Xerox PHASER 6250 Manuale utente
001-1514-00 RevA Copyright © 2003 Xerox Corporation. All rights reserved.
Phaser
®
Color Laser Printer
6250
Reference
Quick
Guide
www.xerox.com/office/6250support
www.xerox.com/office/6250support
Printer Tour
Front Door AFront Door A Front Door BFront Door B
Imaging UnitImaging Unit FuserFuser
Transfer RollerTransfer Roller
Front Doors A and B access different parts of the printer.Front Doors A and B access different parts of the printer.
Phaser®
Color Laser Printer
6250
User
Documentation
CD-ROM
Complete
Reference Guide
Instructional Videos
Tray: 1 (MPT) 2-4
Statement •
5.5 x 8.5 in.
Executive ••
7.25 x 10.5 in.
A/Letter ••
8.5 x 11.0 in.
US Folio ••
8.5 x 13.0 in.
Legal ••
8.5 x 14.0 in.
A6 •
105 x 148 mm
A5 •
148 x 210 mm
A4 ••
210 x 297 mm
B5 JIS ••
182 x 257 mm
ISO B5 •
176 x 250 mm
Custom •
(H) x (W)
Tray 1 (MPT)
Tray 2-4
64-90 g/m2
(17-24 lb. Bond)
85-130 g/m2
(22-32 lb. Bond)
Tray 1 (MPT)
Tray 2
Tray 1 (MPT)
Tray 2
Tray 1 (MPT)
100-163 g/m2
(36-60 lb. Cover)
160-216 g/m2
(59-80 lb. Cover)
Thin Card Stock Thick Card Stock
Labels Phaser 25-Series Transparency
Plain Paper Heavy Plain Paper Letterhead
Print the "Paper Tips Page"
for a complete listing.
Go to Reference/Printing/
Supported Papers.
Supported Papers
Tray 2-4
Faceup
Tray 1 (MPT)
Facedown
1
3
2
1
3
2
3.1 3.2 3.3
2
3
4
1(MPT)
www.xerox.com/office/6250support
Basic Printing
OK: Letter (8.5 x 11.0 in.) Plain
Paper
Change
OK: Letter (8.5 x 11.0 in.) Plain
Paper
Change
Confirm Tray Paper
4
5
Tray: 1 (MPT)
Envelope
A7
#10 Comm......4.12 x 9.5 in.
Monarch......... 3.87 x 7.5 in.
A7................... 5.25 x 7.25 in.
Custom........... (H) x (W)
DL...................110 x 220 mm
C5................... 162 x 229 mm
C6................... 114 x 162 mm
B5................... 176 x 250 mm
Select settings to avoid fuser damage.
Use Phaser®media for best results.
Select settings to avoid fuser damage.
Use Phaser®media for best results.
Use the Xerox printer driver for complete printing control.
PC: Click the Properties button.
Mac: Use the pull-down menu.
Use the Xerox printer driver for complete printing control.
PC: Click the Properties button.
Mac: Use the pull-down menu.
www.xerox.com/office/6250support
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Walk-Up Features
Printer Setup
Troubleshooting
READY TO PRINT.READY TO PRINT.
Phaser®
Color Laser Printer
6250
User
Documentation
CD-ROM
Complete
Reference Guide
Instructional Videos
READY TO PRINT
Information
Walk-Up Features
Printer Setup
Troubleshooting
Troubleshooting
Help Guide
Paper Jams
Print Quality Problems
Network Log Pages
Service Tools
Print Quality
For Print-Quality Solutions:
See the Print-Quality Problems menu.
Print the "Troubleshooting
Print-Quality Page".
Go to Reference/Troubleshooting/
Print-Quality Problems.
Visit the Support web site.
For Print-Quality Solutions:
See the Print-Quality Problems menu.
Print the "Troubleshooting
Print-Quality Page".
Go to Reference/Troubleshooting/
Print-Quality Problems.
Visit the Support web site.
Supplies
Guide
®
6250
www.xerox.com/office/6250supplies
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Walk-Up Features
Printer Setup
Troubleshooting
READY TO PRINT.READY TO PRINT.
READY TO PRINT
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Menu Map
Printer Identification
Information Pages
Sample Pages
Supplies Info
Supplies Info
For Supplies Information:
See the Supplies Info menu.
Print the "Supplies Usage Page".
See the Supplies Guide
and contact your local reseller.
Visit the Xerox Phaser Supplies web site.
For Supplies Information:
See the Supplies Info menu.
Print the "Supplies Usage Page".
See the Supplies Guide
and contact your local reseller.
Visit the Xerox Phaser Supplies web site.
Information Button–
Press at any time to display
additional information about
the message or menu.
Information Button–
Press at any time to display
additional information about
the message or menu.
InformationInformation
www.xerox.com/office/6250support
Front Panel Buttons
Information Button
OK
Accepts the
settings selected.
OK
Accepts the
settings selected.
Up Arrow
Use arrow buttons to scroll
up and down the menus.
Up Arrow
Use arrow buttons to scroll
up and down the menus.
Down ArrowDown Arrow
Cancel
Cancels the
current print job.
Cancel
Cancels the
current print job.
Back
Returns to the previous menu.
Back
Returns to the previous menu.
InformationInformation
Press at any time to display additional information
about the message or menu.
Press at any time to display additional information
about the message or menu.
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Walk-Up Features
Printer Setup
Troubleshooting
READY TO PRINT.READY TO PRINT.
READY TO PRINT
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Menu Map
Printer Identification
Information Pages
Sample Pages
Supplies Info
1
Information
Menu Map
Printer Identification
Information Pages
Sample Pages
Supplies Info
2
Information Pages
= Prints an information page.= Prints an information page.
Use the front panel to print information pages on a variety of subjects.Use the front panel to print information pages on a variety of subjects.
www.xerox.com/office/6250support
www.colorconnection.xerox.com
Phaser®
Color Laser Printer
6250
User
Documentation
CD-ROM
Complete
Reference Guide
Instructional Videos
Information
Walk-Up Features
Printer Setup
Troubleshooting
Information
Walk-Up Features
Printer Setup
Troubleshooting
READY TO PRINT.READY TO PRINT.
READY TO PRINT
Information
Walk-Up Features
Printer Setup
Troubleshooting
Troubleshooting
Help Guide
Paper Jams
Print Quality Problems
More Information
Visit the Support web site for:
Printer drivers
Printer management software
Troubleshooting help
User manuals
Instructional videos
See the User Documentation CD-ROM for:
User manuals
Instructional videos
Networking information
Print the "Help Guide" for a complete list
of information resources.
Visit the Color Connection web site for templates, tips, and tutorials
designed especially for Xerox printers.
