Phaser® 6250 Color Laser Printer

2-26

2-Sided Printing

This topic includes:

■"Automatic 2-Sided Printing" on page 2-26

■"Binding Preferences" on page 2-27

■"Manual 2-Sided Printing" on page 2-29

■"Manual 2-Sided Printing Using Tray 1 (MPT)" on page 2-30

Automatic 2-Sided Printing

Your printer must be a 6250DP, 6250DT, or 6250DX to perform automatic 2-sided printing.

Guidelines

To print a 2-sided document, verify that you are using the following weight ranges:

Caution

DO NOT use any specialty media, envelopes, or labels for automatic 2-sided printing.

Damage caused by automatically printing specialty media using the duplex unit is not

covered under the Xerox warranty, service agreement, or Total Satisfaction Guarantee.

For best results with automatic 2-sided printing, do not use heavy toner coverage on the even-

numbered pages of your print job.

Weight Tray

65–163 g/m2(37–60 lb. Cover) Tray 1 (MPT)

65–130 g/m2(17–32 lb. Bond) Trays 2-4

120–163 g/m2(81–110 lb. Book)

(Glossy Coated Paper)

All Trays

120–163 g/m2(81–110 lb. Book)

(Thin card stock)

Tray 1 (MPT)

2-Sided Printing

Phaser® 6250 Color Laser Printer

2-27

Tray 1 (MPT) Paper Path

The following graphic displays the printer’s paper path:

Trays 2-4 Paper Path

The following graphic displays the printer’s paper path:

Binding Preferences

Use the printer driver to select Portrait or Landscape orientation for the images on the page.

When you print 2-sided jobs, select the binding preference which determines how the pages

turn.

Portrait

Bind on Side Edge

Flip on Long Edge

Portrait

Bind on Top Edge

Flip on Short Edge

Landscape

Bind on Side Edge

Flip on Short Edge

Landscape

Bind on Top Edge

Flip on Long Edge

6250-09

6250-091

2-Sided Printing

Phaser® 6250 Color Laser Printer

2-28

To perform automatic 2-sided printing:

1. Insert paper into the tray. For more information see the “Basic Printing” topic in this

section. Place the side to be printed with the odd-numbered pages face down with the top

of the page at the back of the tray. If using paper with pre-punched holes, place the holes

toward the right side of the tray when you are facing the front panel.

Caution

If you change the type of paper in a tray, you must change the paper type on the front

panel to match the paper that you loaded. If you fail to do this, print-quality

problems can occur and the fuser can be damaged.

2. In the printer driver:

■Select the appropriate tray.

■Select the orientation.

■Select 2-sided printing as described in the table below.

3. Click OK to accept the printer driver settings, then click OK to print.

Setting the Printer Driver for 2-Sided Printing

Operating System Steps

Windows 98 or

Windows Me

1. Select File, then select Print.

2. Click Properties.

3. Select Setup, then select Print 2 Sides.

4. Select or deselect Bind On Top Edge.

Windows 2000,

Windows XP, or

Windows Server 2003

1. Select File, then select Print.

2. Click Properties.

3. Select either Flip On Long Edge, or Flip On Short Edge in Print On

Both Sides (Duplex) on the Layout tab.

Windows NT 1. Select File, then select Print.

2. Click Properties.

3. Select either Long Edge, or Short Edge in Print On Both Sides

(duplex printing) on the Page Setup tab.

6250-058

2-Sided Printing

Phaser® 6250 Color Laser Printer

2-29

Manual 2-Sided Printing

Guidelines

If the printer does not have automatic 2-sided printing capability, or you want to print on a

paper type that cannot be automatically printed on two sides, print manually on both sides of

the paper by following the procedures in this section.

■Use any tray for manual 2-sided printing.

■For best opacity and feed reliability, use Plain Paper that is 90 g/m2(24 lb. Bond) or

heavier paper.

■Increase the top margin on side 1 to at least 12 mm (0.48 in.).

■You must print all the odd-numbered pages first. Reinsert the printed pages in the same

tray from which the odd-numbered pages were taken, then print the even-numbered pages.

■Do not use heavy toner coverage on side 1 of a manual 2-sided print job.

■2-sided printing on specialty paper can shorten the life of printer components.

Print quality may be degraded on the second side of manual 2-sided printing jobs. For best

results, follow the prompt on the front panel to perform manual 2-sided printing (duplex

printing).

Mac OS 9 1. Select File, then select Print.

2. Select Layout.

3. Select Print on Both Sides.

4. Click the Binding icon that matches the edge to bind.

Mac OS X, version

10.1 (and higher)

1. Select File, then select Print.

2. Select Duplex.

3. Select Print on Both Sides.

4. Click the Binding icon that matches the edge to bind.

Setting the Printer Driver for 2-Sided Printing (Continued)

Operating System Steps

2-Sided Printing

Phaser® 6250 Color Laser Printer

2-30

Manual 2-Sided Printing Using Tray 1 (MPT)

Printing Side 1

1. Insert paper into Tray 1 (MPT). For more information, see the “Basic Printing” topic in

this section. Place the side to be printed facedown with the top of the page entering the

printer first. If using paper with pre-punched holes, place the holes toward the right side

of the tray when you are facing the front panel.

Caution

If you change the type of paper in a tray, you must change the paper type on the front

panel to match the paper that you loaded. If you fail to do this, print-quality

problems can occur and the fuser can be damaged.

2. In the printer driver, select Tray 1 (MPT).

3. Send the job to the printer so that the odd-numbered pages (side 1) are printed.

Printing Side 2

1. Insert the printed paper with side 1 faceup, and the top of the page at the back of Tray 1

(MPT). If using paper with pre-punched holes, the holes toward the left side of the tray

when you are facing the front panel.

6250-072

PHASER 6250

6250-056

2-Sided Printing

Phaser® 6250 Color Laser Printer

2-31

2. In the printer driver, select Tray 1 (MPT) as the paper source.

3. Send the job to the printer so that the even-numbered pages (side 2) are printed.

Manual 2-Sided Printing Using Trays 2-4

Printing Side 1

1. Insert paper into the tray. Place the side to be printed faceup with the top of the page at the

front of the tray. If using paper with pre-punched holes, place the holes toward the right

side of the tray when you are facing the front panel.

2. In the printer driver, select the tray containing the paper.

3. Send the job to the printer so that the odd-numbered pages (side 1) are printed.

Printing Side 2

1. Insert the printed paper with side 1 facedown,and the top of the page at the front of the

tray. If using paper with pre-punched holes, place the holes toward the left side of the tray

when you are facing the front panel.

2. In the printer driver, select the tray containing the paper.

3. Send the job to the printer so that the even-numbered pages (side 2) are printed.

6250-041

6250-040
