ZALMAN CNPS7700 LED Manuale utente
* Please read before installation.
http://www.zalman.co.kr http://www.zalmanusa.com
Intel
Dual Core Pentium / Pentium 4
Socket 775 CPU
Grip (S-Type)
Grip (L-Type)
Inner Hole
Grip (L-Type)
Outer Hole
Intel Pentium 4
Socket 478 CPU
AMD Sempron/AMD64
(Athlon 64 X2/Opteron/Athlon 64)
Socket 754/939/940 CPU
CNPS7700 LED
(English version)
※
The specifications of any product may change without prior notice to improve performance.
1
Fan
Clip
Fan Fixing Screw
Grip (S-Type)
Grip (L-Type)
Fan Support Fixing Screw
Fan Support
FHS
1. Features
2. Specifications
3. Exploded Vie
1) Pure copper and/or pure aluminum ase materials ensure excellent heat dissipation.
2) Supports Intel Dual Core Pentium / Pentium 4 (Socket 775), Intel Pentium 4 (Socket 478), AMD Athlon
64 X2 Dual Core, Sempron / AMD64 (Socket 754/939/940) for road compati ility.
3) The large 120mm fan inside the FHS maximizes cooling performance y providing sufficient airflow
even at low fan speed.
4) The large 120mm fan provides air flow over a large area, cooling not only the CPU, ut the VGA card,
North ridge, FET, and RAM as well.
5) The high intensity red LEDs will operate with sufficient rightness even in low operating voltage.
6) The adjusta le fan speed controller (FAM MATE 2) ena les control of noise and fan performance.
2) FAN MATE 2
- Output Voltage : 5V ~11V 2%
- Power Consumption : 6W or lower
(Note 1) The maximum weight for a cooler is specified as 450g for Intel Socket 775/478 and AMD Socket
754/939/940. Special care should e taken when moving a computer equipped with a cooler
which exceeds the relevant weight limit. Zalman is not responsi le for any damage that occurs
when moving a computer.
(Note 2) The cooler fan operates at 2,300rpm if connected directly to the mother oard’s power connector
without the use of FAN MATE 2.
(Note 3) Noise measured 1m distance away from source.
1) ooler ( NPS7700 LED)
CNPS7700-AlCu LED CNPS7700-Cu LED
Model
Spec.
Materials
Weight
Thermal Resistance
Dimensions
Dissipation Area
Bearing Type
Fan Speed
Noise Level
Input Voltage
Pure copper and pure aluminum
600
(1)
0.19 ~ 0.28 ℃/W
918
(1)
0.17 ~ 0.24 ℃/W
136 (L) X 136 (W) X 67 (H) mm
3,268 ㎠
2 Ball-Bearing
1,000 ~ 2,000rpm ± 10%
2)
22.7 ~ 37.1dBA ± 10%
3)
5 ~ 12V
※
The specifications of any product may change without prior notice to improve performance.
2
❿
❾
❶
❸
❺
❹
❻
❽
❼
❷
Korean Patent No. 389257
Korean Patent Design No. 327440-3
Parents pending in over 20 nations around the world, including the USA, EU, and Japan
4. Patents
Precautions
1) Keep the product away from children.
2) Check to see that all components are present, and check the condition of the product and its components efore
installation. If there is any pro lem, contact the place of purchase for a replacement.
3) If excessive force is exerted on the fan, the fan may malfunction and result in damage to the product and/or the
computer.
4) Do not insert your finger into the fan while it is operating.
Disclaimer) Zalman Tech Co., Ltd. is not responsi le for any damages due to external causes, including ut not
limited to, improper use, pro lems with electrical power, accident, neglect, alteration, repair,
improper installation, or improper testing.
