User Manual

Item No. 9005 Ages: 14+

Contents Contents

Table of contents P. 1 - 2

Introduction P. 3

About Wowwee Alive™ Elvis® P. 4

Package contents P. 4

Technical specications P. 4

Battery details P. 5 - 6

Battery requirements P. 5

Elvis bust P. 5

Microphone remote controller P. 5

Installing and changing the batteries P. 5

AC/DC adaptor P. 7

Powering on/o P. 7

Sleep and reset P. 8

Sleep mode P. 8

Resetting Elvis P. 8

Contents

Remote controller overview P. 8 - 9

Elvis overview P. 9

Song and Monologue cartridge P. 10

Voice mode P. 11

Alive mode (Taking Care of Business™) P. 11

Song mode P. 11

Monologue mode P. 11

Sing Through mode (Share the Spotlight) P. 12 - 13

External music playback P. 14

Vision system P. 15

Taking Care of Elvis P. 16

Safety and warranty information P. 17 - 18

Safety tips P. 17

Warranty P. 17

Support P. 18

About Wowwee Alive™ Elvis®

Introduction

Dear Customer,

In 2005, Wowwee entered into a licensing

agreement with Elvis Presley Enterprises to

create the Wowwee Alive™ Elvis®, the rst

lifesize, completely realistic looking and

functioning bust of the world’s most loved

entertainer of all time.

Your animatronic Elvis consists of 10 precision

motors housed in an eciently designed

mechanical bust that conforms to the synthetic

skin likeness of Elvis!

More than two years of intense research and

development were dedicated to this project.

Initial sculptures were developed based upon

archival photo reference and lm footage from

Graceland. Forensic reconstruction techniques

were relied upon to assist in the creation

process. A total of 18 separate sculptures were

produced before a perfect recreation was

achieved.

Specially-developed motion-capture software,

in conjunction with a joystick system, was used

to nely tune the head and facial movements to

produce all the subtle motions that create a

believable Elvis.

We hope you will experience many enjoyable

and entertaining hours with the Wowwee Alive

Elvis.

With warm regards,

George York

Wowwee Ltd.

About Wowwee Alive™ Elvis®

About Wowwee Alive Elvis

Wowwee Alive Elvis is a lifelike singing and talking bust of the

best-selling solo artist in US history. Motion-captured facial animations

for amazing realism and expression utilizing Wowwee Alive

animatronics, and a leather-like jacket styled from the “Elvis Presley ’68

Comeback Special”, complete the most authentic recreation ever of this

legendary artist. Whether you’re his greatest fan or new to the man and

his music, you can listen to, sing along with, and learn more about the

life of the man they call“The King”.

Package contents

• 1x Alive Elvis

• 1x Microphone-shaped remote control

• 1x 9V AC/DC 2.7A adaptor

• This user manual

Technical specications

• Measurements: 20”L x 11.5”D x 18.5”H

(50.8cm L x 29.2cm D x 47.0cm H)

• Full-face animatronic design with realistic animated motions

• Infrared vision sensors

• High quality stereo system

• Audio line-in (line-in cable not included)

• 1/4 inch microphone jack plug (microphone not included)

• Memory card slot (for Song and Monologue cartridge, each sold

separately)

• DC power connector socket

Voice

Alive

Battery details

The following section describes the details concerning batteries for Elvis

and his remote controller.

NOTE: For best performance, use Elvis with the provided adaptor.

Battery requirements

Elvis bust

Elvis is powered by 8 x 1.5V ‘D’ size batteries (not included). We

recommend you use top-quality alkaline batteries.

Alternatively, Elvis can be powered by an Output 9V AC/DC 2.7A, center

positive adaptor (included).

Microphone remote controller

Your Elvis remote controller is powered by 3 x ‘AAA’ batteries (not

included).

Installing and changing the batteries

The following are steps to follow when installing or replacing the

batteries in Elvis and/or his remote controller.

NOTE: Before installing or changing batteries, make sure that Elvis and/or

his remote controller are turned o (switch is set to the OFF position).

1. Remove the battery compartment covers using a Phillips screwdriver

(not included).

2. Insert the batteries (not included) into the battery compartment of

Elvis and/or the remote controller, as illustrated in the diagrams.

IMPORTANT: Make sure you align the positive and negative polarities

of the batteries with corresponding markings inside the battery

compartment.

3. Replace the battery compartment covers and replace the screws.

When you notice Elvis slowing down or stopping any movement, you

might need to change the batteries in the body. Also, if you notice Elvis

not responding well to controller commands, you might need to replace

the batteries in the remote controller.

Battery details

Attention: important battery information

• Use only fresh batteries of the required size and recommended type.

• Do not mix old and new batteries, dierent types of batteries

(Standard (Carbon zinc), alkaline, or rechargeable), or rechargeable

batteries of dierent capacities.

• Remove rechargeable batteries from the Elvis unit and remote control

before recharging them.

• Rechargeable batteries are only to be charged under adult

supervision.

• Please respect the correct polarity, (+) and (-).

• Do not try to charge non-rechargeable batteries.

• Do not throw batteries into the re.

• Replace all batteries of the same type/brand at the same time.

• The supply terminals are not to be short-circuited.

• Remove exhausted batteries from the Elvis unit and remote control.

• Batteries should only be replaced by adults.

• Remove batteries if your Elvis is not going to be used for some time.

• Retain packaging as it contains important information.

“Bottom view of

Elvis bust”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

1.5V

LR20

UM1

“D”

AC/DC adaptor

Elvis can be powered by an output 9V AC/DC, 2.7 A, center positive

adaptor. You can use the adaptor included in this package.

NOTE: For best performance, always use the adaptor as the power

source for Elvis. Battery usage should be limited to the external

music playback function only.

