Zonet KVM3332 Manuale utente

NOTE: All hardware must power-OFF before and during hardware installation.

1. Connect all KVM cables to the KVM switch and computers.

2. Connect monitor, keyboard, mouse, speaker and microphone to the KVM switch’s

console port.

3. Power-ON all hardware.

4. Do not switch between computers during boot-up process.

5. Hardware installation is now completed. Your KVM3332 is now ready to operate.

zOne KVM3332

zOne Installation Guide

zTwo sets of KVM w/Audio cable

Monitor: To the female VGA (HDDB-15) console port

Speaker: To the top audio console port next to the speaker symbol

Microphone: To the bottom audio console port next to the microphone symbol

USB Mouse: To the right USB female console port with the Mouse symbol

USB Keyboard: To the left female USB console port with the keyboard symbol

NOTE:

1Use USB mouse and USB keyboard for KVM3332 USB port only, other USB devices are

not working while plug in KVM3332 USB ports.

2USB mouse and USB keyboard must correctly plug in the corresponding port, otherwise

hot key function will no response.

Use “Select” button only to switch PC 1 and PC 2.

NOTE:

Other push buttons (PC1/PC2/Power) are no function.

PC 1: [Steady ON] Computer and all KVM cables are securely connected to PC 1

port. The computer connected on PC 1 port is power-ON and selected.

[Off] Computer connected to PC 1 port is power-OFF and/or KVM cables are

not connected

PC 2: [Steady ON] Computer and all KVM cables are securely connected to PC 2

port. The computer connected on PC 2 port is power-ON and selected.

[Off] Computer connected to PC 2 port is power-OFF and/or KVM cables are

not connected

Select: [Steady ON] All cables are connected properly and KVM3332 is receiving

power from PC 1 and PC 2

Power: [Steady ON] All cables are connected properly and KVM3332 is receiving

power from PC 1 and PC 2

KVM3332 supports 4 different “Hot Key” modes in order to be compatible with different

keyboards.

1. [Ctrl] + [Shift] mode (Left-hand side) – default settings

[Ctrl] ++ [Ctrl] Go to next PC

[Ctrl] ++ [Shift] + 1 Go to PC 1

[Ctrl] ++ [Shift] + 2 Go to PC 2

[Ctrl] ++ [Shift] + Îor ÐGo to the next PC (Ex: 1 Î2 Î1)

[Ctrl] ++ [Shift] + Íor ÏGo to the previous PC (Ex: 2 Î1 Î2)

[Ctrl] ++ [Shift] + B Turn ON/OFF beep sound

[Ctrl] ++ [Shift] + S Enter Auto-Scan mode (“ESC” to cancel)

[Ctrl] ++ [Shift] + S + n Set Auto-Scan interval (“ESC” to cancel)

[Ctrl] ++ [Shift] + [Caps Lock] Change to [Caps Lock] mode

[Ctrl] ++ [Shift] + [Num Lock] Change to [Num Lock] mode

[Ctrl] ++ [Shift] + [Scroll Lock] Change to [Scroll Lock] mode

2. [Scroll Lock] mode

[Scroll Lock] ++ [Scroll Lock] + 1 Go to PC 1

[Scroll Lock] ++ [Scroll Lock] + 2 Go to PC 2

[Scroll Lock] ++ [Scroll Lock] + Îor ÐGo to the next PC (Ex: 1 Î2 Î1)

[Scroll Lock] ++ [Scroll Lock] + Íor ÏGo to the previous PC (Ex: 2 Î1 Î2)

[Scroll Lock] ++ [Scroll Lock] + B Turn ON/OFF beep sound

[Scroll Lock] ++ [Scroll Lock] + S Enter Auto-Scan mode (“ESC” to cancel)

[Scroll Lock] ++ [Scroll Lock] + S + n Set Auto-Scan interval (“ESC” to cancel)

[Scroll Lock] ++ [Scroll Lock] + [Caps Lock]

Change to [Caps Lock] mode

[Scroll Lock] ++ [Scroll Lock] + [Num Lock] Change to [Num Lock] mode

[Scroll Lock] ++ [Scroll Lock] + [Ctrl] Change to [Ctrl]+[Shift] mode

NOTE:

1Command key, [Scroll Lock], [Caps Lock], [Num Lock] & [Ctrl]+[Shift], MUST

press twice within 2 seconds.

