Xerox WorkCentre 3655i Manuale
Wi-Fi Direct Enablement
Setup Instructions
Activation de Wi-Fi Direct
Instructions d'installation
1
Enabling Wi-Fi Direct Printing
Wi-Fi Direct, peer to peer connection for mobile clients, can be enabled on the following Xerox®products with a Wireless
Network Adapter Kit.
• Xerox®WorkCentre®3655i/6655i
• Xerox®WorkCentre 5865i/5875i/5890i
• Xerox®WorkCentre 5945i/5955i
• Xerox®WorkCentre 7220i/7225i
• Xerox®WorkCentre 7830i/7835i/7845i/7855i/7970i
Requirements:
• A wired-networked Multifunctional Printer with access to the Xerox®CentreWare®Internet Services
• USB dongle from the Wireless Adapter Kit
• Android mobile smartphone or tablet (Android™ 4.4 or later).
• Xerox® device software level of 073.xxx.xxx.34540 or newer
• Mopria Alliance Print Plug-in
Verifying the Software Level on a Xerox®Printer
At the control panel, press the Machine Status button.
073.xxx.xxx.xxxxx
1
2
Installing the USB Adapter
1. Retrieve the USB adapter from the kit. Store the remaining components in the kit for future use.
Xerox®Wi-Fi Direct Enablement – Setup Instructions
2
2. Power off the Xerox®WorkCentre.
At the rear of the Xerox®WorkCentre printer, insert the adapter into the USB slot.
Note: Do not use the USB port on the front or the machine.
WorkCentre 7220i/7225i WorkCentre 78xxi Series and 7970i WorkCentre 58xxi Series and 59xxi Series WorkCentre 3655i/6655i
3. Power on the Xerox®WorkCentre.
Enabling the USB Network Interface Adapter for Wi-Fi Direct
1. Determine the IP address of the printer. At the printer control panel, press the Machine Status button. On the Machine
Information tab, find the IPv4 Address of the printer.
1
2
Note the IP Address for later use (xxx.xxx.xxx.xxx): ___.___.___.___
2. At your networked computer, open a web browser. In the address field, type the IP address of the printer, then press
Enter or Return. The Xerox®CentreWare®Internet Services web interface opens.
Note: For enhanced security, the Xerox®device web page is redirected using https. When https is first used, many web
browsers alert you to a potential security issue. You can proceed to the web page and ignore the alert messages.
• In Internet Explorer, you may see this message:
To proceed to the website, click Continue to this website.
Xerox®Wi-Fi Direct Enablement – Setup Instructions
3
• In Google Chrome, you may see this message:
To proceed to the website, click Proceed anyway.
• In Mozilla Firefox, you may see this message:
To proceed to the website, click I understand the risks.
• In Apple Safari, you may see this message:
Click Continue to proceed to the website.
3. In the top-right area of the page, click Login.
4. Log in using the system administrator account. The default system administrator account is
User ID: admin
Default password: 1111
5. Click Login.
6. Ensure that the device is not in sleep mode. To exit sleep mode, touch the control panel.
7. In CentreWare Internet Services, click Properties > Connectivity > Setup.
8. Next to Wi-Fi Direct, click Edit.
Note: the Edit button is available after you install the USB wireless network adapter.
Xerox®Wi-Fi Direct Enablement – Setup Instructions
4
9. You can change the Device Name in the Convenience Link section. To accept the default name or proceed to the next
step to make a change, click Close.
10. To change the Device Name, click Edit.
11. Enter the desired information. Enter the device name, then click Apply.
12. Confirm the Device Name set in the previous step. To return to the Connectivity window, click Close.
1
2
Xerox®®Wi-Fi Direct Enablement – Setup Instructions
5
13. On the Connectivity page:
a. Confirm that Wi-Fi Direct is enabled.
b. On the HTTP row, click Edit.
1
2
14. Check No in Force Traffic over Secure Connection (HTTPS), then click Save.
1
2
15. Log out of CentreWare Internet Services.
CentreWare
®
Internet Services
Xerox®Wi-Fi Direct Enablement – Setup Instructions
6
16. At the Xerox®printer control panel, press the Machine Status button. On the Machine Information tab, confirm that you
see the Wi-Fi Protected Setup (WPS).
Note the name for later use _________________.
1
2
Preparing the Smart Device
One-Time Android Prerequisites
• Android smartphone or tablet (Android 4.4 or later)
• Mopria Alliance Print Plug-In installed from Play Store apps:
1. On your smartphone, access the online Google Play store.
2. Search for Mopria Print Service.
3. Touch the Mopria Print Service app.
4. Touch Install.
5. After the installation is complete, go to Settings and touch Printing.
6. Turn on Mopria Print Service.
• Wi-Fi and Wi-fi Direct settings enabled
You can now send print jobs from the mobile device.
1. On the smartphone or tablet, touch your Mopria-certified mobile app.
Note: Not all mobile apps are Mopria-certified.
2. Touch the desired image to print.
3. Open the Apps menu and touch Print.
4. Wi-Fi Direct automatically lists the eligible Xerox®multifunction printers, such as WC 7835 XYZ. Touch the Xerox® device
name.
5. At the Xerox®device control panel, touch OK to connect.
6. On your smart device, touch the print icon to select settings and submit the print job.
Xerox®Wi-Fi Direct Enablement – Setup Instructions
Activation de Wi-Fi Direct
Instructions d'installation