1) Common Components
❶
FHS Assem ly (CNPS7700 LED)
❷
Four (4) Grips (2 each for S-Type and L-Type)
❸
Four (4) Bolts (for installing the FHS)
❹
Thermal Grease
❺
Fan Speed Controller (FAN MATE 2)
❻
Dou le - sided Tape (for installing FAN MATE 2)
❼
Ca le for FAN MATE 2
❽
User’s Manual (in English and Korean)
5. Components
2) Components for Intel Dual Core Pentium/Intel
Pentium 4 (Socket 775)
❾
One (1) Clip Support for Socket 775
❿
One (1) Backplate for Socket 775
Four (4) Clip Support Fixing Bolts
3)
Components for Intel Pentium 4 (Socket 478)
Two (2) Clip Supports for Socket 478
4)
Components for AMD Sempron / AMD64 (Socket 754/939/940)
Two (2) Nipples
One (1) Backplate for AMD64
One (1) set of Washers
※
The specifications of any product may change without prior notice to improve performance.
3
6. Compatible CPUs
1) Intel Dual ore Pentium / Pentium 4 - Socket 775
All PUs conforming to Socket 775 platform
Caution)
①No components higher than 39mm (possi le examples :
PSU, graphics card, RAM etc.) should e present within
a 68mm radius from the center of the CPU.
②For more information, please visit Zalman’s we site
(http://www.zalman.co.kr) and click on the links of
"CNPS7700 Compati le Socket 775 Mother oards List".
2) Intel Pentium 4 - Socket 478
All PUs conforming to Socket 478 platform
Caution)
①No components higher than 39mm (possi le examples : PSU, graphics card, RAM etc.) should e present
within a 68mm radius from the center of the CPU.
②
For Socket 478, as shown in Figure 2, a mother oard that is not compliant with the "10.2mm Mother oard
component height restriction" standard, introduced y Intel, may create interference etween components
and the grip of CNPS7700 LED. Please do not install the CNPS7700 LED if this interference is o served.
③
For more information, please visit Zalman’s we site (http://www.zalman.co.kr) and click on the links of
"Compati ility etween CNPS7700 and Socket 478 Pentium 4 Mother oards".
3) AMD Sempron / AMD64 - Socket 754/939/940
All
PUs conforming to Socket 754/939/940 platform
Caution)
①No components higher than 39mm (possi le examples :
PSU, graphics card, RAM etc.) should e present within a
68mm radius from the center of the CPU.
②For more information, please visit Zalman’s we site
(http://www.zalman.co.kr) and refer to “CNPS7700
Compati le Socket 754/939/940 Mother oards List” link.
10.2mm Mother oard component height restriction
4mm
Grip
Mother oard
Component
Grip
Mother oard Component
Figure 1
ompatible
Figure 2
Not ompatible
※
The specifications of any product may change without prior notice to improve performance.
4
Clip Support Fixing Bolt
Socket Lever Hinge
Lever Slot
Lever Slot
Socket Lever
Clip Support for Socket 775
Mother oard
Backplate for Socket 775
Backplate Support
CPU (IHS)
Bolt Grip (S-Type)
Grip (S-Type)
Clip Support for
Socket 775
Socket
775
478
754/939/940
Gr p
S - Type
L - Type
L - Type
Hole
Hole
Inner Hole
Outer Hole
7. Installation
※
CNPS7700 LED must e used with a specific grip for
each CPU socket. Refer to the ta le on the right
to choose the correct grip.
1) Intel Dual ore Pentium/Intel Pentium 4 - Socket 775
①①Installation of lip Support for Socket 775
Align the clip support for socket 775 and the ackplate for socket 775 with the mounting holes on the mother oard
and fasten them together using the clip support fixing olts. The lever slot on the clip support should e properly
oriented on the hinged side of the socket lever when installing.
※The ackplate support is used for the convenience of installation. You can remove it if it is not deemed necessary.
②②Thermal Grease Application
Clear off particles and residue from the top of the
CPU then spread a generous amount of the included
thermal grease thoroughly on top of the CPU.
※Unlike the flat-milled ase of the FHS, the top surface of the LGA775 CPU may have minute dips and peaks
causing pockets of non-contact etween the FHS and CPU. Please apply a generous amount of thermal grease
on the top of the CPU.
