Yamaha YZ125 2019 Guida all'applicazione

B0V-28199-10LIT-11626-32-19

Read this manual carefully before operating this vehicle.

YZ125K2

OWNER’S SERVICE MANUAL

YZ125

2019

PRINTED IN JAPAN

2018.04-0.4×1 !

(E)

PRINTED ON RECYCLED PAPER

2019

YZ125K2

B0V-28199-10_OSM_cover.indd 1-3 2018/03/09 14:26:49

For your best ownership experience, think Genuine Yamaha!

Genuine Yamaha Parts – Genuine Yamaha replacement parts are the exact same parts as the ones

originally equipped on your vehicle, providing you with the performance and durability you have come to

expect. Why settle for aftermarket parts that may not provide full confidence and satisfaction?

Genuine Yamaha Accessories – Yamaha only offers accessories that meet our high standards for quality

and performance. Buy with confidence, knowing your Genuine Yamaha Accessories will fit right and

perform right – right out of the box.

Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products.

They're formulated and approved by the toughest judges we know: the Yamaha engineering teams that

know your Yamaha from the inside out.

Genuine Yamaha Service Manuals – Get the same factory manual for your vehicle that the technicians

at your authorized Yamaha dealer use. Service manuals are available through your Yamaha dealer or you

can order them directly through yamahapubs.com.

Genuine Yamaha products are available only from your Yamaha dealer.

Find out more at yamaha-motor.com

postscript3-本文レイアウト準拠-.fm Page 1 Monday, May 23, 2011 1:39 PM

Operating, servicing and

maintaining a passenger vehicle or off-road vehicle can

expose you to chemicals including engine exhaust,

carbon monoxide, phthalates, and lead, which are

known to the State of California to cause cancer and

birth defects or other reproductive harm. To minimize

exposure, avoid breathing exhaust, do not idle the

engine except as necessary, service your vehicle in a

well-ventilated area and wear gloves or wash your

hands frequently when servicing your vehicle. For more

information go to

www.P65Warnings.ca.gov/passenger-vehicle

QRead this manual carefully before operating this vehicle. This manual should stay with this vehicle if it is sold.

B0V-28199-10_OSM_cover.indd 4-6 2018/03/09 14:26:49

YZ125K2

OWNER'S SERVICE MANUAL

1st Edition, April 2018

Any reprinting or unauthorized use

without the written permission of

Yamaha Motor Corporation U.S.A.

is expressly prohibited.

Printed in Japan

P/N. LIT-11626-32-19

INTRODUCTION

Congratulations on your purchase of a Yamaha

YZ series. This model is the culmination of

Yamaha's vast experience in the production of

pacesetting racing machines. It represents the

highest grade of craftsmanship and reliability

that have made Yamaha a leader.

This manual explains operation, inspection, ba-

sic maintenance and tuning of your machine. If

you have any questions about this manual or

your machine, please contact your Yamaha

dealer.

Yamaha continually seeks advancements in

product design and quality. Therefore, while

this manual contains the most current product

information available at the time of printing,

there may be minor discrepancies between

your machine and this manual. If you have any

questions concerning this manual, please con-

sult your Yamaha dealer.

PLEASE READ THIS MANUAL CAREFULLY

AND COMPLETELY BEFORE OPERATING

THIS MACHINE. DO NOT ATTEMPT TO OP-

ERATE THIS MACHINE UNTIL YOU HAVE

ATTAINED A SATISFACTORY KNOWL-

EDGE OF ITS CONTROLS AND OPERATING

FEATURES AND UNTIL YOU HAVE BEEN

TRAINED IN SAFE AND PROPER RIDING

TECHNIQUES. REGULAR INSPECTIONS

AND CAREFUL MAINTENANCE, ALONG

WITH GOOD RIDING SKILLS, WILL ENSURE

THAT YOU SAFETY ENJOY THE CAPABILI-

TIES AND THE RELIABILITY OF THIS MA-

CHINE.

IMPORTANT MANUAL

INFORMATION

Particularly important information is distin-

guished in this manual by the following nota-

tions.

This is the safety alert symbol. It is used to

alert you to potential personal injury haz-

ards. Obey all safety messages that follow

this symbol to avoid possible injury or

death.

A WARNING indicates a hazardous situa-

tion which, if not avoided, could result in

death or serious injury.

A NOTICE indicates special precautions

that must be taken to avoid damage to the

vehicle or other property.

A TIP provides key information to make proce-

dures easier or clearer.

SAFETY INFORMATION

THIS MACHINE IS DESIGNED STRICTLY

FOR COMPETITION USE, ONLY ON A

CLOSED COURSE. It is illegal for this machine

to be operated on any public street, road, or

highway. Off-road use on public lands may also

be illegal. Please check local regulations be-

fore riding.

• THIS MACHINE IS TO BE OPERATED BY

AN EXPERIENCED RIDER ONLY.

Do not attempt to operate this machine at

maximum power until you are totally familiar

with its characteristics.

