Worx WG650 Manuale utente
Snow Thrower EN
Souffleuse à neige F
Quitanieves
ES
P07
P16
P26
HELPLINE NUMBER
1-866-354-WORX (9679)
HELPLINE NUMBER
WG650
14
13
12
10
4
5
6
7
1
2
3
9
8
11
ii ii
i ii iii
c
da
e
ag
f
b
c
d
a
a
f
e
g
b
a
14
13
1
1
2
1
2
3
3
2
1
4
5
6
c
d a
b
e
15
10
12 12
10
a
A1 A2 B
C D E
F G H
I J K
L M1 M2
NO P
QR S
TU V
W X
Z2
Y
Z3Z1
AA
ii ii
i ii iii
c
da
e
ag
f
b
c
d
a
a
f
e
g
b
a
14
13
1
1
2
1
2
3
3
2
1
4
5
6
c
d a
b
e
15
10
12 12
10
a
A1 A2 B
C D E
F G H
I J K
L M1 M2
NO P
QR S
TU V
W X
Z2
Y
Z3Z1
AA
7
6
ii ii
i ii iii
c
da
e
ag
f
b
c
d
a
a
f
e
g
b
a
14
13
1
1
2
1
2
3
3
2
1
4
5
6
c
d a
b
e
15
10
12 12
10
a
A1 A2 B
C D E
F G H
I J K
L M1 M2
NO P
QR S
TU V
W X
Z2
Y
Z3Z1
AA
Snow Thrower EN
7
6
1. LOCK-OFF BUTTON
2. SWITCH LEVER
3. UPPER HANDLE
4. CHUTE DEFLECTOR
5. CHUTE DEFLECTOR KNOB
6. DISCHARGE CHUTE
7. AUGER
8. BELT COVER
9. LOCKING CAM LEVERS (WITH BOLTS AND WASHERS)
10. MIDDLE HANDLE
11. CHUTE CRANK BAR
12. CHUTE CRANK HANDLE
13. CABLE CLIP
14. POWER CORD HOOK
15. LOWER HANDLE (See Fig. A1)
Not all the accessories illustrated or described are included in standard delivery.
Snow Thrower EN
9
8
TECHNICAL DATA
Voltage 120V~60Hz
Power input 13A
No load speed 2200/min
Clearing width 18’’
Snow cut depth 10’’
Rotor style 4 Blades
Throw distance 30’
Machine weight 30 lbs
ACCESSORIES
Screwdriver 1
Spanner 1
Cable Clips 3
Locking Cam Levers 4
Only use the appropriate accessories intended for this tool. Accessory information can be found
on the product packaging, at a WORX dealer or on our website at www.worx.com
Snow Thrower EN
9
8
SAFETY INSTRUCTIONS
WARNING: Some dust created by
power sanding, sawing, grinding,
drilling and other construction activities
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
Some examples of these chemicals are:
1) Lead from lead-based paints.
2) Crystalline silica from bricks and cement
and other masonry products.
3) Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work.To reduce your exposure to these
chemicals:
• Work in a well-ventilated area.
• Work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
WARNING: Read all instructions
before using this appliance.
SAFETY INSTRUCTION
WARNING: Use the accessory
or attachment the manufacturer
recommended, Use of any other accessory
or attachment may increase the risk of injury.
DANGER!
Do not use hands to unclog chute. Stop motor
before removing debris. Do not walk in front
of running machine. Do not direct discharge at
bystanders.
CAUTION!
Use for snow removal only.
WARNING! To reduce the risk of electric
shock - replace damaged cord immediately.
To reduce the risk of injury, do not operate
without guards in place.
Double insulation - when servicing, use only
identical replacement parts.
A. FOR ALL DOUBLE-INSULATED SNOW
THROWERS
Replacement parts
When servicing use only identical replacement
parts. Replace or repair damaged cords.
B. FOR ALL SNOW THROWERS
1) Do not use on graveled surface unless
the SnowThrower is adjusted for such a
surface in accordance with the operator’s
manual.
2) Keep children away - All visitors should
be kept a safe distance from work area.