③③Installation of Grips and Bolts
Interlock the S-type grips with the clip. Insert the two
olts into the holes of the grips.
④④FHS Placement
Set the FHS at the center of the CPU. Screw the olts
in slightly, then tighten each olt a few turns at a time while
alternating etween the two until the Grips are completely
pressed against the Clip Support.
⑤⑤onnect Power (Use FAN MATE 2)
◆Please refer to FAN MATE 2 Installation and Usage on page 7.
Thermal Grease
※
The specifications of any product may change without prior notice to improve performance.
5
②②
Installation of lip Supports for Socket 478
Install the clip supports for socket 478 on oth sides
of the retention guide as shown in the diagram.
③③Installation of Grips and Bolts
Interlock the L-type grips with the clip. Insert the two olts
into the inner holes of the grips.
④④
FHS Placement
Set the FHS at the center of the CPU. Screw the olts
in slightly, and then tighten each olt a few turns at a
time while alternating etween the two until the Grips
are completely pressed against the Clip Support.
Retention Guide
Clip Support for Socket 478
⑤⑤onnect Power (Use FAN MATE 2)
◆Please refer to FAN MATE 2 Installation and Usage on page 7.
Bolt Grip (L-Type)
Inner Hole
Grip (L-Type)
Clip Support for
Socket 478
2) Intel Pentium 4 - Socket 478
①①
Thermal Grease Application
Clear off particles and residue from the top of the
CPU then spread a thin layer of the included thermal
grease thoroughly on top of the CPU.
CPU (IHS)
Thermal Grease
※
The specifications of any product may change without prior notice to improve performance.
6
①①
Nipple Installation
Place a small washer on the mother oard. Then, put a nipple over it and fasten the nipple until the
Backplate for AMD64 is firmly attached to the mother oard on the opposite side of the CPU.
* A Retention Guide is not necessary for installing CNPS7700 LED on Socket 754/939/940.
③③Installation of Grips and Bolts
Interlock the L-Type grips with the clip. Insert the two olts
into the outer holes of the grips.
④④
FHS Placement
Set the FHS at the center of the CPU. Screw the olts
in slightly, and then tighten each olt a few turns at a
time while alternating etween the two until the Grips
are completely pressed against the Nipples.
⑤⑤onnect Power (Use FAN MATE 2)
◆Please refer to FAN MATE 2 Installation and Usage on page 7.
②②
Thermal Grease Application
Clear off particles and residue from the top of the
CPU then spread a thin layer of the included thermal
grease thoroughly on top of the CPU.
Bolt Grip (L-Type)
Outer Hole
Grip (L-Type)
Nipple
3) AMD Sempron/AMD64 - Socket 754/939/940
CPU (Lid)
Thermal Grease
Backplate for AMD64
Nipple
Mother oard
Small Washer
※
The specifications of any product may change without prior notice to improve performance.
7
Fan Connector
(CNPS7700 LED)
Mother oard
Dou le-sided Tape
FAN MATE 2
6-Pin Connector
※FAN MATE 2 Installation and Usage
1) Installing FAN MATE 2 on the Inside of the System 2) Installing FAN MATE 2 on the Outside of the System
Connect the appropriate 3-pin connector on the
ca le to the mother oard fan header and the
CNPS7700 LED’s fan connector.
Pull the 6-pin connector out of the system through
the ack and connect it to FAN MATE 2, which
should e installed on the case using the included
dou le-sided tape.
◆
Fan speed can e controlled with the use of FAN MATE2. Turning the speed control kno in the clockwise
direction will increase the fan speed, and turning the speed control kno in the counter-clockwise direction will
decrease the fan speed.
Note) FAN MATE 2 has een specifically designed for the fan of this product. Zalman Tech Co., Ltd. is not
responsi le for any damage to systems or CPUs caused y using it with other types of fans.
8. Notes on Usage
1) hecking PU ompatibility
Please refer to “Compati le CPUs” on page 3 to confirm that your CPU is compati le efore using the CPU cooler.
