Accessing Extended Features

Xerox 4127/4110

PDL Reference Guide for the

Xerox 4127/4112

October 16, 2007

Overview

This document enables you to access the extended features of the Xerox 4127/4112

and in environments that do not have a custom driver.

NOTE: Some of the commands and syntax used in this documents requires some

familiarity with either PostScript (PS) or Printer Command Language (PCL).

This document provides the Printer Description Language (PDL) commands and

syntax for each feature. The following items are also included:

・ A PostScript tables that describes the PostScript features the Xerox 4127/4110

supports and the syntax to use the feature.

・ A PCL tables that describes the PCL features the Xerox 4127/4110 supports and

the syntax to use the feature.

This document is not intended to be a complete PS or PCL reference manual:

It is a guide for using the PS and PCL commands with Xerox 4127/4110.

Refer to these additional reference materials PostScript Language Reference Manual,

Third Edition, ISBN 0-201-38922-8, PCL5 Printer Language Technical Reference

Manual, Hewlett-Packard Manual and Printer Job Language Technical Reference

Manual, Hewlett-Packard Manual.

Using this Guide

1. Search the Feature Table to determine whether the feature you wish to use is

supported.

2. Verify that the feature is supported by the platform. For example, the Xerox

4127/4110 must have the Finisher option installed to use stapling commands.

3. Following across the table to find the syntax listed for the PDL examples shown.

Read the Dependencies/Caveats section.

Page 1 Xerox 4127/4112 PDL Reference Guide

PostScript

This Xerox 4127/4110 supports PS3 commands that enable the features listed in the

following table.

Feature Description

Media Size This command specifies the size of media on which to

print the job.

Media Direction This command specifies the edge of the input medium

that will enter the printing engine or imager first and

across which data will be imaged. Values reflect

positions relative to a canonical page in portrait

orientation (width smaller than height):

Media Source This command specifies the tray to supply the job’s

media.

Media Source from

Bypass tray This command indicates whether the input medium is to

be fed from bypass tray.

Media Color Use this command to indicate the color of the media

used to print a job.

Media Weight Media weight. Unit: (g/㎡) gram per square-meter

Media Class Paper class (ex. normal, thick, recycled)

Media Type Media types are used to distinguish the type of media a

job requires.

Media Selection Specify if you apply the strict setpagedevice rule to

media selection.

Resolution This command sets the resolution value.

Duplex Delivers two-sided output. Landscape documents read

like a calendar, and Portrait documents read like a book.

Tumble Deliver two-sided output. (Use combine with Duplex)

Landscape documents read like a book and Portrait

documents read like a calendar.

Image Enhancement Specify whether you apply edge-smoothing to output

after rendering

Toner Save Use this command to control toner consumption when

printing.

Halftone Screen

Selection This command specifies the screen type.

Output Location Indicates the output bin where the print job is sent.

Copies The number of copies to produce, either of each page

individually or of the document as a whole, depending

on the value of the Collate parameter.

Collation A flag specifying how the output is to be organized when

multiple copies are requested for a multiple-page

Page 2 Xerox 4127/4112 PDL Reference Guide

Page 3 Xerox 4127/4112 PDL Reference Guide

Feature Description

document. Output consists of page sets that are

delivered together. If Collate is true, a page set consists

of one copy of all pages of the document; if it is false, a

page set consists of all copies of one page of the

document.

Offset This feature provides a physical offset of hard copy that

distinguishes between sets or stacks within a job.

Stapling This command indicates use and location of staple(s).

Punch This command indicates hole punches for a print job on

a device with hole punch capability.

Booklet This command enables you to print documents as small

booklets. If available on your printer, you can also have

your job folded or stapled.

Interleaving Paper

(Transparency

Separator)

Insert blank sheet between OHP sheets.

Process Color Model Select process color model (DeviceGray, DeviceRGB,

DeviceCMYK,,,)

Separations Specify whether multiple color separations are

generated for each page of output.

Separation Color

Names Specify the process colorant name.

