April 2023 1 www.wtsensor.com
PCMPT01&PCMPT02&PCMPT03 Series
Economical Melt Pressure Transmitter
Features
■Signal output:4～20mA,0～10V,0～5V
■Accuracy grade:±1.0%F.S
■Special diaphragm coating
■IP65 ingress protection
■80% internal calibration
Applications
■Injection molding industry
■Chemical fiber industry
Notes:
1 Do not touch the diaphragm with hard
objects, which may cause damage to the
diaphragm.
2 Please read the Instruction Manual of the
product carefully before installation and
check the relevant information of the product.
3 Strictly follow the wiring method for wiring,
otherwise it may cause product damage or
other potential faults.
4 Misuse of the product may cause danger or
personal injury.
Product overview
PCMPT01&PCMPT02&PCMPT03 series economical melt
pressure transmitter series is specially designed for pressure
measurement at high temperature in the injection molding
industry, special diaphragm and highly anti-abrasive coating of
which enable it to work normally at high temperature up to
320℃.This series is installed in the manner of standard
threaded connection and has many advantages like high
stability and long service life.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference only.
Do not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information is
provided in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.
Refer to below pressure range form
