10/100 Fast Ethernet Managed
Switch with Fiber Connectivity
KS-801
OperationManual
DOC.020419-KS801-K
-2-
The information contained in this document is subject to change without prior notice.
TRADEMARKS
Ethernet is a registered trademark of Xerox Corp.
This device complies with Class A Part 15 the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received including the interference that may cause.
CISPRACOMPLIANCE:
This device complies with EMC directive of the European Community and meets or exceeds the follow-
ing technical standard.
EN 55022 - Limits and Methods of Measurement of Radio Interference Characteristics of Information
Technology Equipment. This device complies with CISPR Class A.
WARNING: This is a Class A product. In a domestic environment this product may cause radio inter-
ference in which case the user may be required to take adequate measures.
CE NOTICE
Marking by the symbol indicates compliance of this equipment to the EMC directive of the
European Community. Such marking is indicative that this equipment meets or exceeds the following
technical standards:
EN 55022: Limits and Methods of Measurement of Radio Interference characteristics of Information
Technology Equipment.
EN 50082/1:Generic Immunity Standard -Part 1: Domestic Commercial and Light Industry.
EN 60555-2: Disturbances in supply systems caused by household appliances and similar electrical equip-
ment - Part 2: Harmonics.
-3-
Table of Contents
1. Introduction.........................................................4
1.1Features...............................................................................5
1.2Specifications.......................................................................7
2. Installing the Switch ...........................................8
2.1 Packing List .........................................................................8
2.2Panels..................................................................................9
2.3 Mounting the Switches .......................................................10
3. Making Network Connections ......................... 11
3.1NetworkSwitchedPorts .....................................................11
3.210/100BASE-TX FastEthernetPorts..................................13
3.3 Fast Ethernet Fiber Slot .....................................................15
3.4Making TrunkConnections .................................................18
3.5MakingSniffer ....................................................................20
4. LED Indicators ..................................................21
4.1 LED Panels........................................................................21
4.2Interpretation ......................................................................21
5. Performing Network Management ..................22
5.1ManagementSupport .........................................................22
5.2Management objects..........................................................23
5.3 Setting IP Address .............................................................24
5.4ConsoleManagement ........................................................24
5.5Web Management..............................................................25
5.6TelnetManagement ............................................................25
5.7 SNMPManagement ...........................................................26
5.8Support ..............................................................................26
-4-
6. Console & Telnet Management .......................27
6.1 Set IP Address...................................................................28
6.2 IP Status............................................................................28
6.3 View Port Status ................................................................29
6.4View Port Counters ............................................................30
6.5 View STP Status................................................................31
6.6Restore DefaultValues.......................................................33
6.7UpdateFirmware ................................................................34
6.8 Remote Boot System.........................................................36
7. Web Management .............................................37
7.1Start BrowserSoftwareand MakingConnection .................37
7.2 Login to the Switch.............................................................38
7.3 Port Status.........................................................................40
7.4 Port Statistics ....................................................................41
7.5Administrator......................................................................42
7.5.1 Basic ..............................................................................43
IPAddress ...............................................................................44
SNMP Entries ..........................................................................45
7.5.2Advanced ........................................................................47
Advanced/Spanning ...............................................................48
Advanced/Trunking.................................................................53
Advanced/Sniffer ....................................................................54
7.5.3ConsolePort Information .................................................56
7.5.4Port Controls ...................................................................57
7.5.5Security Manager ............................................................58
7.5.6System Manager.............................................................59
TFTPUpdateFirmware.............................................................60
Remote Boot System...............................................................62
-5-
1. Introduction
Driven by recent advances in desktop computing technology, today’s
network applications have increased in speed, power and the ability to
process information. To meet the demands of these more bandwidth-
intensive applications, this switch device provides significant increase
in performance for your Ethernet and Fast Ethernet network. The switch
comes with high number of 10/100 Fast Ethernet switched ports, each
capable of transferring information simultaneously at full wire speed to
control and allocate the network bandwidth. It also provides one Fast
Ethernet Fiber slot for uplink to fiber backbone.
The key features of the switch units are:
•Easy Migration : With 10BASE-T, 100BASE-T support, the switch
provides a non-disruptive and smooth migration path from Ethernet
to Fast Ethernet network.
•Easy Installation : With the functions of auto-speed-sensing and
auto-negotiation on each port, the switches support plug-and-play
installation by default which eliminates configuration problems.
