ZyXEL Communications PLA-402 V2 Manuale utente

Taking Advantage of Home Cable Lines

Benefits

LAN Extension through Coaxial Outlets

ZyXEL HomePlug PLA402 v2 is an access extension solution allowing your

house to be completely networked using the existing powerline or coaxial

cabling. Simply connect the PLA402 v2 to an existing coaxial outlet, power

up the unit and it transforms the existing powerlines or cables into a

house-wide network with no need for additional wiring. It’s the easiest way

to extend the network connection from your home broadband router to

every corner in the house.

Data Rates of Up to 200 Mbps

The PLA402 v2 is an access extension solution to have your house

completely networked with existing powerlines.Thanks to the advanced

HomePlug AV Technology, the PLA402 v2 is capable of transmitting data at

up to 200 Mbps. It allows you to share network resources and enjoy

Internet access through secure high-speed data connection over the

house powerlines you already have.

High Speed and QoS for High Definition Video

The inherent advanced QoS features empower the HomePlug AV Series to

become ideal access tools for service providers to deliver “triple-play”

multimedia services such as high-quality digital video streams, high-speed

Internet access,and voice services.

ˍġ

Simultaneous Ethernet, Coaxial and Power Connections

for Applications

ˍġ

Data Transmission Rates of Up to 200 Mbps over the

Powerline

ˍġ

Network Protection with Advanced 128-bit AES Security

ˍġ

HomePlug AV Compliant

ˍġ

Instant HomePlug Encrypt Button to Secure the

Powerline Network

ˍġ

Multi-colored LED Indicating Data Transmission Rates

over the Powerline

MEPLU

Powerline Hybrid Adapter

PLA402 v2

Advanced 128-bit AES Security

With the 128-bit Data Encryption Security (AES) feature, the PLA402 v2 provides secure network connection

for Internet access and network resource sharing. Just enjoy fast Internet surfing experience and secure file

transfer, and leave the sweats to the PLA402 v2.

System Specifications

•

Sta

omeP

ug AV 200 M

ps comp

iance Data Rat

•

ower Line Networ

Supports up to 16 (Tone Map) PL- devices

ommunicating on a sing

e networ

•

ation:

OFDM S

mbol Modulation, Supports QAM

024/256/64/16, DQPSK, DBPSK an

ROBO Carrier

ation sc

eme

•

requenc

Band: 1.7 MHz ~ 30 MHz

•

overage Area:up to 300 meters

•

Security

128 bit AES encr

ption

Encr

ption

utto

Hardware Specifications

• Interface: 10/100Mbps Ethernet port with

MDI/MDIX

• One Power Input: 100-240 VAC,50 ~ 60 Hz

• LED Display on Top-Case

- PWR

- Powerline Link, Activity, and Throughput Indicator

- Ethernet Link and Activity

Physical Specifications

• Dimensions: 112 (W) x 106 (D) x 28.5 (H) mm

• Weight: 185 g

Environmental Specifications

Operation Environment

• Temperature: 0ºC ~ 40ºC

• Humidity: 20% ~ 95% RH

Storage Environment

• Temperature: -20ºC ~ 60ºC

• Humidity: 20% ~ 95% RH

Certification

• Safety: UL, cUL, LVD

• EMI: CE, FCC part 15B

• HomePlug Certification: HomePlugAV

Specifications

Powerline Hybrid Adapter

PLA402 v2

For more product information, visit us on the web at www.ZyXEL.com

65-100-402003B 01/08

product names, or trademarks mentioned are the property of their respective owners.All specifications are subject to change without notice.

Powerline

Adapter

Gaming

Internet 1

Media

Player

3GamingGaming

r L

ble

net

HDTV

Application Diagram