2) autions During Booting
When ooting the computer, it may automatically power down after an alarm sound y a system
monitoring program to indicate that the CPU fan is rotating slowly. If this happens, turn the speed
control kno fully clockwise to increase the fan speed. Then set ‘CPU Fan Detected’ to ‘Disa led’ in
BIOS settings, or set the slowest rotational speed of the CPU fan in the system monitoring program to
less than or equal to 900rpm.
Note) Some mother oards do not oot if the rotational speed of the CPU fan is elow a certain
rpm. If the BIOS settings are updated, Silent Mode can e used. For more information on
updating your BIOS, please refer to your mother oard manufacturer's we site. Disa ling
CPU fan speed detection in BIOS settings does not affect computer performance.
3) Overclocking
The fan should e set to Normal Mode if Overclocking.
(Zalman Tech Co., Ltd. is not responsi le for any damage resulting from CPU Overclocking.)
※
The specifications of any product may change without prior notice to improve performance.
8
11.
Home Theatre PC Enclosures
TNN Computer Enclosures are the world’s first environment-friendly noiseless computer enclosures
that operate without the use of a fans. TNN Computer Enclosures use the aluminum enclosure itself
as a heatsink. They are ideal for environments that require silence, as well as for home theatre
systems and multi-media systems.
The HD160 is designed for ultra quiet home theatre
PC operation, utilizing optimized ventilation and
anti-vi ration reinforcements, making it ideal for
environments that require silence such as living
rooms, edrooms, educational facilities, and offices.
For more information, please visit our website.
10.
TNN (Totally No Noise) Computer Enclosures
TNN 300 TNN 500AF
HD160
The use of Zalman's Noiseless Power Supplies, Fanless North ridge Coolers, Heatpipe HDD
Coolers, Case Fans, VGA Coolers and Multi-Fan Controllers will allow you to maintain sta le
performance and a noiseless environment.
9. Zalman Computer Noise Prevention System
Noiseless Power Supply Fanless Northbridge Cooler Heatpipe HDD Cooler
Noiseless Case Fan Ultra Quiet VGA Cooler Multi - Fan Controller
Altri manuali per CNPS7700 LED
4
Questo manuale è adatto per i seguenti modelli
2
Altri manuali ZALMAN Hardware per computer
ZALMAN
ZALMAN CNPS5100-Al Manuale utente
ZALMAN
ZALMAN RESERATOR1 Manuale utente
ZALMAN
ZALMAN CNPS10X Optima (2011) Manuale utente
ZALMAN
ZALMAN CNPS9700 LED Manuale utente
ZALMAN
ZALMAN CNPS12X Manuale utente
ZALMAN
ZALMAN CNPS2005-Plus Manuale utente
ZALMAN
ZALMAN Optima CNPS8X Manuale utente
ZALMAN
ZALMAN CNPS9800 MAX Manuale utente
ZALMAN
ZALMAN ZM-2HC2 Manuale utente
ZALMAN
ZALMAN RESERATOR1 V2 Guida rapida
ZALMAN
ZALMAN Z9 series Manuale utente
ZALMAN
ZALMAN CNPS10X Extreme Manuale utente
ZALMAN
ZALMAN Reserator 5 Manuale utente
ZALMAN
ZALMAN CNPS7000C-Cu/AICu Manuale utente
ZALMAN
ZALMAN CNPS9900 Max Manuale utente
ZALMAN
ZALMAN CNPS7000 Manuale utente
ZALMAN
ZALMAN ZM-WB5 Plus Manuale utente
ZALMAN
ZALMAN Extreme Gaming VGA Cooler GV1000 Manuale utente
ZALMAN
ZALMAN CNPS2X Manuale utente
ZALMAN
ZALMAN ZM80D-HP Manuale utente
Manuali Hardware per computer popolari di altre marche
EMC2
EMC2 VNX Series Manuale del proprietario
Panasonic
Panasonic DV0PM20105 Manuale utente
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuale utente
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuale utente
Raidon
Raidon iT2300 Manuale utente
National Instruments
National Instruments PXI-8186 Manuale utente