Separation Order Specify the order of process colorant name.

Use CIE Color Specify if you apply CIE-based color space through

color conversion

Job Name

Job Type

(Secure Print / Proof

Print)

Job Based

Accounting

Auditron

Delay Print

Banner Sheet

These features are same as ‘PCL/PJL Implementation’.

Please refer the section to leverage the features.

PostScript Implementation

This section describes the PostScript commands required to access specific Xerox

4127/4110 features. This table lists each feature and the PostScript syntax that is

required to use the feature. Following this table are some examples of how to use

these commands and what the PostScript file looks like.

For more information about PostScript commands, refer to the PostScript Language

Reference Manual, Third Edition, and ISBN 0-201-37992-8.

PostScript Print Features/Implementation

* = default value

Feature Implementation Values

Media Size <</PageSize [width height]>>

setpagedevice

[width x height] in 1/72 inch(points)

[842 1191] = A3 (297 x 420mm) †

[595 842] = A4 (210 x 297mm)

[420 595] = A5 (148 x 210mm) †

[729 1032] = B4 (257 x 364mm)

[516 729] = B5 (182 x 257mm)

[792 1224] = Tabloid (11 x 17")

[612 1008] = Legal (8.5 x 14")

[612 936] = 8.5 x 13"

[612 792] = Letter (8.5 x 11")

[522 756] = Executive (7.25 x 10.5")

[396 612] = Statement (5.5 x 8.5") †

[576 720] = 8 x 10"

[641 879] = 226 x 310mm †

[879 1225] = 310 x 432mm

[864 1296] = Oversized Tabloid (12 x

18") †

[907 1274] = SRA3 (320 x 450mm) †

[907 1383] = 12.6 x 19.2" †

[936 1296] = 13 x 18" †

[936 1368] = 13 x 19" †

[553 765] = 16K (195 x 270mm) †

[550 757] = 16K (194 x 267mm) †

[765 1106] = 8K (270 x 390mm) †

[757 1100] = 8K (267 x 388mm) †

†: Whether each paper is available

depends on NV memory setting.

The following paper sizes are only

available with Bypass tray.

[297 420] = A6 (105 x 148mm)

[363 516] = B6 (128 x 182mm)

[792 1080] = 11 x 15"

[288 432] = Postcard (4 x 6")

[360 504] = 5 x 7"

[609 892] = 215 x 315mm

[632 842] = A4 Cover (223 x 297mm)

[648 792] = 9 x 11"

[283 420] = Postcard (100 x 148mm)

[420 567] = Postcard (148 x 200mm)

Page 4 Xerox 4127/4112 PDL Reference Guide

Page 5 Xerox 4127/4112 PDL Reference Guide

Feature Implementation Values

Media

Direction <</LeadingEdge int >>

setpagedevice Where int is one of the following:

0 = Short Edge; top of canonical page

1 = Long Edge; right side of canonical

page

2 = Short Edge; bottom of canonical page

3 = Long Edge; left side of canonical

page

null* = Auto

Media Source <</MediaPosition int>>

setpagedevice Where int is one of the following:

0 = Tray1

1 = Tray2

2 = Tray3

3 = Tray4

4 = Tray6

5 = Tray7

null* = Auto(The values with the asterisk

is the default value)

Media Source

from Bypass

tray

<</ManualFeed value>>

setpagedevice Where value is one of the following:

true = Feed paper from Bypass tray

false* = Feed paper from a tray other

than Bypass tray

Media Color <</MediaColor (string) >>

setpagedevice Where string is one of the following or null*:

white

blue

yellow

green

pink

ivory

gray

buff

goldenrod

red

orange

custom1 = Custom Color 1

custom2 = Custom Color 2

custom3 = Custom Color 3

custom4 = Custom Color 4

custom5 = Custom Color 5

transparent = Clear

other

Media Weight <</MediaWeight real >>

setpagedevice

Where real is in g/ ㎡(gram per

square-meter) or null*

(MediaWeight will not affect any tray

selection.)

