Xerox®Common Access Card

Installation Guide

Xerox®WorkCentre 4250/4260

of this publication may not be reproduced in any form without permission of Xerox Corporation.

XEROX® and XEROX and Design® are trademarks of Xerox Corporation in the United States and/or other countries.

Changes are periodically made to this document. Changes, technical inaccuracies, and typographic errors will be corrected in

subsequent editions.

Document version 1.0: July 2011

Xerox Common Access Card

Common Access Card Installation Guide

Table of Contents

1Introduction

Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Card Readers and Card Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Supported Card Readers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Documentation and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

2Preparation

Server Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

3Installation

Software Enablement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Configuring Common Access Card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Hardware Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using Common Access Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

4 Troubleshooting

Fault Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Locating the Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Troubleshooting Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

During Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

After Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

A Retrieving the Certificate from a Domain Controller or OCSP Server

B Determining the Domain in which your Card is Registered

Xerox Common Access Card

Common Access Card Installation Guide

Xerox Common Access Card

Common Access Card Installation Guide

Introduction

The Common Access Card solution brings an advanced level of security to sensitive information.

Organizations can restrict access to the walk-up features of a Xerox device. This ensures only

authorized users are able to copy, scan, e-mail and fax information.

The key benefit of this solution is its two-factor identification requirement. Users must insert their

access card and enter a unique Personal Identification Number (PIN) at the device. This provides

added security in the event that a card is lost or stolen.

Once validated, a user is logged into the Xerox device for all walk-up features. The system allows for

functions to be tracked for an added layer of security.

The Common Access Card enablement kit integrates with Xerox multifunction printers and existing

smart and personal identity verification cards and readers.

This guide explains how to install and configure the Common Access Card solution. It identifies the

resources and equipment required to complete a successful installation.

Should you require any further information, please contact your Local Xerox Representative.

Introduction

Xerox Common Access Card

Common Access Card Installation Guide

Compatibility

This solution is compatible with the following product and configurations:

• To identify the software level on your machine, press the Machine Status button on the control

panel.

•TheSystem Software Version number is displayed.

Configuration Software Level

Xerox WorkCentre 4250 15.004.02.000

Xerox WorkCentre 4260 30.104.08.000

Introduction

Xerox Common Access Card

Common Access Card Installation Guide

Card Readers and Card Types

Supported Card Readers

The customer is responsible for providing a card reader for each Xerox device. The following card

readers are compatible with the solution:

• Gemalto TOP DL GX4 144K V2.6.2b Applets

• Oberthur ID-One Cosmo v5.2 128K V2.6.2 Applets

• Oberthur ID-One Cosmo v5.2 72K V2.6.1 Applets

• Oberthur ID-One Cosmo v5.2D 72K V2.6.1 Applets

• Oberthur ID-One Cosmo v5.2 72K V2.6.2 Applets

• Gemalto GemCombiXpresso R4 dual interface 72K V2.6.2 Applets

• Axalto Access 64KV1

• Gemplus GXP3 64V2N V2.6.1 Applets

• Gemalto Cyberflex Access V2C 64K V2.6.1 Applets

• Oberthur ID-One Cosmo V5.2D 64K

• Oberthur OCS Galactic V1 32K V1 Applets

• Oberthur Cosmo V4 32K V1 Applets

• Schlumberger / Axalto Cyberflex V2 32K V1 Applets

Other card types and CCID compliant readers may function with the solution, but have not been

validated.

Additional information from your System Administrator may be required to validate which card reader

works best in your environment.

Note: Information about CCID compliant card types can be obtained from various websites, for

example www.pcsclite.alioth.debian.org/ccid.This site is not a Xerox website and is not endorsed

by Xerox.

Introduction

Xerox Common Access Card

Common Access Card Installation Guide

Documentation and Support

For information specifically about your Xerox product, the following resources are available:

•System Administrator Guide provides detailed instructions and information about connecting

your device to the network and installing optional features. This guide is intended for

System/Machine Administrators.

•User Guide provides detailed information about all the features and functions on the device. This

guide is intended for general users.

Most answers to your questions will be provided by the support documentation supplied on disc with

your product. Alternatively you can contact the Xerox Support Center or access the Xerox website at

www.xerox.com.

Xerox Common Access Card

Common Access Card Installation Guide

Preparation

This section explains the preparation and resources required to install the Common Access Card

software.

The installation will take approximately one hour for each device. The following items are required in

order to complete the installation:

Item Supplier

Compatible Card Readers and Access Cards (refer to Card Readers and

Card Types on page 7)

Customer

Common Access Card Enablement Kit 497K09950 (one required for

each Xerox device)

Xerox

Feature Enable Key Xerox

TCP/IP enabled on the device Customer

DNS Host name or static IP address assigned Customer

Network Settings to be checked to ensure network is fully functional Customer

Domain Controller (DC) information:

• Domain Controller authentication environment

• lP address or Host Name

• Domain information

• Domain Controller Root certificates

• Check that all certificates are in 64 bit X.509 format

Customer

Online Certificate Status Protocol (OCSP) Server Information:

•OCSPServerURL

• OCSP - Root and Intermediate Certificates

• Check that all certificates are in 64 bit X.509 format

Customer

Proxy Server configuration details Customer

Preparation

Xerox Common Access Card

Common Access Card Installation Guide

The method to validate the Domain certificate requires installation of the certificate chain including

the Root certificate on to the Xerox device. The Xerox WorkCentre may be configured to validate all

certificates via OCSP (Online Certificate Status Protocol Responder). It submits the Domain Certificate

and any associated Intermediary Certificates to the OCSP Responder, to verify that these certificates

are valid and not revoked. The WorkCentre then receives a response from the OCSP responder stating

whether these certificates are valid.

Note: Certificates are often obtained from the Information Technology professionals that support

your organization. The certificate chain consists of all Intermediate Certificates up to and

including the Root Certificate. If you are unable to obtain the required certificates, refer to the

process outlined in Appendix A. You can determine the domain that you are registered in using the

process outlined in Appendix B.

Server Specifications

Prior to installation, ensure your network infrastructure supports Common Access Card or Personal

Identification Verification (PIV).

Names or IP addresses of all servers and domains are required during setup.

Electrical Requirements

The USB port on the back of the Xerox device network controller provides the power required for any of

the supported card readers.
