Xcruiser XDSR385HD Manuale utente
User’s Manual
XDSR385HD
Full HD Digital Satellite Receiver
Personal Video Recorder
•Please read this User’s Manual carefully before installing the receiver.
•This document is subject to update without perior notice.
•This document may be available in other languages. Please visit our
website: http://www.xcruiser.net
XDSR385HD
4
Index
INDEX ...................................................................................................4
Precautions.............................................................................................6
1. Important Safety Instructions ..........................................................6
2. Notice..............................................................................................6
3. Copyright ........................................................................................7
4. Disclaimer .......................................................................................7
5. Trademarks.....................................................................................7
Before You Begin ....................................................................................8
1. Main Features.................................................................................8
2. Accessories ....................................................................................9
Hardware Description...........................................................................10
1. .............................................................10
2. ............................................................. 11
3. Remote Control Unit .....................................................................12
Connecting diagram.............................................................................14
1. Receiver to Adaptor ......................................................................14
2. Receiver to TV with Digital A/V Output .........................................14
3. Receiver to TV with Analog A/V Output ........................................16
4. Connecting to Antenna Cable .......................................................16
5. Guide to mounting an STB on TV back panel (Optional)..............18
Guide of Functions ...............................................................................19
1. Selecting a Service .....................................................................19
1.1 Using CH UP/DOWN buttons ..............................................19
1.2 Using Service List ................................................................19
1.3 Using Simple Service List ....................................................19
XDSR385HD
5
1.4 Using Recent Service List....................................................20
2. Information Window ...................................................................20
3. Multi-Picture Display...................................................................20
4. Electronic Program Guide (EPG) ..............................................20
5. Favorite Group ............................................................................21
6. Volume Control ...........................................................................21
7. Pause ...........................................................................................21
8. Subtitle.........................................................................................22
9. Audio Control..............................................................................22
10. Teletext.........................................................................................23
11. PIP (Picture in Picture) ...............................................................23
PVR (Personal Video Recorder) Function ..............................................24
1. Recording ....................................................................................24
1.1 Recording methods..............................................................24
1.2 Recording Edit .....................................................................25
1.3 Long Time recording ............................................................26
1.4 Pause during recording........................................................26
2. Time Shifting ...............................................................................27
3. Playback (Play List) ....................................................................28
3.1 Recorded Files.....................................................................29
3.2 Imported Files ......................................................................29
3.3 Music....................................................................................29
3.4 Photo....................................................................................29
4. Bookmark ....................................................................................30
5. Trick mode...................................................................................30
Menu Map.............................................................................................31
Main Menu of Guide .............................................................................32
1. System Tools...............................................................................32
1.1 Storage Manager .................................................................32
1.2 Timer Settings......................................................................33
1.3 Service List Manager ...........................................................33
1.4 Data Transfer .......................................................................34
2. ..............................................................................35
2.1 Recording Option.................................................................36
2.2 Parental Control...................................................................37
2.3 Display Setting.....................................................................37
2.4 Time Setting.........................................................................38
2.5 Language Setting.................................................................38
2.6 A/V Output Setting ...............................................................39
3. Installation...................................................................................40
3.1 Dish Setting..........................................................................40
3.2 Positioner Setting.................................................................41
3.3 Service Search.....................................................................42
3.4 Network Setting....................................................................43
3.5 System Recovery.................................................................44
3.6 System Information..............................................................45
4. Utility............................................................................................44
4.1 Calculator.............................................................................44
4.2 Calendar ..............................................................................45
4.3 CAS (Conditional Access System).......................................45
4.4 Plugin...................................................................................46
4.5 Free TV+..............................................................................47
4.6 Internet TV+ .........................................................................48
Troubleshooting...................................................................................49
Specications .......................................................................................50
XDSR385HD
6
1. Important Safety
Instructions
wwRead these instructions.
wwKeep these instructions.
wwHeed all warnings.
wwFollow all instructions.
wwDo not use this apparatus near
water.
wwClean only with dry cloth.
wwDo not block any ventilation
openings. Install in accordance
with the manufacturer’s
instructions.
wwDo not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including ampliers)
that produce heat.
wwDo not reverse the safety purpose
of the polarized or grounding-
type plug. A polarized plug
has two blades with one wider
than the other. A grounding
type plug has two blades and
a third grounding prong. The
wide blade or third prong is
provided for your safety. If the
provided plug does not t into
your outlet, consult an electrician
for replacement of the obsolete
outlet.
wwProtect the power cord from
being walked on or pinched
particularly at plugs, convenience
receptacles, and the point where
they exit from the apparatus.
wwOnly use attachments/accessories
specied by the manufacturer.
wwUse only with the cart, stand,
tripod, bracket, or table specied
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
wwUnplug this apparatus during
lightning storms or when unused
for long periods of time.
wwRefer all servicing to qualied
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such
as power-supply cord or plug is
damaged, liquid has been spilled
or objects have fallen into the
apparatus, the apparatus has
been exposed to rain or moisture,
does not operate normally, or has
been dropped.
WARNING: To Prevent re or shock hazard
do not expose the set to rain or moisture.
2. Notice
wwThese servicing instructions
are for use by qualied service
personnel only. To reduce the
risk of electric shock, do not
perform any servicing other than
that contained in the operating
instructions unless you are
qualied to do so.
wwThe apparatus shall not be
exposed to dripping or splashing
and that no objects lled with
liquids, such as vases, shall be
placed on the apparatus.
wwThe mains plug is used
as the disconnect device. The
disconnect device shall remain
readily operable.
Precautions
XDSR385HD
7
To reduce the risk of electric shock, do not remove the cover (or back).
