XK034015/XK034016/XK034017!Motorcycle!7-Color!Kit!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
!
!
1!
Input
Voltage
Controller
Size
Power Consumption
Per Pod/Strip
Controller Max Output
12V DC
3.62 x 2.24 x 0.7in
(92 x 57 x 18mm)
0.05 amp/pod
0.1 amp/strip
4amp
Warranty and Disclaimer
Within One year after the purchase date, the original buyer may return any XKGLOW products that has
one or more LEDs that fail to illuminate, due to a defect in materials or workmanship.
Installation of this product must be performed by a licensed professional. Should the failure of the product be
the result of damage occurring as a result of improper installation, alteration of the product or an act or omission
on the part of the consumer, this warranty is void. XKGLOW Lighting shall not be responsible for any
consequential damages which arise from the use and/or installation of the product. If the kit is installed in any
manner other than specified, XKGLOW Lighting reserves the right to deny any warranty claims at the discretion
of the technical support department. Any product return must include the original packaging, invoice number and
a statement of the alleged defect. Upon receipt of the returned product, the company will test the product for
defect. If the results of the testing do not support the warranty claim, do not reveal any defect or indicate
consumer negligence in the installation and handling of the product, then the product will be returned to you and
you will be charged a reshipping fee. If the product is returned from an address within the continental United
States, within the first 30 days after purchase, and is found to be defective, XKGLOW Lighting will exchange or
refund the original purchase expense. This offer does not extend to the cost for shipping charges on any
international packages.
Additional Disclaimer Terms
Please check your local and state laws for the proper use of this product.
• Improper installation of electrical products such as lighting may cause damage to any vehicle or device to
which the improperly handled or installed lighting is attached.
• Improperly installed product may cause electrical injury to persons.
• It is recommended that the kit should be installed by a licensed professional.
• XKGLOW assumes no liability for the installation of the product.
• Warranty or liability will not exceed the product purchase price, which shall be buyer’s sole and exclusive
remedy.
Return/Exchange Procedure
1. Email [xk@xkglow.com] to notify us of the product issue as well as the item number and name of customer
on invoice.
2. We will send you the trouble-shooting guide to fix the issue, or to narrow down which of the component(s)
need to be replaced. If the issue still exists, we will ask you to send back the defective items to be replaced.
3. Please send the returned item as instructed, along with claims and a telephone number where you can be
reached.
4. After the returned item(s) have been accepted and inspected, we will issue a refund or replace the items
ASAP. For refunds, item(s) must be sent to XKGLOW within 14 days from date of purchase. Original shipping
charges are not refundable.
We always stand behind our products and are committed to our customers! For questions you may have,
please contact xk@xkglow.com. We normally respond within 24 hours. (Monday-Friday).
XK034015/XK034016/XK034017!Motorcycle!7-Color!Kit!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! !
!
!
2!
Recommended Mounting Locations
Mounting Instructions
Remote Functions
Button A: Flash Pattern adjustment
Button B: Speed adjustment
Button C: Color adjustment
Button D: Turn on/off the entire light kit.
1. Test all components before mounting: As shown below, plug all light units together and connect them to
the controller and the switch wiring harness. Connect the RED battery terminal to the POSITIVE pole of 12V
DC battery. Connect the BLACK battery terminal to the NEGATIVE pole. Turn on the switch and push the
remote buttons to exam all lights. If the light has any defective issue, please contact us and we will be happy
to replace them for you.
2. Plan mounting locations: Disconnect the tested lights from the vehicle’s battery and remove any bodywork
that will have the LED lights located behind them. Clean the mounting surface. LOOSELY mount the LED
lights using Scotch or painters tape (not included) to the desired locations. (DO NOT firmly attach the lights
in this step.)
3. Mount the lights and wires: Clean the mounting surface again. Use 3M tape to attach lights to the planned
locations. Firmly push the lights to make sure they are securely attached. Connect all splitters, extension
wires and the switch wiring harness. Apply 1 piece of 3M tape to the back of
each connections and mount them securely. WARNING- Do not force the
plugs together! If they don’t snap together, verify that all the pins line up. If a
pin is out of place, it must be straightened for the plug to snap together.
4. Secure all wires and connectors: Use provided zip ties and wire clips to
neatly mount and hide any loose wires. Make sure they are not touching
anything hot surface or located on moving parts. Locate the ON/OFF switch
in a dry and convenient location. Use provided end caps to cap all uncovered connectors.
5. Connect to 12V DC power: Firmly connect the wire terminals to the positive and negative poles of the
battery.
Visit www.XKGLOW.com to purchase extra lights and accessories.
