Zagg Pro Guida all'installazione

NEED MORE HELP? PLEASE SEE OUR FAQ SECTION AT:

www.ZAGG.com/faq

WARRANTY REGISTRATION

SEPARATING

YOUR ZAGGkeys™ PRO™/PROplus™ COMES WITH A

1 YEAR MANUFACTURER’S WARRANTY. YOU

MUST REGISTER YOUR ZAGGkeys PRO/PROplus™

AND KEEP YOUR RECEIPT OF PURCHASE TO

ACTIVATE THE WARRANTY. IF YOU PURCHASED

ON ZAGG.COM, ZAGG HAS ALREADY REGISTERED

YOUR ZAGGkeys PRO/PROplus AND HAS YOUR

PROOF OF PURCHASE.

YOUR ZAGGkeys PRO/PROplus ATTACHES

TO THE APPLE® iPAD® USING MAGNETS AT

THE TOP AND BOTTOM OF BOTH DEVICES.

1. TO SEPARATE, SET ON STABLE SURFACE

AND GRASP BOTH DEVICES FIRMLY USING

THE GROOVE AT THE TOP OF THE ZAGGkeys

PRO/PROplus, AND CAREFULLY PULL APART.

THEN, AN ADDITIONAL PULL WILL DETACH

THE BOTTOM MAGNETS.

TO CLOSE, LINE UP THE CUTOUT IN THE

ZAGGkeys PRO/PROplus WITH THE 30-PIN

CHARGER PORT ON iPAD®, AND PLACE iPAD®

FACE DOWN ONTO THE PRO/PROplus. THE

MAGNETS WILL ATTRACT AND SECURE iPAD®

TO THE ZAGGkeys PRO/PROplus. iPAD® WILL

AUTOMATICALLY SWITCH TO SLEEP MODE

WHEN SECURED IN THE ZAGGkeys PRO/PROplus

AND START UP WHEN THE DEVICES ARE

SEPARATED. THIS FUNCTION CAN BE

TOGGLED ON OR OFF IN THE SETTINGS

MENU OF YOUR iPAD®.

NOTE: THE ZAGGkeys PRO/PROplus AND

iPAD® MUST BE ALIGNED PROPERLY FOR

THE MAGNET CLOSURE TO FUNCTION. IF

THE ALIGNMENT IS NOT CORRECT, THE

MAGNETS WILL NOT ATTRACT.

POSITIONING

SIMPLY PLACE iPAD® EITHER

VERTICALLY OR HORIZONTALLY

INTO THE SLOT AND LEAN THE

DEVICE BACK. THE DESIGN OF

THE CHANNEL AND THE WEIGHT

OF THE DEVICE, WILL HOLD

YOUR iPAD® SECURELY IN PLACE

DURING NORMAL USE. CENTRAL GROOVE

POWERING ON AND PAIRING YOUR

ZAGGkeys PRO/PROplus

THE ZAGGkeys PRO/PROplus’s BLUETOOTH

KEYBOARD SHOULD ONLY NEED TO PAIR TO

YOUR iPAD® ONCE AS FOLLOWS:

1. ON THE ZAGGkeys PRO/PROplus, SLIDE THE

POWER BUTTON ON. THE BLUE CAPS LOCK

LIGHT WILL ILLUMINATE FOR FOUR SECONDS

AND THEN TURN OFF TO SAVE POWER. YOUR

ZAGGkeys PRO/PROplus IS STILL ON.

2. PRESS THE PAIR BUTTON AND THE CAPS

LOCK LIGHT WILL FLASH INDICATING THAT

YOUR PRO/PROplus IS READY TO PAIR.

3. ON THE iPAD®, SELECT: SETTINGS >

GENERAL > BLUETOOTH > ON.

4. THE CAPS LOCK LIGHT WILL FLASH ON THE

PRO/PROplus AND THE iPAD® WILL DISPLAY

“ZAGGkeys PRO/PROplus” AS AN AVAILABLE

DEVICE.

5. SELECT “ZAGGkeys PRO/PROplus” ON THE

iPAD®; TO PAIR.

6. YOUR iPAD® AND PRO/PROplus WILL

AUTOMATICALLY PAIR.

