User’s
Manual FSA120 (EJXMVToolTM)
Read Me First
IM 01C25R51-10E
IM 01C25R51-10E
4th Edition
Thank you for purchasing FSA120 EJX-MV Conguration DTM.
This document is intended to guide users what to do after receiving the software package.
Please carefully read this document rst when you receive the package and follow the instructions.
I. Receiving the Package
Soon after you receive the package, please open it and conrm that following items are included in the package.
• CD-ROM 3 pieces
□ FieldMate disk (Basic or Advance, as specied in order)
□Device Files disk
□EJXMVToolAdditional Resource disk
• Paper Document
□ Read Me First (IM 01C25R51-10E) <This document>
□FieldMate User license sheet
□EJXMVTool User license sheet
□EJXMVTool LicenseAgreement
□ FieldMate Versatile Device Management Wizard Getting Started (IM 01R01A04-01E)
□ FieldMate Operational Precaution (IM 01R01A01-91E)
II. To start with
1) Before starting any operation, please carefully read the instructions in the user’s manual of FSA120 and obtain necessary
knowledge about installation and operation of the software.
The User’s manual “FSA120 EJX-MV Conguration DTM”(IM 01C25R51-01E) is provided as a Portable Document Format
(pdf) le in the CD-ROM labeled “EJXMVTool Additional Resource Disk”, and is located at <Yokogawa MVTool Additional
resource Disk CDROM>: \EJXMVTool_Manual.pdf.
Set the Additional resource disk in the CD-ROM drive of your computer and double click the name of the le.
To read the le in PDF format, Adobe Reader is required.
If Adobe Reader is not on your PC, install it. This can be done by setting the FieldMate disk in the CD-ROM drive of your
computer and double clicking on;
< FieldMate CDROM>:\READER\ENGLISH\AdbeRdr80_en_US.exe in Windows Explorer.
2) FSA120 is the DTM software utilizing FDT/DTM technology. To use this software, a frame application is required. ‘Field-
Mate’ is bundled with this software package as Yokogawa standard frame application. The quality, operability of EJXMVTool
are certied for use with FieldMate only. Please use ‘Field Mate’ as frame application. Also, you can use Field communica-
tion server included in FieldMate as an communication DTM.
For the installation and operation of FieldMate, please refer to the printed document “FieldMate Versatile Device Manage-
ment Wizard Getting Started” (IM 01R01A04-01E) and “FieldMate Operational Precaution” (IM 01R01A01-91E). For the
details of installation and operation, please also refer to the user’s manual of FieldMate in pdf format which is stored in the
FieldMate CDROM.
