Worldlawn PYTHON WYP72MX825EV5 Manuale utente

OPERATORS MANUAL

WYP72MX825EV5 WYP72MX825EV5RD

WYP72BSV37EV5 WYP72BSV37EV5RD

WYP72FX1000V5 WYP72FX1000V5RD

WORLDLAWN POWER EQUIPMENT, INC.

WORLDLAWNPOWEREQUIPMENT.COM

401 COMMERCE STREET

BEATRICE, NE 68310

800-267-4255

FAX –402-223-4103



4

Contents
AVAILABLE ACCESSORIES...............................................................................................................................7
SAFETY....................................................................................................................................................................8
SAFETY ALERT SYMBOL...........................................................................................................................................8
TRAINING................................................................................................................................................................8
PREPARATION.........................................................................................................................................................8
OPERATION.............................................................................................................................................................9
SLOPE OPERATION............................................................................................................................................... 11
USING THE ROLLOVER PROTECTION STRUCTURE............................................................................................... 11
MAINTENANCE AND STORAGE............................................................................................................................ 11
SAFETY AND INSTRUCTIONAL DECALS ................................................................................................................ 13
SPECIFICATIONS .............................................................................................................................................. 16
MODEL NUMBER ................................................................................................................................................. 16
WEIGHT & DIMENSIONS...................................................................................................................................... 16
FUEL SYSTEM ....................................................................................................................................................... 16
ELECTRICAL SYSTEM ............................................................................................................................................ 16
TRANSMISSION.................................................................................................................................................... 16
CUTTING DECK..................................................................................................................................................... 16
TIRES.................................................................................................................................................................... 16
OPERATION......................................................................................................................................................... 17
OPERATOR CONTROLS......................................................................................................................................... 17
STEERING AND MOTION CONTROL................................................................................................................. 17
SAFETY INTERLOCK .......................................................................................................................................... 17
CHOKE CONTROL............................................................................................................................................. 17
THROTTLE CONTROL........................................................................................................................................ 17
PARK BRAKE LEVER.......................................................................................................................................... 17
FUEL SHUT-OFF VALVE .................................................................................................................................... 18
IGNITION SWITCH............................................................................................................................................ 18
HOUR METER................................................................................................................................................... 18
DRIVE WHEEL RELEASE VALVES....................................................................................................................... 18
DECK LIFT SWITCH ........................................................................................................................................... 19
BLADE ENGAGEMENT SWITCH........................................................................................................................ 19
FULL SUSPENSION SEAT................................................................................................................................... 19



5

PRE-START.......................................................................................................................................................... 19
OPERATING INSTRUCTIONS......................................................................................................................... 20
RAISE THE ROLLOVER PROTECTION STRUCTURE (ROPS) ................................................................................ 20
STARTING THE ENGINE.................................................................................................................................... 20
BLADE ENGAGEMENT...................................................................................................................................... 20
DISENGAGING THE BLADES ............................................................................................................................. 20
STOPPING THE ENGINE.................................................................................................................................... 21
DRIVING THE MACHINE................................................................................................................................... 21
DRIVING FORWARD......................................................................................................................................... 21
DRIVING IN REVERSE ....................................................................................................................................... 22
ADJUSTING THE CUTTING HEIGHT .................................................................................................................. 22
ADJUSTING THE ANTI-SCALP ROLLERS ............................................................................................................ 22
TRANSPORTING ...................................................................................................................................................... 23
TRANSPORTING A UNIT................................................................................................................................... 23
LOADING A UNIT.............................................................................................................................................. 23
MAINTENANCE................................................................................................................................................... 24
RECOMMENDED MAINTENANCE SCHEDULE(S)................................................................................ 25
CHECK ENGINE OIL LEVEL ................................................................................................................................ 26
CHECK BATTERY CHARGE ................................................................................................................................ 26
RECOMMENDED JUMP-STARTING PROCEDURE ............................................................................................. 27
CHECK MOWER BLADES .................................................................................................................................. 28
CHECK SAFETY INTERLOCK SYSTEM................................................................................................................. 28
CHECK ROPS..................................................................................................................................................... 29
CHECK SEAT BELT............................................................................................................................................. 29
CHECK FOR LOOSE HARDWARE....................................................................................................................... 29
SERVICE AIR CLEANER...................................................................................................................................... 29
CHANGE ENGINE OIL ....................................................................................................................................... 29
CHANGE ENGINE OIL FILTER............................................................................................................................ 29
CHECK HYDRAULIC OIL LEVEL.......................................................................................................................... 30
CHECK TIRE PRESSURES................................................................................................................................... 30
CHECK CONDITION OF BELTS........................................................................................................................... 30
LUBRICATE GREASE FITTINGS.......................................................................................................................... 30
CASTER WHEEL ROTATION.............................................................................................................................. 30