No user serviceable parts are inside.
Refer servicing to qualied service personnel.
The Lightning Flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to the presence
of un-insulated “dangerous voltage” within the product
enclosure that may be of sucient magnitude to constitute a
risk of shock to persons
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying
the product
3. Copyright
This manual is protected by copyright
laws.
Copy, use and reproduction of this
manual in part or whole without
Manufacturer’s prior written approval are
prohibited.
4. Disclaimer
The manufacturers, distributors and
agents are not liable to any kind of
damage caused by the use of the
information contained in this manual.
The instruction and descriptions which
this manual contains are based on the
time of this manual’s production.
The manufacturer constantly updates it
with new functions and technology.
All the specications are subject to
change without prior notice.
5. Trademarks
HDMI, the HDMI logo and High-
Denition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC
XDSR385HD
8
Before You Begin
1. Main Features
wwFull HD Satellite PVR receiver
wwHDMI Video & Audio Output (576i, 576p, 720p,
1080i, 1080p)
wwH.264/MPEG4 (HD/SD), DVB-S2 Compliant
wwRecording & Playback with External USB 2.0
Devices
wwRecording and Time Shifting Simultaneously
wwEvent Recording by EPG
wwUSB 2.0 Host ports (MP3 Player & JPEG Viewer)
wwVarious Media File Format Playback (Xvid le
Playback)
ww10/100 Base-Tx RJ-45 port
ww4-Digit Alphanumeric LED Display
wwFully compliant with DVB-S2
wwBlind scan
wwMulti-LNB Controlled by DiSEqC Control Version
1.0, 1.1, 1.2 and USALS
wwMulti-Satellite Search
wwSupport EPG (Electronic Program Guide)
wwOn-Screen Display with Full Color & Resolution
wwFavorite Service Groups
wwPowerful Service Control by Favorites, Lock, Skip,
Move and Delete
wwService Sorting by Alphabet, Transponder and CAS
wwMulti-language Supported (OSD & Menu)
wwTeletext Support
wwMaximum 10,000 Services Programmable
wwPIP (Picture in Picture)
wwParental Lock / System Lock / Installation Lock
wwCVBS Video & Audio Output via RCA
wwHDMI Video & Audio Output
wwOptical Output for Digital Audio (SPDIF)
wwSoftware & Service Database update via USB and
Ethernet port
XDSR385HD
9
2. Accessories
User’s Manual Remote Controller RCA cable (Option)
AAA size batteries X2 HDMI cable USB hub
Adaptor TV mount bracket (Optional) IR extension (Optional)
NOTE: If any accessories listed above are missing, contact the sales representative where you purchased this unit.
It is ready to be mounted behind of the TV. Use the screws provided to hold the components in place.
XDSR385HD
10
1. Front Panel Conguration
Hardware Description
1. Display :
The 4-digit shows channel number or menu state in
normal mode, shows local time in standby mode.
2. POWER Button:
Press to switch between STANDBY and POWER ON
modes.
3. CH Up/Down Button:
Press to change services in normal mode, to move
the highlighted-bar UP/DOWN in menu mode.
4. STANDBY / REMOTE Indication LED (RED / GREEN):
The LED (RED) lights on in standby mode. / The LED
(GREEN) lights on when a key on the Remote Control
is pressed.
5. Remote Sensor:
Receives signal from remote controller.
XDSR385HD
11
2. Rear Panel Conguration
1. IR extension : The 2.5mm mini plug is
connected to the “IR Rec” jack to use IR
extension when XDSR385HD is mounted
with optional bracket. (Front remote
sensor will not be operated when IR
Extension is connected)
2. PCMCIA : To receive other pay-tv service
you need a CA-Module(Viaccess, Irdeto,
Nagravison, etc.) and a smart card from
the service provider.
3. SMART CARD READER : Insert smart card for
encrypted service access.
4. LNB IN: Use to connect a satellite antenna.
5. LNB OUT: Use it when connecting to
another STB for loop-through.
6. RS-232C : Serial port for rmware update
and data transfer.
7. Ethernet : Local area network port for
direct computer connection.
8. USB : Use it when connecting to external
USB storage device.
9. HDMI : Connects to the TV by using a
HDMI cable for the best quality picture
and audio.
10. A/V OUT : Connects to the TV or VCR using
a optional RCA cable (Stereo audio
output / White, Red, Composite video
output / Yellow)
11. SPDIF : Connects to the audio system
using a S/PDIF cable. (digital audio)
12. D/C power socket : Connects the adaptor
XDSR385HD
12
3. Remote Control Unit 1. POWER: Turns the STB On/O.
2. MUTE / Resolution: Turns the sound On/O. / To select the
resolution format press and hold Resolution button. You will
see the resolution menu. Each time you press the Resolution
button, the resolution changes in the following sequence:
576i > 576p > 720p > 1080i > 1080p by pressing the Exit button it
turns the sound On/O again.
3. Numeric: Controls the numerical operation and service
numbers directly.
4. Subtitle: To show multilingual subtitle.
5. Teletext: To show the digital teletext.
6. OK or Service List: Show the service list in non-menu mode and
select an item or conrm in menu mode.
7. ARROW Buttons
a. Up & Down Buttons: To change the value of a selected item with
preprogrammed values in menu.
b. Left & Right Buttons: To move the cursor left and right in menu.
8. Menu: To enter the main menu or to move to the previous
menu.
9. EXIT: Exit from the menu or pop-up window.
10. Play List: To show the le list in the USB Storage Device or
Network Storage Device.
Indice
Altri manuali Xcruiser Ricevitore