Media Class <</MediaClass (string)>>

setpagedevice Where string is one of the following or null*:

stationary = Plain

stationary[S1] = Plain S1

Page 6 Xerox 4127/4112 PDL Reference Guide

Feature Implementation Values

stationary side2 = Plain Reload

used[S1] = Plain S1 Reload

recycled = Recycled

recycled[S1] = Recycled S1

thin = Lightweight (52 - 63g/m2)

thick1 = Heavyweight (HW) (106 -

216g/m2)

thick1[S1] = Heavyweight (HW) S1 (106 -

216g/m2)

thick2 = Extra HW (X-EW) (217 -

253g/m2)

thick2[S1] = Extra HW (X-EW) S1 (217 -

253g/m2)

transparency = Transparency

holed = Punched

label1 = Labels (106 - 216g/m2)

label2 = HW Labels (217 - 253g/m2)

tabbed thick1 = Tab Stock (106 -

216g/m2)

tabbed thick2 = HW Tab Stock (217 -

253g/m2)

coating1 = Gloss (64 - 105g/m2)

coating1[A] = Gloss A (106 - 135g/m2)

coating1[B] = Gloss B (136 - 216g/m2)

coating2 = HW Gloss (217 - 253g/m2)

user1 = Custom 1

user2 = Custom 2

user3 = Custom 3

user4 = Custom 4

user5 = Custom 5

Media Type <</MediaType (string)>>

setpagedevice Where string is any value or null*.

(MediaType will not affect any tray

selection.)

Media

Selection <</DeferredMediaSelection

value>>

setpagedevice

Where value is one of the following:

true* = Deferred media selection by

output device (more powerful and flexible

media selection)

false = Immediate media selection by

strict setpagedevice operator

To select the appropriate media when

using MediaClass / Staple / Punch feature,

value must be set to true intentionally in the

beginning of header.

Print Mode <</HWResolution [x y]>> Where x and y are one of the following:

Page 7 Xerox 4127/4112 PDL Reference Guide

Feature Implementation Values

setpagedevice [600 600]*(dpi)

[1200 1200]

Duplex <</Duplex value>>

setpagedevice

Where value is one of the following:

true = Duplex

false* = Simplex

Tumble <</Tumble value>>

setpagedevice This feature is effective only in conjunction

with that Duplex is true

Where value is one of the following:

true = Tumble (Short edge binding

Duplex)

false* = Duplex (Long edge binding

Duplex)


Enhancement <</PostRenderingEnhance true

/PostRenderingEnhanceDetails

<< /Type 32 /REValue int >>

setpagedevice

Where int is one of the following:

0 = No image enhancement

1* = Activate image enhancement

Toner Save <</PostRenderingEnhance true

/PostRenderingEnhanceDetails

<< /Type 32 /TonerSaver int >>

setpagedevice

Where int is one of the following:

0* = No toner saving

1 = Lighten output density, toner saving

Halftone

Screen

Selection

<</PostRenderingEnhance true

/PostRenderingEnhanceDetails

<< /Type 32 /EngineScreen int >>

setpagedevice

Where int is one of the following:

0 = Low frequency screen

1* = High frequency screen

2 = Compatible screen with FX standard

PDL’s(Low frequency)

3 = Compatible screen with FX standard

PDL’s(High frequency)

Output

Location <</OutputType (string)>>

setpagedevice Where string is one of the following or null*:

FINISHER TOP TRAY = finisher top tray

(w/ D-Finisher)

FINISHER TRAY = finisher tray (w/

D-Finisher)

FOLDER TRAY = folder tray (w/

D-Finisher and folder module)

BOOKLET TRAY = booklet tray (w/

D-Finisher and booklet module)

HCS1 TOP TRAY = hcs top tray (w/

HCS)

HCS1 TRAY = hcs tray (w/ HCS)