IMPORTANT: Only use an adaptor of the recommended type.

To operate Elvis using an adaptor:

1. Set the power switch on the back of Elvis’ bust to OFF.

2. Open the rubber cover on the DC socket.

3. Insert the jack into the DC socket in the back of Elvis’ bust and plug the

adaptor into a power outlet.

4. Set the power switch on Elvis to the ON position.

Important safety notice

• Examine the AC/DC adaptor regularly for damage to the cord, plug,

enclosure and other parts, and, in the event of such damage the

product must not be used with the adaptor until the damage has

been repaired.

• The AC/DC adaptor is not a toy and should be operated by adults.

• If you wish to clean Elvis ensure that the power is disconnected rst.

Only clean with a damp cloth.

• Elvis may generate some abnormal motion or sound if you directly

change the power source (from batteries to adaptor and vice versa)

without turning the ON/ OFF switch to OFF rst. After changing the

power source, please turn the ON/ OFF switch to the ON position.

• Elvis is not intended for children under 14 years old.

Powering on/o

Elvis’power switch is located on his back, just below his neck, as

illustrated. To turn Elvis on, move the power switch from the OFF

position to the ON position. To turn him o, move the power switch to

the OFF position.

AC/DC adaptor / Powering on/off

DC IN 9V

CENTER POSITIVE

Sleep and reset

Sleep mode

When you leave Elvis unattended for around 10 minutes or more, he

will go into sleep mode, which means he will power down to conserve

energy. To wake him up, move the power switch to the OFF setting and

then ON again.

Resetting Elvis

You can reset Elvis to his default settings by performing a full reset. To

carry out a full reset, move Elvis’power switch to the OFF setting then

ON again.

Remote controller overview

The microphone-styled remote controller is based upon one of the many

microphones used by Elvis during the‘68 Comeback Special. You can use

the six (6) multi-function buttons and the slider on the remote controller

to activate and control various functions of your Elvis unit.

NOTE: The remote controller will work best at distances up to 6 feet

(approx. 2 meters) and closer. You should point the remote controller

towards the front of the bust for optimal response.

Sleep and reset / Remote controller overview

Voice mode button

Song / Monologue

mode button

Song / Monologue

selector button

Sing Through / Along

mix volume button

Play / Pause button

Alive mode button

Volume Control

knob

Remote controller overview / Elvis overview

Voice mode button

Toggle Elvis’ voice ON or OFF.

Alive Mode button

Elvis performs random sequences of animations (see P. 11).

Song / Monologue Mode button

Toggle between songs or monologues (see P. 11).

Play / Pause button

Start or pause a song or monologue.

Sing Through/Along mix volume button

Set your desired sing through/along mix volume setting using the mix

volume control (see p. 12 - 13).

NOTE: Do not press the center of the button.

Song / Monologue selector button

Use the song/monologue selector button to choose from the Elvis songs

and monologues on the Song and Monologue cartridge (see P. 11).

(sold separately).

NOTE: Do not press the center of the button.

Volume control knob

Use the volume control knob to adjust the main volume settings.

Elvis overview

- To mix Volume up press “+”.

- To mix Volume down press “-”.

- Forward direction

- Backward direction

Indice

Altri manuali WowWee Giocattolo

WowWee

WowWee ROBOROVER 8405 Manuale utente

WowWee

WowWee Jeobot Manuale utente

WowWee

WowWee RC Mini MiP Guida all'installazione

WowWee

WowWee MiP Manuale utente

WowWee

WowWee Lite Sprites Manuale utente

WowWee

WowWee RobotZombie Manuale utente

WowWee

WowWee Buttheads Manuale utente

WowWee

WowWee RoboMe Manuale utente

WowWee

WowWee BUTT HEADS LOUD & PROUD FART LAUNCHER 3000 Manuale utente

WowWee

WowWee RS FEMISAPIEN Manuale utente

WowWee

WowWee ROBORAPTOR 8095 Manuale utente

WowWee

WowWee NERF SUPER SOAKER ROBOBLASTER Manuale utente

WowWee

WowWee Untamed Fingerlings Manuale utente

WowWee

WowWee RS Media Manuale utente

WowWee

WowWee Mini Robosapien Manuale utente

WowWee

WowWee FINGERLINGS MONKEY BAR & SWING Manuale utente

WowWee

WowWee Chippies Manuale utente

WowWee

WowWee ArtSee Studio Manuale utente

WowWee

WowWee Minion MiP Turbo Dave 0868 Manuale utente

WowWee

WowWee MiP Manuale utente

WowWee

WowWee Chimpanzee Manuale utente

WowWee

WowWee Tri-bot Manuale utente

WowWee

WowWee FlyTech HOVERPOD REMOTE CONTROL HOVERCRAFT Manuale utente

WowWee

WowWee 0442 Manuale utente

Manuali Giocattolo popolari di altre marche

marklin

marklin 37321 Manuale utente

Canon

Canon PAPER CRAFT Manuale utente

GREAT PLANES

GREAT PLANES Pitts M-12S Manuale utente

NOCH

NOCH 14261 Manuale utente

Hausler

Hausler 450 SE V2 Manuale utente

Dynaflite

Dynaflite Daydream Manuale utente

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuale

Kenner

Kenner Batman 63651 Manuale utente

LEGO

LEGO 8527 Manuale utente

iKarus

iKarus ECO 8 Manuale utente

Multiplex

Multiplex EasyStar II Manuale di istruzioni

Walkera

Walkera 38 Manuale di istruzioni

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuale utente

MD MXION SWD Manuale utente

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuale utente

marklin

marklin 39671 Manuale utente

Meccano

Meccano 15103 Manuale utente

LEGO

LEGO TECHNIC 8735 Manuale utente