2The command will automatically cancel in 5 seconds if nothing is entered after the

command key.

3Auto-Scan Interval: “n” = number from 1 to 9.

【n】= number Interval

1 5 seconds

2 10 seconds

3 15 seconds

4 20 seconds

5 25 seconds

6 30 seconds

7 35 seconds

8 40 seconds

9 60 seconds

(

n’

’t

)

3. [Caps Lock] mode

[Caps Lock] ++ [Caps Lock] + 1 Go to PC 1

[Caps Lock] ++ [Caps Lock] + 2 Go to PC 2

[Caps Lock] ++ [Caps Lock] + Îor ÐGo to the next PC (Ex: 1 Î2 Î1)

[Caps Lock] ++ [Caps Lock] + Íor ÏGo to the previous PC (Ex: 2 Î1 Î2)

[Caps Lock] ++ [Caps Lock] + B Turn ON/OFF beep sound

[Caps Lock] ++ [Caps Lock] + S Enter Auto-Scan mode (“ESC” to cancel)

[Caps Lock] ++ [Caps Lock] + S + n Set Auto-Scan interval (“ESC” to cancel)

[Caps Lock] ++ [Caps Lock] + [Scroll Lock] Change to [Scroll Lock] mode

[Caps Lock] ++ [Caps Lock] + [Num Lock] Change to [Num Lock] mode

[Caps Lock] ++ [Caps Lock] + [Ctrl] Change to [Ctrl]+[Shift] mode

4. [Num Lock] mode

[Num Lock] ++ [Num Lock] + 1 Go to PC 1

[Num Lock] ++ [Num Lock] + 2 Go to PC 2

[Num Lock] ++ [Num Lock] + Îor ÐGo to the next PC (Ex: 1 Î2 Î1)

[Num Lock] ++ [Num Lock] + Íor ÏGo to the previous PC (Ex: 2 Î1 Î2)

[Num Lock] ++ [Num Lock] + B Turn ON/OFF beep sound

[Num Lock] ++ [Num Lock] + S Enter Auto-Scan mode (“ESC” to cancel)

[Num Lock] ++ [Num Lock] + S + n Set Auto-Scan interval (“ESC” to cancel)

[Num Lock] ++ [Num Lock] + [Caps Lock] Change to [Caps Lock] mode

[Num Lock] ++ [Num Lock] + [Scroll Lock] Change to [Scroll Lock] mode

[Num Lock] ++ [Num Lock] + [Ctrl] Change to [Ctrl]+[Shift] mode

NOTE:

1Command key, [Scroll Lock], [Caps Lock], [Num Lock] & [Ctrl]+[Shift], MUST

press twice within 2 seconds.

2The command will automatically cancel in 5 seconds if nothing is entered after the

command key.

3Auto-Scan Interval: “n” = number from 1 to 9.

【n】= number Interval

1 5 seconds

2 10 seconds

3 15 seconds

4 20 seconds

5 25 seconds

6 30 seconds

7 35 seconds

8 40 seconds

9 60 seconds

1. Make sure all KVM cables are connected securely, properly and well-seated.

2. Suggested to label all KVM cables accordingly to avoid confusion.

3. Do not move or press any mouse buttons when switch between PC ports.

4. Do not move or press any keys on keyboard when switch between PC ports. It may

cause keyboard error.

5. What should I do if keyboard is not working or keyboard error during computer boot-up

process?

a. Make sure you are using 101-, 102-, and 104- keyboards.

b. Check if the keyboard functions properly when connects to computer directly.

6. What should I do if mouse is not detected or not working properly?

a. Check if the mouse functions properly when connects to computer directly.