YOUR ZAGGkeys PRO/PROplus COMES WITH A

CHARGING CABLE THAT PLUGS INTO THE SIDE

OF THE DEVICE. YOU CAN PLUG THE OTHER

END OF THE CHARGING CABLE INTO ANY USB

OUTLET, INCLUDING THE FOLLOWING: A

COMPUTER, YOUR iPAD® CHARGER, A ZAGGsparq™,

ETC. A COMPLETE CHARGE TAKES 2-4 HOURS.

YOUR ZAGGkeys PRO/PROplus HAS BEEN

DESIGNEDWITH SPECIAL FUNCTION KEYS TO

GIVE YOU MORE CONTROL OF YOUR iPAD®.

CHARGING

SPECIAL FUNCTION KEYS

CHARGING PORT

HOME BUTTON

-BRINGS YOU TO THE iPAD® HOME SCREEN

-BRINGS UP THE iPAD® SEARCH SCREEN

SLIDE-SHOW

-STARTS PLAYING SLIDE-SHOW OF SAVED

PICTURES

KEYBOARD HIDE/ SHOW

-ALLOWS YOU TO HIDE OR SHOW iPAD® ON

SCREEN KEYBOARD

LOCK

-MAKES THE iPAD® SCREEN GO DARK AND

COME BACK ON WHEN PRESSED AGAIN

PREVIOUS TRACK

-SKIPS TO PREVIOUS TRACK ON CURRENT

PLAYLIST

PLAY/PAUSE

-STARTS OR STOPS CURRENT PLAYLIST

NEXT TRACK

-SKIPS TO NEXT TRACK ON CURRENT PLAYLIST

MUTE

-MUTES AUDIO ON iPAD®

VOLUME DOWN

-DECREASES VOLUME ON iPAD®

VOLUME UP

-INCREASES VOLUME ON iPAD®

BATTERY LIGHT INDICATOR KEY: TURNS ON

WHEN CHARGING, TURNS OFF WHEN FULLY

CHARGED. WHEN PRESSED, LIGHT ON KEY

WILL BLINK GREEN WHEN BATTERY IS

CHARGED APPROXIMATELY 50-100%, BLINK

YELLOW WHEN 20-50%, AND BLINK RED

WHEN LESS THAN 20%. (THIS SHOULD GIVE

YOU ABOUT 2 WEEKS OF NORMAL USE)

CAPS LOCK STATUS LIGHT (BLUE):

1. LIGHT STAYS ON WHEN CAPS LOCK IS ACTIVE

2. FLASHES WHEN PAIRING

3. LIGHTS BRIEFLY WHEN YOU TURN ON

ZAGGkeys PRO/PROplus THEN TURNS OFF

TO SAVE BATTERY

BACKLIGHT KEY (ON SELECT MODELS):

WHEN PRESSED, BACKLIGHT ON KEYS WILL

TOGGLE FROM LOW, TO MEDIUM, TO HIGH,

AND THEN OFF. NOTE: WHEN BATTERY LIFE

IS LESS THAN 20%, BACKLIT KEYS ARE

AUTOMATICALLY SWITCHED OFF TO

CONSERVE BATTERY LEVEL. EVEN THOUGH

YOU WILL NOT BE ABLE TO USE YOUR

BACKLIGHTS, THE KEYBOARD WILL HAVE

ENOUGH POWER TO OPERATE FOR ABOUT

2 WEEKS.

LIGHTS AND BUTTONS

TO CONSERVE BATTERY LIFE, THE BACKLIT

KEYS WILL TURN OFF AFTER 60 SECONDS OF

NON-TYPING. THEY WILL AUTOMATICALLY

TURN ON AT THE PRESS OF ANY KEY. AFTER 30

MINUTES OF NON-TYPING THE BACK LIT KEYS WILL

NEED TO BE TURNED BACK ON BY SIMPLY PRESSING

THE BACKLIGHT KEY. PRESS THE BACKLIGHT KEY

TO INCREASE BRIGHTNESS FROM LOW, MEDIUM

AND HIGH AND THEN AGAIN TO TURN OFF.

TO CHANGE THE COLOR OF THE BACKLIGHT, PRESS

THE BACKLIGHT KEY AND THE RIGHT OR LEFT

DIRECTION KEY AT THE SAME TIME. YOU CAN SELECT

FROM: WHITE, RED, AMBER, GREEN, AQUA, BLUE,

OR VIOLET.