• THIS MACHINE IS DESIGNED TO BE RID-

DEN BY THE OPERATOR ONLY.

Do not carry passengers on this machine.

• ALWAYS WEAR PROTECTIVE APPAREL.

When operating this machine, always wear an

approved helmet with goggles or a face

shield. Also wear heavy boots, gloves, and

protective clothing. Always wear proper fitting

clothing that will not be caught in any of the

moving parts or controls of the machine.

• ALWAYS MAINTAIN YOUR MACHINE IN

PROPER WORKING ORDER.

For safety and reliability, the machine must be

properly maintained. Always perform the pre-

operation checks indicated in this manual.

Correcting a mechanical problem before you

ride may prevent an accident.

• GASOLINE IS HIGHLY FLAMMABLE.

Always turn off the engine while refueling.

Take care to not spill any gasoline on the en-

gine or exhaust system. Never refuel in the vi-

cinity of an open flame, or while smoking.

• GASOLINE CAN CAUSE INJURY.

If you should swallow some gasoline, inhale

excess gasoline vapors, or allow any gasoline

to get into your eyes, contact a doctor imme-

diately. If any gasoline spills onto your skin or

clothing, immediately wash skin areas with

soap and water, and change your clothes.

• ONLY OPERATE THE MACHINE IN AN

AREA WITH ADEQUATE VENTILATION.

Never start the engine or let it run for any

length of time in an enclosed area. Exhaust

fumes are poisonous. These fumes contain

carbon monoxide, which by itself is odorless

and colorless. Carbon monoxide is a danger-

ous gas which can cause unconsciousness or

can be lethal.

• PARK THE MACHINE CAREFULLY; TURN

OFF THE ENGINE.

Always turn off the engine if you are going to

leave the machine. Do not park the machine

on a slope or soft ground as it may fall over.

• THE ENGINE, EXHAUST PIPE, MUFFLER,

AND OIL TANK WILL BE VERY HOT AFTER

THE ENGINE HAS BEEN RUN.

Be careful not to touch them or to allow any

clothing item to contact them during inspec-

tion or repair.

• PROPERLY SECURE THE MACHINE BE-

FORE TRANSPORTING IT.

When transporting the machine in another ve-

hicle, always be sure it is properly secured

and in an upright position and that the fuel

cock is in the "OFF" position. Otherwise, fuel

may leak out of the carburetor or fuel tank.

YAMAHA MOTOR CORPORATION, U.S.A.

YZ MOTORCYCLE LIMITED WARRANTY

HOW TO USE THIS MANUAL

FINDING THE REQUIRED PAGE

1. This manual consists of seven chapters; "General Information", "Specifications", "Regular inspec-

tion and adjustments", "Engine", "Chassis", "Electrical" and "Tuning"

2. The table of contents is at the beginning of the manual. Look over the general layout of the book

before finding then required chapter and item.

Bend the book at its edge, as shown, to find the required fore edge symbol mark and go to a page

for required item and description.

MANUAL FORMAT

All of the procedures in this manual are organized in a sequential, step-by-step format. The informa-

tion has been complied to provide the mechanic with an easy to read, handy reference that contains

comprehensive explanations of all disassembly, repair, assembly, and inspection operations.

In this revised format, the condition of a faulty component will precede an arrow symbol and the

course of action required will follow the symbol, e.g.,

• Bearings

Pitting/damage →Replace.

HOW TO READ DESCRIPTIONS

To help identify parts and clarify procedure steps, there are exploded diagrams at the start of each

removal and disassembly section.

1. An easy-to-see exploded diagram "1" is provided for removal and disassembly jobs.

2. Numbers "2" are given in the order of the jobs in the exploded diagram. A number that is enclosed

by a circle indicates a disassembly step.

3. An explanation of jobs and notes is presented in an easy-to-read way by the use of symbol marks

"3". The meanings of the symbol marks are given on the next page.

4. A job instruction chart "4" accompanies the exploded diagram, providing the order of jobs, names

of parts, notes in jobs, etc.

5. For jobs requiring more information, the step-by-step format supplements "5" are given in addition

to the exploded diagram and job instruction chart.

ILLUSTRATED SYMBOLS (Refer

to the illustration)

Illustrated symbols "1" to "7" are used to identi-

fy the specifications appearing in the text.

1. With engine mounted

2. Filling fluid

3. Lubricant

4. Special tool

5. Tightening

6. Specified value, Service limit

7. Resistance (Ω), Voltage (V), Electric cur-

rent (A)

Illustrated symbols "8" to "14" in the exploded

diagrams indicate grade of lubricant and loca-

tion of lubrication point.

8. Apply engine mixing oil

9. Apply transmission oil

10. Apply molybdenum disulfide oil

11. Apply brake fluid

12. Apply lightweight lithium-soap base grease

13. Apply molybdenum disulfide grease

14. Apply silicone grease

Illustrated symbols "15" to "16" in the exploded

diagrams indicate where to apply a locking

agent and where to install new parts.

15. Apply locking agent (LOCTITE®)

16. Use new one

MEMO
