MonoSnap Lite (Ages 6+)
USER MANUAL
!
!
Model:
PCZ2
Customer Service
Scan the QR code to join our !
Telegram group for support.!
Please be sure to specify the
model number.
This guide contains all the info you need to get from setup to your shots.
LED Power !
Button
Shutter !
Button
Lens
USB-C Port
Print Head
Serrated Edge
Reset Hole
Fig. 2
Fig. 3
Fig. 1
Accessories Included
At a Glance
Chapter 1: Safety Instructions!
1. Adult Supervision: The MonoSnap camera is designed for children aged 6 and
above. Adult supervision is recommended during use to ensure safe and
responsible handling.!
2. Safe Handling: Instruct children to hold the camera securely and avoid touching
the internal print head while it is hot. Wait for it to cool down before attempting
to open the camera.!
3. Built-In Rechargeable Battery: The MonoSnap camera features a built-in
rechargeable lithium-ion battery. Only use the provided USB-A to C cable for
recharging the camera. Do not attempt to use other cables or chargers, as they
may not be compatible and could pose a safety risk.!
4. Proper Charging: Connect the USB-A end of the cable to a suitable power
source, such as a computer or USB wall adapter. Insert the USB-C end into the
camera's charging port. Ensure a secure connection. Monitor the charging
process and avoid overcharging the battery by disconnecting the cable once the
battery is fully charged.!
5. Battery Maintenance: To maximize battery life and safety, avoid exposing the
camera to extreme temperatures (both hot and cold). Do not attempt to
disassemble, puncture, or tamper with the battery or camera. !
6. Waterproof Caution: Please note that the MonoSnap camera is not waterproof.
Keep the camera away from water and moisture to avoid damage. Do not
submerge the camera or expose it to rainy or wet conditions.!
7. Proper Storage: Store the MonoSnap Pro camera in a safe place when not in
use. Keep it out of the reach of young children and away from moisture, extreme
temperatures, and direct sunlight.!
8. Responsible Sharing: Teach children to respect others' privacy and not take
photos without permission. Encourage responsible and respectful sharing of
photos with friends and family.!
Chapter 2: Getting Started
1. Charging Your MonoSnap!
•Connect the USB-C end of the provided cable to your MonoSnap camera.!
•Plug the other end of the cable into a USB-A power source.!
•Allow the camera to charge until the battery is full.!
2. Powering on!
•Locate the power button on your MonoSnap camera.!
•Press and hold the power button for 3 seconds to power on the camera.!
3. Launching the Viewfinder:!
•Press the red button on top to extend the viewfinder for framing your shot. You
can manually push the viewfinder back after use.!
NOTE: The MonoSnap uses a special viewfinder located slightly above the
camera's lens. This means that what you see through the viewfinder is from a
different perspective than what the lens is seeing. As a result, you’ll need to
adjust your aim a little upwards to compose your shot correctly. (Fig. 1)!
4. Capturing a Photo!
•Point the camera at your subject using the viewfinder.!
•Press the shutter button to instantly capture the photo.!
5. Printing and Sharing!
•Wait for the camera to process the image and print it instantly.!
•Once printed, carefully tear offthe photo against the serrated edge.!
•Share the instant printout with others or keep it as a physical memento.!
6. Loading the Paper Roll!
•Slide to open the paper compartment cover. (Fig. 2)!
•Remove the remaining paper roll, if present. !
•Insert a new paper roll into the compartment and make sure the smooth side of
the paper is facing up. (Fig. 3)!
•Close the paper compartment cover securely. !
7. Powering off!
•Press and hold the power button for 3 seconds to power offthe camera after
use.!
Chapter 3: Problems? No Problem!
How long can it be used on a single charge?!
•One roll of 300dpi grayscale print.!
Why is there a discrepancy between the range printed and what is seen through
the viewfinder? !
•The viewfinder design is similar to that of a rangefinder camera, resulting in a
slight deviation between the viewfinder and camera lens. The actual captured
image may appear slightly lower than what is seen in the viewfinder. Shooting
technique: Align the subject within the viewfinder and slightly lift the bottom of
the camera by about 5 degrees for the best results. (Fig. 1)
What is the resolution of the camera? !
•The camera has a 1-megapixel wide-angle lens with a DFOV of 70 degrees. It
also comes with an ISP for professional image processing. It delivers good
imaging results when capturing subjects from a distance of half a meter or more.!
How long does it take to fully charge?!
•It takes about 1.5 hours to fully charge.!
Unable to print? !
•Check if the thermal paper has run out.!
•Check if the thermal print head is overheated (indicated by a flashing white
light). If overheated, wait for the print head to cool down before attempting to
print again.!
•Restart the camera and try again.!
Why is no content being printed? !
•Confirm that the consumables are installed correctly, with the correct orientation
(that is, the smooth side faces up). (Fig. 3)!
How to restart the device if it freezes?!
•Slide open the compartment cover, remove the consumables, and press the
Reset pinhole once with a paperclip to restart the device.!
How to check the battery level?!
•The LED power button will flash white when the battery level is low. !
Does this printing camera require carbon ribbons?!
•It is a thermal printer that does not require carbon ribbons or ink cartridges. Only
thermal paper is needed for printing.!
What is the difference between regular thermal paper and grayscale thermal
paper?!
•Grayscale paper has a brighter surface and provides more delicate print results.!
Does the printing paper contain bisphenol A?!
•The provided paper roll does not contain harmful substances such as
fluorescent agents, bisphenol A, or bisphenol S.!
How long does the printout last?!
•The printout has a longevity of at least 5 years.!
Chapter 4: Specifications
Model
PCZ2
Technology
Direct Thermal Printing
Print Resolution
300dpi
Min. Print Speed
2.3mm/s
Compatible Consumable
Grayscale Thermal Paper (57 x ⌀30mm)
Photo Aspect Ratio
4:3
Megapixels
1MP
Lens
Wide-Angle Lens
Focus Range
50cm - Infinity
Field of View
70-Degree Diagonal
Battery Capacity
1,200mAh
Interface
USB-C
Input
5V⎓1A
Weight
approx. 250g (exl. paper roll)
Dims.
105 x 90 x 52mm
!
© 2023 Xiamen PAPERANG Technology Co., Ltd. All Rights Reserved. !
PAPERANG is a registered trademark of Xiamen PAPERANG Technology Co., Ltd.
