Zte MU5001 Manuale utente
1
ZTE MU5001
5G Router
User Manual
Benutzerhanbuch
Version 1
2
CONTENTS
Contents 2
What’sin the box 3
teChniCal speCifiCation 4
GettinG familiar With your router 5
hoW to install the battery 6
hoW to insert the nano-sim 7
turn your 5G router on 8
Computer ConneCtion via usb type-C9
touCh sCreen iCons 10
start-up Guide: details required 11
pC start-up Guide: the proCess 12
mobile deviCe start-up Guide: the proCess 13
trouble shootinG / fehlerbehebunG 14
soinstallieren sie die batterie 15
soleGen sie die nano-sim ein 15
sChalten sie ihren 5G-router ein 16
ComputerverbindunG über usb type-C16
touChsCreen-symbole 17
startanleitunG: anGaben erforderliCh 18
pC-starthilfe: der prozess 19
leitfaden zur inbetriebnahme mobiler Geräte: der prozess 19
Please read the manual carefully.
If further support is required please contact us
United Kingdom enquiries
UK Website: https://falcontechnology.co.uk/
European Website : https://falcontechnology.eu
Email: support@falcontechnology.co.uk
Telephone: +44 1928 759 239
Germany Enquiries:
Email: info@easynd24.de
Hotline: +49 2688 988181
Congratulations on the purchase of your new
FALCON 5G Router
3
WHAT’S IN THE BOX
5G Router
USB Type-c
Cable
User
Manual
*The item colours and shapes may vary depending on the models.
4
TECHNICAL SPECIFICATION
Product Dimensions 13.3 x 7.3 x 1.85 cm; 200g
Batteries 1x Li-ION Polymer battery required.
(included)
Item model number MU5001
Colour Black
Wireless Type 802.11n, 802.11b, 802.11a, 802.11g,
802.11ac
Battery (in hours) 8 Hours charge with 8 hours use
Are Batteries
Included
Yes
Lithium Battery
Energy Content
4500 Milliamp Hours (mAh)
Lithium Battery
Packaging
Batteries contained in equipment
Number Of Lithium
Ion Cells
1
5
GETTING FAMILIAR WITH YOUR ROUTER
1External Antenna Ports
2Power Button
3Nano SIM Slot
4Touch Screen
5Charge/USB type-C jack
6LAN Port
12
3
4
FALCON
5
6
6
HOW TO INSTALL THE BATTERY
1
2
1. Pull back the cover to open. Note the nail gap on one
edge.
2. Insert the battery (found in box)
7
HOW TO INSERT THE NANOSIM
1
2
1. Insert the tip of a tray eject tool into the hole.
2. Pull out the tray and place the nano-SIM on the tray.
Slide the tray back in place with the provider logo facing up
(device facing screen down).
*Tray eject tool not included
8
TURN YOUR 5G ROUTER ON
*Note: If the battery is extremely low, you may be unable to power on the
device. Please charge your device rst.
Press and hold the power button until the screen lights
up. Once you have setup the device then in future it will
connect automatically.
9
COMPUTER CONNECTION VIA USB TYPEC
USB Type-C cable: Connect the cable to your computer to
browse the internet.
FALCON
10
TOUCH SCREEN ICONS
Network type: 4/5G
Signal
Strength
Wi:
- Users
connected
- Touch to
congure
settings
Battery Percentage
Settings:
- Connection by USB
- Connection by ethernet
cable
- Touch to congure device
settings
Date Usage*
*Usage shown for
demonstration
purposes
*Messages:
Not shown in
the image but
its accessible by
clicking on “settings”
then“messages”
*
Apply light pressure to the touch screen. Hold for a few second
to unlock.
