magiccarpet Manual 2021

01 possible magiccarpet

configurations

One MagicCarpet in front

One child seat in back

One MagicCarpet in back

One child seat in front

2

Two MagicCarpetsOne MagicCarpet

Please note

When carrying a passenger on the back deck of an

Xtracycle, be sure a set of bags or wheelskirts is properly

installed to protect the passenger's feet.

02 installing one magiccarpet

with no child seats

02 D

Bring the strap back up towards the MagicCarpet and thread

it up through the D-ring sewn onto the pad. The strap should

now be looping under and around the horizontal support bar

of the RearRack.

02 C

Thread the long end of the MagicCarpet fastening strap

down and between the deck and the horizontal support bar.

With your fingers now underneath the horizontal support bar,

grab the strap and pull it back towards you.

3

02 B

Undo the hook and loop straps and slide them out of

the plastic rings so they are long and hanging off of the

MagicCarpet. Place the MagicCarpet on the rear deck.

02 A

When placing the MagicCarpet on the RearRack, the end of

the MagicCarpet with the stitched Xtracycle logo is the back

end of the pad.

4

02 E

Gently pull up and then cinch down the strap. When at the

desired tension, press the strap onto itself to secure it in

place. To complete the installation, repeat steps 02 C - 02 G

for all the straps.

03 installing two magiccarpets

or a magiccarpet & child seat

03 D

To install a second MagicCarpet or a MagicCarpet on the

rear end only, position the front of the second MagicCarpet

to start where the first MagicCarpet stops or in the center of

the deck.

03 C

To attach them to the bracket, simply loop the straps around

the vertical bracket supports.

5

03 B

To attach the hook and loop straps to the horizontal support

bars, follow steps 02 C - 02 G.

03 A

If a Hooptie or two SnackBars are installed on the RearRack,

you can install MagicCarpets following these steps.

To install two MagicCarpets or a MagicCarpet on the front of

the deck only, position a MagicCarpet on the deck so that the

back end is on the center of the rear deck. Front half will fold

up and along the inside of the Hooptie or SnackBar bracket.

6

Care & Maintenance

If the MagicCarpet becomes dirty, it can be gently

scrubbed with a washcloth and soap and water. Hand

wash only and air dry.
