ZyXEL Communications G-210H Manuale utente

G-210H

802.11b/g Wireless USB Adapter

Quick Start Guide

Version 1.00

4/2008

Edition 2

G-210H

Overview

The G-210H is a wireless network USB adapter for your

computer. See page 21 for a list of system requirements.

1 Install the Software

"Install the software from the CD before you

insert the G-210H. Do not insert the G-210H yet.

1.1 Windows

1Insert the included CD into the CD-ROM drive on your

computer.

2When the following screen displays, click Setup to install

the ZyXEL utility and driver.

G-210H

VIf the screen does not display, locate and

double-click autorun.exe on the CD.

3In Windows

Vista, if the

following screen

displays, click

Allow to

continue.

4The following screen displays. Click Yes.

G-210H

5In Windows Vista, if the following screen displays, click

Install this driver software anyway.

6Select Driver and Utility to install both ZyXEL utility and

driver on your computer. If you are using Windows XP or

Vista to manage your wireless network, you do not have to

install the Utility.

G-210H

7Click Next to accept the default file location or click

Browse to select an alternate folder.

8When the following screen displays, click Finish to

complete the software installation and restart your

computer.

1.2 Macintosh

Screen shots for Macintosh 10.4 are shown in the following

procedure unless otherwise specified. The screens on your

computer may differ slightly from the screens shown here

depending on the version of your operating system.

1Close all programs and applications.

2Insert the included CD into the CD-ROM drive. An icon for

the CD appears.

G-210H

3Double-click the CD's icon.

4Double-click the Mac Driver

folder.

5Double-click the .dmg file.

6Double-click your Macintosh OS’s driver folder.

G-210H

7Double-click ZyXEL_G-210H_MacPkg_Install.pkg to begin

the installation procedure.

8A welcome screen appears. Click Continue.

9You then see the Select a Destination screen, select a

destination drive and click Continue.

G-210H

10 Click Install.

11 In Mac OS 10.3, you then see a screen telling you that you

must restart the computer after the installation completes.

Click Continue Installation. The driver will automatically

install.

G-210H

12 Click Restart to reboot your computer and complete the

driver installation.

13 Go to section 3.4 on page 19 to set up your wireless

connection.

2 Install the Hardware

"Do not install the hardware until you have

installed the software from the CD.

1Locate an available USB port on the computer.

2Remove the protective cap to expose the USB connector.

Insert the G-210H to an available USB port on the

computer. The G-210H's lights turn on if it is properly

inserted.

G-210H

VIf the G-210H’s power ( ) and link ( ) LEDs

are not on after you have installed the software

and the G-210H, make sure the G-210H is

properly inserted.

3 Connect to a Wireless Network

After you install the ZyXEL utility and insert the G-210H,

an icon appears in the system tray (typically at the

bottom of the desktop).

VIf the icon does not display, uninstall and re-

install the ZyXEL utility. See the User’s Guide

for how to uninstall the utility.

The G-210H automatically searches for any available

network(s) and connects to a wireless network without

security enabled. However, this wireless network may not be

connected to the Internet.

1Double-click the icon.