BACKLIGHT (ON ZAGGkeys PROplus)

ZAGGkeys PRO/PROplus’s LONG-LIFE BATTERY

LASTS FOR SEVERAL MONTHS OF NORMAL USE.

THE ZAGGkeys PRO/PROplus WILL GO INTO SLEEP

MODE IF LEFT ON AND NOT BEING USED; PRESS

ANY KEY AND WAIT A SECOND OR TWO TO

BRING IT OUT OF SLEEP MODE. THE LITHIUM-

POLYMER BATTERY IN THE ZAGGkeys PRO/PROplus

HAS NO MEMORY EFFECT AND MAY BE

CHARGED WHENEVER YOU WISH. WHEN NOT IN

USE FOR A PROLONGED PERIOD, IT IS

RECOMMENDED THAT YOU TURN OFF THE

KEYBOARD TO LENGTHEN BATTERY LIFE.

BATTERY

WHAT TO DO IF THE iPAD® DOES NOT RESPOND TO

THE ZAGGkeys PRO/PROplus.

A FEW THINGS CAN CAUSE THIS PROBLEM:

-DEAD BATTERY

-NEED TO PAIR THE ZAGGkeys PRO/PROplus

TO YOUR iPAD® AGAIN

-OLD iPAD® SOFTWARE

-PROBLEM WITH ZAGGkeys PRO/PROplus

PLEASE FOLLOW THE LIST BELOW TO FIND THE

PROBLEM AND APPROPRIATE SOLUTION.

1. RESTART YOUR iPAD® BY HOLDING DOWN THE

HOME AND POWER BUTTON SIMULTANEOUSLY

UNTIL IT RESETS. LET GO OF THE BUTTONS

WHEN YOU SEE THE APPLE® LOGO.

2. TURN OFF ZAGGkeys PRO/PROplus.

3. TURN THE ZAGGkeys PRO/PROplus ON. YOU

SHOULD SEE THE CAPS LOCK LIGHT TURN ON

FOR ABOUT 4 SECONDS AND THEN TURN OFF.

IF NOT, CHARGE YOUR ZAGGkeys PRO/PROplus.

4. AFTER CHARGING, SLIDE THE POWER SWITCH

ON. IF THE CAPS LOCK LIGHT DOES NOT

ILLUMINATE FOR A FEW SECONDS AND GO DIM,

YOU MAY HAVE A PROBLEM WITH YOUR ZAGGkeys

PRO/PROplus. PLEASE CONTACT CUSTOMER

SUPPORT AT ZAGG.COM TO RESOLVE THIS PROBLEM.

TROUBLESHOOTING

5. ON THE iPAD®, SELECT:

SETTINGS > GENERAL > BLUETOOTH > ON.

6. IF YOU SEE ZAGGkeys PRO/PROplus LISTED AS AN

“AVAILABLE DEVICE” ON YOUR iPAD®, CLICK

ON THE ARROW TO THE RIGHT AND CHOOSE

TO HAVE YOUR iPAD® “FORGET THE DEVICE.”

7. CLICK PAIR BUTTON ON ZAGGkeys PRO/PROplus

AND WATCH FOR THE CAPS LOCK LIGHT TO

FLASH.

8. YOU SHOULD SEE ZAGGkeys PRO/PROplus

LISTED AS AN “AVAILABLE DEVICE.”

9. SELECT ZAGGkeys PRO/PROplus BY TOUCHING

IT ON YOUR iPAD®.

10. YOUR ZAGGkeys PRO/PROplus SHOULD

NOW BE PAIRED.

11. IF YOUR iPAD® GIVES YOU AN ERROR MESSAGE,

REPEAT PROCESS AGAIN.

12. IF YOU STILL CAN’T GET YOUR ZAGGkeys

PRO/PROplus TO PAIR, IT IS POSSIBLE YOUR iPAD®

NEEDS TO HAVE ITS SOFTWARE UPDATED.

13. IF BACKLIGHTING IS NOT OPERATING: BATTERY

MAY NEED TO BE CHARGED AS BACKLIT KEYS

WILL NOT OPERATE WHEN BATTERY LIFE

FALLS BELOW 20%.