BOOKLET TRAY = booklet tray (w/

C-Finisher and booklet module)

null* = Not specified

Page 8 Xerox 4127/4112 PDL Reference Guide

Feature Implementation Values

Quantity <</NumCopies value >>

setpagedevice

Where value is one of the following:

integer from 1 to 9999 : number of copies

null*: Not specified

Collation <</Collate value >>

setpagedevice Where value is one of the following:

true = collated

false* = uncollated

Offset <</Jog int >>setpagedevice Where int is one of the following:

0* = Do not offset

3 = Offset at the beginning of each page

[set]

Stapling

(w/

D-Finisher)

<</Staple int1

/StapleDetails << /Type 7

/Location int2 >>

setpagedevice

Where int1 is one of the following:

0* = Do not staple

3 = Staple at the end of each set

Where int2 is one of the following:

0* = top-left-single

1 = bottom-left-single

2 = top-right-single

3 = bottom-right-single

4 = top-double

5 = bottom-double

6 = left-double

7 = right-double

Punch

(w/

D-Finisher)

<</Punch int1

/PunchDetails << /Type 5

/Position int2

/Numholes int3 >>

setpagedevice

Where int1 is one of the following:

0* = Do not punch

3 = Do punch by set unit.

Where int2 is one of the following:

0 = topside

1 = bottom side

2 = left side

3 = right side

Where int3 is one of the following:

2 = 2 holes

3 = 3 holes

4 = 4 holes

Fold

(w/ D-Finisher

and folding

module)

<</Fold int1

/FoldDetails << /Type 6

/FoldType int2

/ImageRotation int3

/PrintInside value4 >>

setpagedevice

Where int1 is one of the following:

0* = Do not fold.

4 = Fold every page..

Where int2 is one of the following:

0* = Z Fold Half Sheets.

1 = Z Tri-Fold Single Sheets.

2 = C Tri-Fold Single Sheets.

Where int3 is one of the following:

0* = Do not rotate image.

1 = Roate image 180 degrees.

This feature is effective only in

Page 9 Xerox 4127/4112 PDL Reference Guide

Feature Implementation Values

conjunction with that FoldType is 0.

Where value4 is one of the following:

true* = Print on inside.

false = Print on outside.

This feature is effective only in

conjunction with that FoldType is 1 or 2.

Booklet

(w/ D-Finisher

and booklet

module)

<</Booklet value1

/BookletDetails << /Type 3

/StapleType int

/PrintInside value2

/PageSet value3>>

setpagedevice

Where value1 is one of the following:

true = Do Booklet.

false* = Do not Booklet.

Where int is one of the following:

0* = Do not file on inside.

1 = File on inside.

Where value2 is one of the following:

true* = Print on inside.

false = Print on outside.

This feature is effective only in conjunction

with that StapleType is 0.

Where value3 is one of the following:

true = Integrate several page and folds.

false = Fold every page.

This feature is effective only in conjunction

with that StapleType is 0.

Interleaving

Paper

(Transparency

Separator)

<</SlipSheet int1

/SlipSheetDetails << /Type 1

/AutoTraySelect int2

/SheetTray int3

/MediaClass (string) >>

setpagedevice

Where int1 is one of the following:

0* = Do not deliver interleaving paper.

4 = Deliver interleaving paper at the end

of each page

Where int2 is one of the following:

0 = SheetTray is referred and feed

interleaving paper from the SheetTray

1* = Feed interleaving paper from a tray

following system setting. SheetTray is not

referred.

Where int3 is one of the following:

0* = Feed interleaving paper from Tray1

1 = Tray2

2 = Tray3

3 = Tray4

4 = Tray6

5 = Tray7

100 = Bypass tray

Where string is same as the “Media Class”

feature. It means media class for the

interleaving paper.

Page 10 Xerox 4127/4112 PDL Reference Guide

Feature Implementation Values

Process Color

Model <</ProcessColorModel name >>

setpagedevice

Where name is one of the following:

/DeviceGray

/DeviceRGB (with Separations true)

/DeviceCMYK (with Separations true)

/DeviceCMY (with Separations true)

/DeviceRGBK (with Separations true)

Separations <</Separations value >>

setpagedevice Where value is one of the following:

true = Multiple color separations will be

generated for each page of output.

false* = All colorants will be combined into a

single composite page on a single sheet of

physical medium.