6

CHECK SPARK PLUGS ....................................................................................................................................... 31
CHANGE HYDRAULIC SYSTEM FILTER AND FLUID............................................................................................ 31
HYDRAULIC SYSTEM AIR PURGE...................................................................................................................... 31
THREAD LOCKING ADHESIVES ......................................................................................................................... 32
COPPER-BASED ANTI-SEIZE.............................................................................................................................. 32
DIELECTRIC GREASE......................................................................................................................................... 32
CASTER PIVOT BEARINGS PRE-LOAD AND LUBRICATION................................................................................ 32
CHECK V-BELTS ................................................................................................................................................ 33
ADJUSTMENTS................................................................................................................................................... 34
DECK LIFT LIMIT SWITCHES.............................................................................................................................. 34
DECK LEVELING................................................................................................................................................ 35
PUMP DRIVE BELT TENSION ............................................................................................................................ 35
MOWER DECK DRIVE BELT TENSION............................................................................................................... 35
PARK BRAKE ADJUSTMENT.............................................................................................................................. 35
MOTION CONTROL LINKAGE ADJUSTMENT.................................................................................................... 36
NEUTRAL ADJUSTMENT................................................................................................................................... 37
MOTION CONTROL DAMPER ADJUSTMENT.................................................................................................... 37
MOTION CONTROL NEUTRAL LOCK PIVOT ADJUSTMENT............................................................................... 37
MOTION CONTROL HANDLE ADJUSTMENT..................................................................................................... 37
CLEAN ALL DEBRIS FROM ENGINE AND EXHAUST SYSTEM AREA. .................................................................. 38
CLEAN DUST AND DIRT FROM CYLINDER HEAD FINS...................................................................................... 38
CLEAN DEBRIS FROM MACHINE ...................................................................................................................... 38
CLEAN GRASS BUILD-UP UNDER DECK ............................................................................................................ 38
TROUBLESHOOTING........................................................................................................................................ 39
STORAGE ............................................................................................................................................................. 41
WINTER STORAGE............................................................................................................................................ 41
WIRING SCHEMATICS....................................................................................................................................... 42
WIRING SCHEMATICS....................................................................................................................................... 43
EVAPORATIVE EMISSION CONTROL WARRANTY STATEMENT .......................................................... 44
LIMITED WARRANTY......................................................................................................................................... 46


AVAILABLE ACCESSORIES

FITS MODELS:

WYP72MX825EV5

WYP72FX1000V5

MULCH KIT:

681010 72” MULCH KIT

SAFETY

SAFETY ALERT SYMBOL

This symbol means: ATTENTION! BECOME

ALERT! YOUR SAFETY IS INVOLVED!

The safety alert symbol appears above

information which alerts you to unsafe actions

or situations and will be followed by the word

DANGER, WARNING, or CAUTION.

DANGER: White lettering/Red

background.

Indicates an imminently hazardous situation

which, if not avoided, will result in death or

serious injury.

WARNING: Black letters on orange

background.

Indicates a potentially hazardous situation

which, if not avoided, could result in death or

serious injury.

CAUTION: Black letters on yellow

background.

Indicates a potentially hazardous situation

which, if not avoided, may result in minor or

moderate injury. It may also be used to alert

against unsafe practices

TRAINING

•Read the instructions carefully. Become

familiar with the safe operation of the

equipment, operator controls, and safety

signs.

•All operators need to be trained before

operating this unit.

•Never let children or untrained people

operate the equipment without proper

instruction.

•Keep everyone, especially children and pets,

away from the area of operation.

Remember that the operator or user is

responsible for accidents or hazards

occurring to other people or their property.