3) Dress properly -Do not wear loose
clothing or jewelry.They can be caught in
moving parts.
4) Wear rubber boots when operating the
SnowThrower.
5) Operation of the SnowThrower in the
hand-held position is unsafe, except in
accordance with the special instructions
for such use provided in the operator’s
manual.
6) Warning -To prevent electric shock use
only with an extension cord suitable for
outdoor use.
7) Extension Cords -To prevent
disconnection of SnowThrower cord from
the extension cord during operation.
i) Make a knot as shown in Figure 51.2, or
ii) Use one of the plug-receptacle
retaining straps or connectors described
in this manual.
Figure 51.2
Method of securing extension cord
(A)TIE CORD AS SHOWN
CORD
SET
APPLIANCE
CORD
(B) CONNECT PLUG AND RECEPTACLE
Snow Thrower EN
11
10
8) Avoid accidental starting -Don’t carry
plugged-in SnowThrower with finger
on switch. Be sure switch is off when
plugging in.
9) If cord is damaged in any manner while
plugged in, pull extension cord from wall
receptacle.
10) Don’t abuse cord -Never carry Snow
Thrower by cord or yank it to disconnect
from receptacle. Keep cord from heat, oil,
and sharp edges.
11) Keep hands away from moving parts.
12)
Keep guards in place and in working order.
13) Don’t force Snow Thrower - It will
perform better and safer at the rate for
which it was designed.
14) Don’t overreach - Keep proper footing
and balance at all times.
15) If the SnowThrower strikes a foreign
object follow these steps:
i) Stop SnowThrower. Release the switch.
ii) Inspect for damage.
iii) Repair any damage before restarting
and operating the SnowThrower.
iv) Unplug power cord.
16) Disconnect Snow Thrower -
Disconnect the appliance from the power
supply when not in use, before servicing,
when changing accessories such as
blades, and the like.
17) Store idle Snow Thrower Indoors -
When not in use, appliances should be
stored indoors in dry, and high or locked-
up place -out of reach of children.
18) Maintain Snow Thrower with Care
- Follow instructions for lubricating and
changing accessories.
SAFE OPERATION PRACTICES FOR
WALK-BEHIND SNOW THROWER
TRAINING
1. Read the operating and service instruction
manual carefully. Be thoroughly familiar
with the controls and the proper use of the
equipment. Know how to stop the unit and
disengage the controls quickly.
2. Never allow children to operate the
equipment. Never allow adults to operate
the equipment without proper instruction.
3. Keep the area of operation clear of all
persons, particularly small children, and pets.
4. Exercise caution to avoid slipping or falling,
especially when operating in reverse.
PREPARATION
1. Thoroughly inspect the area where the
equipment is to be used and remove all
doormats, sleds, boards, wires, and other
foreign objects.
2. Do not operate the equipment without
wearing adequate winter outer garments.
Wear footwear that will improve footing on
slippery surfaces.
3. Use extension cords and receptacles
as specified by the manufacturer for all
units with electric drive motors or electric
starting motors.
4. Adjust the collector housing height to clear
gravel or crushed rock surface.
5. Never attempt to make any adjustments
while the motor is running (except
when specifically recommended by
manufacturer).
6. Let motor and machine adjust to outdoor
temperatures before starting to clear snow.
7. Always wear safety glasses or eye shields
during operation or while performing an
adjustment or repair to protect eyes from
foreign objects that may be thrown from
the machine.
OPERATION
1. Do not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at all times.
2. Exercise extreme caution when operating
on or crossing gravel drives, walks, or
roads. Stay alert for hidden hazards or
traffic.
3. After striking a foreign object, stop the
motor, disconnect the cord on electric
motors, thoroughly inspect the Snow
Thrower for any damage, and repair the
damage before restarting and operating
the SnowThrower.
4. If the unit should start to vibrate
abnormally, stop the motor and check
immediately for the cause. Vibration is
generally a warning of trouble.
5. Stop the motor whenever you leave the
operating position, before unclogging the
auger housing or discharge guide, and
