Xerox Document Centre 240 ST Istruzioni per l’uso

Page 1

OS/2 TCP/IP Peer-to-Peer Network Quick Install Card

Xerox Document Centre 240/255/265 LP/ST

c) The Touch Screen will be used for the

remainder of the data entry.

3. Enter the Network Setup menus.

a) Wait for the screen to refresh and

press the Connectivity and Network

Setup button.

b) Wait for the screen to refresh and

press the Network Setup button.

c) PresstheTCP/IPOptionsbutton.

4. Enable the network interface and protocol.

a) Press the TCP/IP Settings button.

b) Press the Protocol and Media button.

c) Press the Enable button, once

pressed the Physical Media buttons

will appear, select Ethernet or Token

Ring. Press Save to retain the

settings and continue.

5. Set the Broadcast Address.

a) Press the Broadcast Address button.

b) The broadcast address can be

calculated this way: Perform a logical

OR of the IP address and the

complement of the Subnet Mask.

Example of logical OR method:

IP Address = 13.175.109.146

Subnet Mask = 255.255.252.0

IP Address

00001101.10101111.01101101.10010010

Complement of Subnet Mask

00000000.00000000.00000011.11111111

The result

00001101.10101111.01101111.11111111

Broadcast Address = 13 . 175 . 111 . 255

Before You Start

If your printer is equipped with a Token Ring

interface, use the Token Ring Quick Install

Card supplied in this Quick Install Card set to

set the Ring Speed and Source Routing settings

for your environment.

Record the following information

IP Address ____________________________

Subnet Mask ___________________________

Default Gateway ________________________

You will compute your Broadcast Address as

part of this procedure.

Go to the printer and...

1. Connect your Document Centre to the

network with the appropriate cabling.

2. Enter the Tools pathway.

a) Press the Access ( )button.

b) On the keypad enter 1111 or the

current password. Press the Enter

button when finished. If your printer is

an ST model press the Go to Tools

button, otherwise skip to the next step.

For assistance, contact your local Xerox Customer Support Center:

USA: 1-800-821-2797 Canada: 1-800-939-3769

Page 2

OS/2 TCP/IP Peer-to-Peer Network Quick Install Card

Xerox Document Centre 240/255/265 LP/ST

b) One at a time press the soft buttons on

the Touch Screen for each octet of the

Subnet Mask and enter the numbers

from the keypad. Repeat this process

for the IP Gateway address. When

finished press Save to record the

changes and exit to the TCP/IP

Settings screen.

c) Press the TCP/IP - LP button. At the

next screen press Enable then press

Save.

d) Press the Exit Tools button.

8. Wait a MINIMUM of 7 minutes for the

printer to reset.

9. Fromthedocumentationpackagesupplied

with your printer, retrieve the CentreWare

Network Services CD-ROM (CD-ROM 2)

and the document entitled Getting

Started with Print and Fax Services.

Proceed to the next section of this

procedure called Go to a Workstation

and...

Go to a workstation and...

1. Create a new printer and load print drivers

from the CD-ROM.

2. Create a printer share and its access

permissions (sharing and connecting).

3. Start LPRPORTD/LPRMON, ping printer,

open EPM and send a print job to the

printer.

4. Check your test job for quality and use the

problem solving section of the Document

Centre 240/255/265 Reference Guide for

resolving print defects.

5. If your print job does not print, refer to the

troubleshooting section in the document

entitled Network Installation and

Troubleshooting Guide to correct the

problem.

6. Repeat this Go to a workstation and...

procedure at each workstation that will

print to this printer.

c) One at a time press the soft buttons

on the Touch Screen for each octet of

the broadcast address and enter the

numbers from the keypad. When

finished press the Save button on the

touch screen and you will be returned

to the TCP/IP Settings Screen.

6. Set the Host Name.

a) Press the Host Name and Address

button.

b) One at a time press the soft buttons on

the Touch Screen for each Octet of the

IP address and enter the numbers

from the keypad.

c) Press the Host Name button.

d) When the soft keypad appears, type

the host name EXACTLY as you want

it to appear with proper case. When

finished press the Save button to

record the changes and exit to the

TCP/IP Settings screen.

7. Set the Subnet Mask and Gateway

a) Press the Subnet and Gateway

button.
