Xerox WorkCentre M24 Color Manuale utente

Fig. 1

Obtain IP address of the WorkCentre M24 from the machine settings

list or network administrator. Run your Internet browser and enter IP

address in the address field. You will see the Home page like the one

above. Click Properties.

Auditron Settings for Print - 1 of 4

Fig. 2

Click Print Auditron then check mark Enable and click Apply New

Settings.

Note: In an environment that includes Mac's, enable, next to "Non-

Account" Print must be checked in order for the Mac users to be able to

print.

Fig. 6

Click Print Auditron on the left to refresh the web page.

Fig. 3

Enter the User Name and Password. Click OK. (See Machine

Administration User Guide for default password)

Fig. 5

Click OK (The WorkCentre M24 will take approximately 5 minutes to

reboot.)

Fig. 4

The "Settings have been changed" confirmation screen appears. Click

Reboot.

Auditron Settings for Print - 2 of 4

Fig. 7

Enter an unused Auditron Account Number, then click Edit.

Fig. 8

Enter a User Name (1 to 31 characters) that is not currently in use.

Enter a Password (must be 4 to 12 numeric digits only) that is not cur-

rently in use. Click Apply New Settings.

Fig. 9

* Ensure the "Settings have been changed" message appears.

You are now ready to configure the WorkCentre M24 print driver.

Continue with Auditron Setting for Print Part 2 of 2.

Quick Start Guide

Auditron Setting for Print

Part 1 of 2

The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a

computer or other electronic device, including FAX machines, to send any message unless such

message clearly contains in a margin at the top or bottom of each transmitted page or on the first page

of the transmission, the date and time it is sent and an identification of the business or other entity, or

other individual sending the message and the telephone number of the sending machine or such

business, other entity, or individual.To enter the telephone number identifying the machine and the

header text information (business name) please refer to "Entering Local Terminal Information"

pamphlet Part 2 of 2. To enter date and time please refer to "Entering Local Terminal Information"

pamphlet Part 1 of 2.

Auditron Settings for Print - 3 of 4

Fig. 1

Click Start | Settings | Printers to open the printers folder.

* This screen may very depending on the operating system of the com-

puter.

Fig. 2

Right-click the WorkCentre M24 printer icon and select Properties.

FOR PCL DRIVER ONLY:

Fig. 3

Click the Configuration tab.

Fig. 4

From the Print Features menu, highlight Specify Job Owner. In the

Specify Job Owner pull-down menu, select Enter Owner Name. Enter

the user name and password for the Job Owner previously configured

on the Internet Services screen for the WorkCentre M24. Click Ok.

You are now ready to print.

Fig. 5

Click Start | Settings | Printers to open the printers folder.

This screen may very depending on the operating system of the com-

puter.

Fig. 6

Right-click the WorkCentre M24 printer icon and select Properties.

FOR POSTSCRIPT DRIVER ONLY:

Auditron Settings for Print - 4 of 4

Fig. 7

Click Configuration tab.

Fig. 8

From the Features List, highlight Specify Job Owner. In the Specify

Job Owner pull-down menu, select Enter Owner Name. Enter the user

name and password for the Job Owner previously configured on the

Internet Services screen for the WorkCentre M24. Click Ok. You are

now ready to print.

Note:

If the auditron print feature is enabled then all users must have the

proper settings in their driver before they are able to print. "Non-

Account Print" must be enabled so that Mac users can print while the

auditron print feature is "Enabled".

Quick Start Guide

Auditron Setting for Print

Part 2 of 2
