Zte E3330 Manuale utente

E3330

Wi-Fi6 Wireless Router

User Manual

Step 1-Install the Device

1

Broadband Internet Access

Network Cable Jack

Connect to

the WAN port

Power Outlet

Alternative

If no Internet access device is

available, connect the network

cable to the broadband network

port on the wall.

If an Internet access device

(modem or optical ber modem)

is available, connect the network

cable the LAN port of the

modem.

2.5GE-WAN/LAN1-1G LAN2 LAN3 RESET POWER

MESH

WPS

Uplink CPE Access

Step 2-Add the Router

Download and install ZLife Lite. For iOS, download

ZLife Lite on App Store. For Android, download it on

Google Play.

Tap Add device.

2

Tap Wi-Fi Router.

Connect the WAN port of the router to the broadband

port. Tap Next.

3

NOTE:

If the operating system of your mobile phone is

Android, you must connect to Wi-Fi manually after

scanning the QR code. If you do not want to enter the

password manually, tap copy the password. This opera-

tion arises from Android rather than ZLife Lite because

of Android security requirements.

Scan the QR code found at the bottom of the router.

If no QR code is present, enter your wireless account

and password.

4

To perform more advanced congurations, go to the

web page for router management. For the login

address and the default username and password, see

the label at the bottom of the router.

NOTE:

After the router is added successfully, the Congure

network screen is displayed. Tap Bind immediately.

After the router is added successfully, the indicator is

green and steady.

LED indicator/WPS

5

Step 3- Set Up a Mesh Network

NOTE:

Step 3 is required only if you want to deploy multiple

E3330 routers.

Method 1: Use ZLife Lite app for connection

1. Make sure the router you have just congured is connected

to the Internet.

2. After the new router is powered on, follow the instructions

given by the app.

3. After the new router is connected to the existing router, the

LED of the new router will turn solid blue.

Method 2: Use WPS key for connection

1. Make sure the router you have just congured is connected

to the Internet.

2. Place a new router close to the existing router, and then

power it on.

3. Press the WPS buttons on the routers until the LEDs blink

green. The time between pressing the two WPS buttons

should be less than 1 minute.

4. The pairing process may take up to 2 minutes. When pairing

is complete, the LED of the new router will turn solid blue.

5. Now you can move your new router to your intended

location.

6

Troubleshooting

The Power indicator on the front panel is o after the

power button is pressed.

Power switch does not turn on.

The power adapter is not correctly connected to the device.

Be sure to use the power adapter supplied with the device.

Unable to connect to the network.

Check that the Ethernet cable is correctly connected to the

WAN interface and the Ethernet cable is correctly connected

to the LAN interface.

Check that the WAN indicator on the front panel is on and

the Internet indicator on the front panel is solid green or

ashing green.

Restore the factory default settings.

After the power is on, use a needle to press the button for over

5 seconds to restore the default factory settings.

7

Postcode: 518057

SJ-20220322181146-001

2022-10-13(R1.0)