PREPARATION

•Evaluate the terrain to determine what

accessories and attachments are needed to

properly and safely perform the job. Use

only accessories and attachments approved

by WORLDLAWN

•The use of personal protective equipment,

such as (but not limited to) safety glasses,

hearing protection, substantial footwear and

long trousers is highly recommended.

CAUTION

This machine produces sound levels in

excess of 85 dBA at the operator’s ear and

can cause hearing loss through extended

periods of exposure.

Wear hearing protection when operating this

machine.

•Thoroughly inspect the area where the

equipment is to be used and remove all

stones, sticks, wires, bones, and other

foreign objects which may damage the

equipment or cause personal injury to

operator or bystanders.

•Check that the operator’s presence controls,

safety switches, and shields are attached

and functioning properly. Do Not operate

unless they function properly.

DANGER

In certain conditions gasoline is extremely

flammable and highly explosive.

A fire or explosion from gasoline can burn

you, others and cause property damage.

•Refuel outdoors, on level ground while

engine is cold.

•Never remove fuel cap or add fuel when

engine is running or when engine is hot.

•Never fill the fuel tank so that gasoline level

rises above the bottom of the filler neck to

allow for gasoline expansion and prevent

fuel spillage.

•If fuel is spilled, DO NOT attempt to start the

engine. Move away from the area of the

spill and avoid creating any source of

ignition until fuel vapors have dissipated.

•Do not smoke while refueling and stay away

from an open flame or where gasoline

fumes may be ignited by spark.

•Do not operate without entire exhaust

system in place and in proper working

condition.

•Do not place any equipment that is leaking

gasoline in an enclosed trailer.

•Be sure all fuel tanks and gasoline storage

containers have proper caps installed to

prevent spillage and minimize vapor

escaping into the trailer.

DANGER

In certain conditions during fueling, static

electricity can be released causing gasoline

vapors to ignite.

A fire or explosion from gasoline can burn

you, others, and cause property damage.

•Purchase and store gasoline only in an

approved container

•Always place gasoline containers on the

ground away from your vehicle while filling.

•Do not fill gasoline containers inside a

vehicle or on a truck or trailer bed because

interior carpets or plastic truck bed liners

may insulate the container and slow the loss

of any static charge.

•When practical, remove gas powered

equipment from the truck or trailer and

refuel the equipment with its wheels on the

ground.

•If this is not possible, then refuel such

equipment on a truck or trailer from a

portable container, rather than from a

gasoline dispenser nozzle.

•Before fueling, touch a metal surface to

minimize the risk of static discharge.

•If a gasoline dispenser nozzle must be used,

keep the nozzle in contact with rim of the

fuel tank or container opening at all times

until fueling is complete.

WARNING

Gasoline is harmful or fatal if swallowed.

Long-term exposure to vapors and failure to

use caution may cause serious injury or

illness.

•Avoid prolonged breathing of vapors.

•Keep face away from nozzle and gas

tank/container opening.

•Keep away from eyes and skin.

•Never siphon by mouth.

OPERATION

Although hazard control and accident

prevention are partially dependent upon the

design and configuration of the equipment,

these factors are also dependent upon the

awareness, concern and proper training of the

personnel involved in the operation, transport,

maintenance and the storage of the equipment.

It is essential that all Operator Safety

Mechanisms be connected and in operating

condition prior to use for mowing.

WARNING

Operating engine parts, especially the

muffler, become extremely hot. Severe

burns can occur on contact and debris,

such as leaves, grass, brush, etc. can catch

fire.

•Allow engine parts, especially the

muffler, to cool before touching.

•Remove accumulated debris from

muffler and engine area.

WARNING

Engine exhaust contains carbon monoxide,

which is an odorless deadly poison that can

kill you.

Do Not run engine indoors or in a small

confined area where dangerous carbon

monoxide fumes can collect.

•Operate only in daylight or good artificial

light, keeping away from holes and hidden

hazards.

•Be sure all drives are in neutral and parking

brake is engaged before starting engine.

•Never raise deck with blades running.

•Never operate the mower with damaged

guards, shields, or covers. Always have

safety shields, guards, switches and other

devices in place and in proper working

condition.

