Xtracycle FreeLoader Too Manuale utente
-
Freeloader too 2021
01 B
Attach the four hook and loop straps located on the sides of
the bags to the vertical supports on the rear rack. There are
two straps on each side of the bag.
01 A
Bring the top back of the FreeLoader Too behind the pannier
rail (if applicable). Attach the five hook and loop straps on
the top of the FreeLoader Too to the top of the RearRack. If
installing on a bike with an LT2 V-rack, you will need to loosen
the deck enough for the strap to fit between the deck and
the rack.
01 installing the freeloader
too on the rear rack
2
01 D
Attach the two bottom hook and loop straps to the frame of
the bike.
Repeat steps 01 A - 01 D for the other side.
01 C
Make sure to attach the straps located toward the front of
the RearRack so it sits below the RackLock. You may need
to loosen some straps and adjust the positioning of the
freeloader in order to accomplish this. The straps on the rear
portion of the bag will both be located above the RackLock.
Please note:
Each FreeLoader Too bag is identical. There is no left side
bag or right side bag.
02 opening the freeloader too
bags
3
02 B
To open the slings, slide this webbing loop off of the C-hook
and allow the hard bottom panel to fold down.
02 A
The FreeLoader Too sling is held closed with 3 hooks located
on the strap adjusters of the sling straps. This hook slides
onto a webbing loop located on what is the bottom hard
panel portion of the sling.
02 D
You can now use the slings to carry cargo.
To fold the slings out of the way, repeat these steps in
reverse.
02 C
With the bottom panel now folded out, you can access the
top of the slings. Take this same C-hook and slide it onto
three webbing loops located on the top of the slings.
03 using the freeloader too
with child rear seats
4
03 B
The other option is to have the slings open and to have the
rear child seat leg holds sitting inside the slings.
03 A
When using the FreeLoader Too with a rear child seat, you
have two options. One is to have the bags folded up and out
of the way, tucked under the leg holds of the child seat.
Care & Maintenance
If the FreeLoader Too becomes dirty, it can be gently
scrubbed with a washcloth and soap and water. Hand
wash only and air dry.
