Zanussi 200470 Manuale utente

ZANUSSI

P R O F E S S I O N A L

REFRIGERATED BASE

N 900

Model 200470

Supply voltage 230 V, 1N, 50

Net weight - kg. 114

installed-electric 0.4

Power - kW

Refrigeration power - W 410

Refrigerant quantity - g. 400

Refrigerant type R404a

N° defrost in 24 hrs. 4/10'

N° of drawers 2

Min/Max internal humidity - % 75/90%

height adjustment 50

height 600

depth 900

width 1200

External dimensions - mm

Gross capacity (D.I.N. 8952) - l. 225

Power supply Electric

NVRE1200

200470

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION

N 900: a range of over 150 models

for the professional caterer designed

to guarantee the highest level of

performance, reliability, energy

saving, safety standards and

ergonomic operation. These

concepts are reflected in the total

modularity of the range that ensures

innumerable configurations, either

free-standing, bridged or cantilever.

N900 demonstrates how advanced

technology can satisfy the needs of

the professional caterer.

The refrigerated base units detailed

on this sheet complete the N900

range and is ideal for storing food at

the various cooking stages.

FUNCTIONAL AND

CONSTRUCTION

FEATURES

� Front and side panels in stainless

steel with Scotch Brite finish.

� The refrigerated base has two

large stainless steel drawers on

telescopic runners, thermostat,

defrost indicator light and ON/OFF

switch. The internal temperature

ranges from -2° to +10°C and the

compressor unit is built-in.

� The two large drawers have front

panels with stainless steel handles.

� R404a Refrigerant.

� Feet in stainless steel 50 mm

adjustables in height.

� All top models can be easily

mounted on the refrigerated base.

BACX4 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

SUPPORT FOR "BRIDGE" SYSTEM 800 MM 206137

SUPPORT FOR "BRIDGE" SYSTEM 400 MM 206154

SUPPORT FOR "BRIDGE" SYSTEM 1600 MM 206141

SUPPORT FOR "BRIDGE" SYSTEM 1400 MM 206140

SUPPORT FOR "BRIDGE" SYSTEM 1200 MM 206139

SUPPORT FOR "BRIDGE" SYSTEM 1000 MM 206138

PAIR OF COVERING STRIPS FOR END ELEMENTS 206234

FRONTAL KICKING STRIP 800 MM 206176

FRONTAL KICKING STRIP 400 MM 206175

FRONTAL KICKING STRIP 200 MM 206174

FRONTAL KICKING STRIP 1600 MM 206179

FRONTAL KICKING STRIP 1200 MM 206178

FRONTAL KICKING STRIP 1000 MM 206177

FRONT.KICK.STRIP F.CONCRETE INST.800 MM 206148

FRONT.KICK.STRIP F.CONCRETE INST.400 MM 206147

FRONT.KICK.STRIP F.CONCRETE INST.200 MM 206146

FRONT.KICK.STRIP F.CONCRETE INST.1600 MM 206152

FRONT.KICK.STRIP F.CONCRETE INST.1200 MM 206151

FRONT.KICK.STRIP F.CONCRETE INST.1000 MM 206150

4 WHEELS (2 WITH BRAKE) 206188

4 FEET FOR CONCRETE INSTALLATION 206210

2 SIDE KICKING STRIPS F.CONCRETE INSTAL. 206157

2 SIDE KICKING STRIPS 206180

2 PANELS FOR SERVICE DUCT (BACK TO BACK) 206202

NVRE1200

200470

ACCESSORIES MODELS

OPTIONAL ACCESSORIES

I - Electrical connection 230 V, 1N, 50

C - Water drain 1/2"

NVRE1200

200470

LEGEND

200470

439

1198

130

70 1057 70

894 304 783.6

55.8 100

829.6

674

670

470200

659