•Stop engine, wait for all moving parts to

stop and engage parking brake:

oBefore refueling

oBefore dumping the grass catcher

oBefore making height adjustments

•Park machine on level ground. Stop engine,

wait for all moving parts to stop, remove key

and engage parking brake:

oBefore checking, cleaning or working

on the mower.

oAfter striking a foreign object or

machine develops an abnormal

vibration (inspect machine for

damage and repair before resuming

operation)

oBefore clearing blockages

oBefore leaving the operator position

•Never mow with the discharge deflector

raised, removed or altered unless there is a

grass collection system or mulch kit in place

and working properly.

•Do Not change the engine governor setting

or overspeed the engine.

WARNING

Hands, feet, hair, clothing, or accessories

can become entangled in rotating parts.

Contact with rotating parts can cause

traumatic amputation or severe lacerations.

Do Not operate the machine without guards,

shields, and safety devices in place and

working properly.

Keep hands, feet, hair, jewelry, or clothing

away from rotating parts. Keep hands and

feet from under deck when PTO is engaged.

DO NOT operate the mower when people,

especially children, or pets are in the area

Never carry passengers.

•Stop the blades, slow down, and use

caution when transporting the mower to and

from the area to be mowed or crossing

surfaces other than grass.

•Do not operate the mower under the

influence of alcohol or drugs.

•Be alert, slow down and use caution when

making turns. Look behind and to the side

before changing directions.

•Use extreme care when loading and

unloading the machine into a trailer or truck.

•Be aware of the mower discharge path and

direct discharge away from others.

•Use care when approaching blind corners,

shrubs, trees, or other objects that may

obscure vision.

•Always wear eye protection when operating

machine.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Worldlawn Taglia erba

Worldlawn

Worldlawn Venom WYS32FS600VL Manuale utente

Worldlawn

Worldlawn DIAMONDBACK WYDB48FR691V32 Manuale utente

Worldlawn

Worldlawn WY28 series Manuale utente

Worldlawn

Worldlawn WYZ 48 Manuale utente

Worldlawn

Worldlawn WYZ 60 Manuale utente

Worldlawn

Worldlawn WY 48FS481V Manuale utente

Worldlawn

Worldlawn Encore EE48FR691V32 Manuale utente

Worldlawn

Worldlawn WY36FS481VH Manuale utente

Worldlawn

Worldlawn WY42 Manuale utente

Worldlawn

Worldlawn WY33N11BS Manuale utente

Worldlawn

Worldlawn WYZ 60 Manuale utente

Worldlawn

Worldlawn KING COBRA WYK52FX801V5 Manuale utente

Worldlawn

Worldlawn WYW36FS481VH Manuale utente

Worldlawn

Worldlawn Venom WYS48FX730VX Manuale utente

Worldlawn

Worldlawn WY28 series Manuale utente

Worldlawn

Worldlawn WY 36 Manuale utente

Worldlawn

Worldlawn Venom WYS48FX730VL Manuale utente

Worldlawn

Worldlawn WY33N11BS Manuale utente

Worldlawn

Worldlawn WY28T Manuale utente

Worldlawn

Worldlawn KINGCOBRA WYK52ECV7495CA Manuale utente

Worldlawn

Worldlawn WYRZ50 Manuale utente

Worldlawn

Worldlawn WY28X Manuale utente

Worldlawn

Worldlawn WY42 Manuale utente

Worldlawn

Worldlawn WY32 Manuale utente

Manuali Taglia erba popolari di altre marche

RHINO

RHINO 1958 Manuale utente

Wolf Garten

Wolf Garten Compact plus 40 B Manuale utente

Cub Cadet

Cub Cadet LTX 1045 Manuale utente

Craftsman

Craftsman 917.378461 Manuale utente

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuale utente

Challenge

Challenge CH18V2 Istruzioni operative

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuale utente

DEWEZE

DEWEZE ATM-725 Manuale operativo

Weed Eater

Weed Eater 180083 Manuale utente

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuale utente

Better Outdoor Products

Better Outdoor Products Quick Series Manuale utente

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuale operativo

MTD

MTD 795, 792, 791, 790 Manuale utente

Toro

Toro Groundsmaster 3505-D Manuale utente

Dennis

Dennis FT 610 Manuale utente

AIRFORCE

AIRFORCE F-15 Gen 3 Manuale utente

MTD

MTD 126-220-000 Manuale utente

Toro

Toro 74806 Manuale utente