•FiberConnectivity:With100BASE-FX slotsupport,the switch pro-
vides an optional solution for fiber uplink when it is needed.
•Network Management : With the built-in SNMP and web manage-
ment software agent, the switch provides network management func-
tion for advanced applications remotely.
-6-
1.1 Features
Designed for resolving congestion problems caused by bandwidth-hun-
gry devices and bandwidth-intensive applications as well as a high num-
ber of users, the switches not only adhere to the IEEE 802.3 10BASE-T,
IEEE802.3u 100BASE-TX,and100BASE-FXstandards, butalsofeature:
• Nine of 10/100BASE-TX auto-negotiation switched ports for
flexible connections to desktop PCs, servers and hubs.
• The 10/100BASE-TX switched ports support:
- auto speed sensing for 100Mbps or 10Mbps connection
- auto configuration with auto-negotiation devices
• One 100Mbps Fast Ethernet fiber slot supports:
- 100BASE-FXST fiber module for MM fiber
- 100BASE-FXSCfiber module for MM andSMfiber
- 100BASE-FXMT-RJfiber module for MMandSM fiber
- 100BASE-FXVF-45fibermoduleforMMfiber
• Self learning for network configuration
• Store and forward switching to ensure only good packets are forwarded
• Full-duplex or half-duplex operation support for all switched ports
• Forwarding and filtering at full wire speed
• SupportsIEEE802.3x flow control for full-duplexoperation
• Supports back-pressure flow control for half-duplex operation
• Supports IEEE 802.1d spanning tree protocol
• Supports port trunking function
• Supports port sniffer function
• Supports Web-based and SNMP management
• Full diagnostic LED indicators to indicate the power and port
status
• 19-inchrack mountable
-7-
Management Features:
• Out-of-band console management via RS232 console port
• In-band Telnet management over TCP/IP network
• In-band Web-based management over TCP/IP network
• In-band SNMP management
-SNMPagentRFC1155-1157
-MIB-II,privateMIB
- SNMP traps
• TFTP - software upgrade capability
-8-
1.2 Specifications
Standard IEEE802.310BASE-T,IEEE802.3u100BASE-TXFX
IEEE802.3xFullduplexflowcontrol
IEEE802.1D Spanningtree
Networkports 9 10/100BASE-TX switchedports
1FastEthernetfiberslotfor100BASE-FXfibermodules
Consoleport 1 DB9 Male connector
Cables 10BASE-TCat. 3,4,5UTP cable(100metersmax.)
100BASE-TXCat.5UTP cable(100meters max.)
100BASE-FXMultimode and Single Modefiber
UnitLED Power status
TPPortLED Link/Activity, Speed, Duplex/Collision status per port
Filteringrate 14,880 pps for Ethernet (10BASE-T)
148.8Kpps for Fast Ethernet(100BASE-TX and -FX)
Forwardingrate 14,880 pps for Ethernet (10BASE-T)
148.8Kpps for Fast Ethernet(100BASE-TX and -FX)
Filteringaddress Multicast/Broadcast/Unicast address
MACaddresses 4K entries
Trunking 2 trunks max., 4 trunking ports per trunk max.
RAMbuffer 512K bytes
Environment Temperature 0oCto40oC
Relativehumidity 10% to 90% non-condensing
Power Universal power supply 100-240VAC,47-63Hz,25W
Dimension 260x150x44.4mm(10.24x5.9x1.75inch)
-9-
2. Installing the Switch
The switch is designed to operate in workgroup environments without a
complicated configuration procedure. It also features an auto-select 100-
240V, 50/60Hz power supply unit, which works in most countries around
the world.
Before connecting the supplied power cord into the switch, check to see
that the cord voltage and current rating conform to the standards of the
country of operation.
2.1 Packing List
The switch has the following components shipped with it:
• One switch unit
• One AC power cord
• One RS232 console cable
• 19-inchrack mount kit
• CD for installation guide, software modules, MIB file and software
operation manuals
-10-
2.2 Panels
The following figure illustrates the major components on front and rear
panels:
10/100 Port 1-9 10BASE-T/100BASE-TXPort#1-#9
CrossoverSW Crossover setting switch for 10/100 Port #9
100Fiber Slot 100M Fiber slot for Port #9
LEDindicators LED display for power and all port status
ACpowersocket Plug-in socket for AC power cord
Consoleport Connector for local console connection
