Wiselazer S20 Manuale utente
WISELAZER SUPPORT
Technical Support support@wiselazer.com
Customer Service service@wiselazer.com
www.wiselazer.com S20 Online Help
S20 USER MANUAL
Please read this manual thoroughly before use and keep it handy for future reference.
v1.5
English
▲
01-09
Deutsch
▲
11-19
Français
▲
21-29
Español
▲
31-39
Italiano
▲
41-49
日本語
▲
51-59
English
▲
support@wiselazer.com
English
01
PACKING LIST
WARNING
Carrying Bag
Lens ClothHDMI CablePower Cable
Don't look straight into the light
from the projector lens.
Don't put projector in a damp, humid
environment to avoid electrocution.
S20 Remote
(Batteries Not Included)
User Manual
English
02
FUNCTION OVERVIEW
Air Outlet
Kickstand
Lens
HDMI
Mute
Left
Back
Volume -
USB Infrared Receiver
Power Button
Power Button
Fast Reverse
Menu
Fast Forward
Down
Up
HDMI Input Source
Right
Volume +
Keystone Correction
Play/Pause
Speaker
Audio Out
Power Input
Press to eject the kickstand
English
03
QUICK START
1. Please install the batteries
for the remote control.
2. Plug the power cord into an
outlet.
3. Take off the lens cover.
4. Press to eject the kickstand.
Rotate the lens to focus.
5. Place the projector on a flat
surface.
6. Press the Power Button to
turn on the projector.
Press the Power
Button twice to turn
off the projector.
English
04
KEYSTONE CORRECTION
INPUT SOURCE
Projection Mode
Manual keystone 18
Digital Zoom
MiraCast
Setting
FileManager HDMI
HummingBirdCast
iOS Mobile Mirror USB Connection
HDMI Connection
Android Mobile Mirror
English
05
LANGUAGE SETTING
WIFI CONNECTION
PROJECTION DISTANCE & SIZE
1. Select "Setting" on the projection image.
2. Select "Language Setting" on the projection image.
Setting
Language Setting
1. Select "Setting" on the projection image.
2. Select “WiFi Setting” on the projection image.
Setting
WiFi Setting
3. Wait for the projector to search for available networks.
4. Choose your network name and enter the password to connect.
4.27ft 6.56ft 9.84ft 16.4ft 22.3ft
(1.3m) (2m) (3m) (5m) (6.8m)
The recommended projection screen is around 100 inches with a distance of around 9.84ft.
Ambient darkness will improve the clarity of the projected images.
