Information

WARNING! / AVERTISSEMENT!

Always completely disconnect the power cord from your

chassis whenever you work with the hardware. Do not

make connections while the power is on. Sensitive

electronic components can be damaged by sudden

power surges. Only experienced electronics personnel

should open the PC chassis.

Toujours débrancher le cordon d’alimentation du chassis

lorsque vous travaillez sur celui-ci. Ne pas brancher de

connections lorsque l’alimentation est présente. Des

composantes électroniques sensibles peuvent être

endommagées par des sauts d’alimentation. Seulement

du personnel expérimenté devrait ouvrir ces chassis.

CAUTION/ATTENTION

Always ground yourself to remove any static charge

before touching the CPU card. Modern electronic devices

are very sensitive to static electric charges. As a safety

precaution, use a grounding wrist strap at all times. Place

all electronic components in a static-dissipative surface

or static-shielded bag when they are not in the chassis.

Toujours verifier votre mise à la terre afin d’éliminer toute

charge statique avant de toucher la carte CPU. Les

équipements électroniques moderns sont très sensibles

aux décharges d’électricité statique. Toujours utiliser un

bracelet de mise à la terre comme précaution. Placer

toutes les composantes électroniques sur une surface

conçue pour dissiper les charge, ou dans un sac anti-

statique lorsqu’elles ne sont pas dans le chassis.

- 8 -

INTRODUCTION

Congratulations on purchasing Winmate® E-Series HMI. Winmate®

continues developing new generation of Human Machine Interfaces

for Industry 4.0 and Internet of Things (IoT). Our E-Series HMI runs

on Ubuntu operating system that allows installing the latest

applications (APPs). Thereby wide customization possibilities are

available to satisfy the needs of industrial automation.

There is one USB 2.0 onboard to connect mouse or keyboard, USB

OTG for system updates and micro SD card for data logging,

backup or data storage. System memory of 1 GB ensures stable

operation of applications.

With mounting clips for panel mounting there is no need to drill

holes in a fixture. This saves you the time for mounting and

guarantee aesthetic look of the wall after the unit gets removed.

Features

Winmate® E-Series HMI features:

Freescale® Cortex® A9 i.MX6 Dual Core 1 GHz

Projected Capacitive (P-CAP) Multi-Touch

Fanless cooling system and Ultra-low power consumption

Front IP65 water and dust proof, rear IP22

Power over Ethernet (Data and Power in a single cable)

Mounting clips for quick Installation

Elegant design for room booking, access control and room

information applications

Ubuntu 16.04 OS

- 9 -

Package Contents

Carefully remove the box and unpack your device. Please check if

all the items listed below are inside your package. If any of these

items are missing or damaged contact us immediately.

Standard factory shipment list:

HMI Device

Quick Start

Guide

(Hardcopy)

User Manual

& Driver CD

USB to Micro

USB Cable

Varies by product

specifications

Varies by product

specifications

Varies by product

specifications

9487049050K0

AC Adapter

(12V/ 50W)

Power Cord

2 pin

Terminal

Block

Mini USB to

UART Cable

(For Linux use)

922D050W12A

Varies by country

94J602G020K0

94E7053090K0

Mounting

Clips and

Screws

82111E240400

*Package content may vary based on your order.

- 10 -

Product Overview

E-Series HMI 4.3”

Unit: mm

№

Description

№

Description

①

USB OTG

④

Micro HDMI

②

USB 2.0

⑤

LAN/ Optional PoE

③

RS485

⑥

12V DC in (Power jack)