Separation

Color Names <</SeparationColorNames

value>>

setpagedevice

Where value is an array.

Legal element values are the process

colorant names implied by the process

color model.

Valid colorant names for each process

color model are like the following in case of

separation

DeviceCMYK = Cyan, Magenta, Yellow,

Black

DeviceCMY = Cyan, Magenta, Yellow

DeviceRGB = Red, Green, Blue

DeviceRGBK = Red, Green, Blue, Gray

DeviceGray = Gray

Separation

Order <</SeparationOrder value>>

setpagedevice

Where value is an array.

Legal element values are the process

colorant names implied by the process color

model.

Use CIE Color <</UseCIEColor value>>

setpagedevice

Where value is one of the following:

true = Re-map each color from device

color space to device independent’s CIE-

based color space

false* = Do not re-map color

Altri manuali per Legacy 4112

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Xerox Stampante tutto in uno

Xerox

Xerox WORK CENTRE 7525 Manuale utente

Xerox

Xerox WorkCentre Pro 580 Manuale utente

Xerox

Xerox M20 - WorkCentre B/W Laser Manuale utente

Xerox

Xerox WorkCentre Pro 423 Manuale utente

Xerox

Xerox WorkCenter 7132 Manuale operativo

Xerox

Xerox 610E35560 Manuale utente

Xerox

Xerox WorkCentre WC7530 Manuale utente

Xerox

Xerox 3210 - workcentre b/w laser Manuale di istruzioni

Xerox

Xerox WorkCentre 6505 Manuale operativo

Xerox

Xerox B205 Manuale operativo

Xerox

Xerox DocuColor 242 Manuale operativo

Xerox

Xerox Phaser 6115 MFP Manuale utente

Xerox

Xerox Versant 180 Press Manuale utente

Xerox

Xerox WorkCentre 6027 Manuale operativo

Xerox

Xerox DocuColor 240 Manuale di installazione e funzionamento

Xerox

Xerox CopyCentre C2128 Manuale di istruzioni

Xerox

Xerox VersaLink C405/N Manuale utente

Xerox

Xerox Phaser 6180MFP Manuale operativo

Xerox

Xerox WorkCentre 3119 Manuale utente

Xerox

Xerox Phaser 6128 MFP Manuale utente

Xerox

Xerox WORKCENTRE 7755 Manuale utente

Xerox

Xerox ColorQube 8700 Manuale operativo

Xerox

Xerox Document Centre Series Manuale utente

Xerox

Xerox WorkCentre 7300 Series Manuale di servizio

Manuali Stampante tutto in uno popolari di altre marche

Triumph Adler

Triumph Adler DC 2016 Manuale

Epson

Epson WorkForce WF-2510 Guida utente

Epson

Epson Stylus Scan 2000 Manuale di installazione e funzionamento

Epson

Epson PictureMate Snap PM 240 Manuale di istruzioni

Konica Minolta

Konica Minolta bizhub C35 Manuale utente

Brother

Brother MFC-J430w Manuale utente

Konica Minolta

Konica Minolta BIZHUB 558 Manuale utente

Lexmark

Lexmark MX710 Series Manuale

Brother

Brother MFC-9760 Manuale utente

Lexmark

Lexmark XC8155 Manuale utente

Lexmark

Lexmark X642E Manuale utente

Sharp

Sharp MX-2310U Guida

Aficio

Aficio 200 Manuale utente

Canon

Canon ImageCLASS 2300 Manuale

Ricoh

Ricoh Pro C900 Manuale utente

Lexmark

Lexmark X925 Manuale utente

Brother

Brother Business Smart MFC-J4510dw Manuale utente

Epson

Epson Stylus CX8400 Series Manuale utente
