ZyXEL Communications N220 - Manuale utente

USB wireless network adapter

Easy Setup Guide

N220

Quick Start Guide x 1 Support CD x 1

USB cable x 1

Contents:

N220 adapter x 1

Step 1

Overview

The N220 is a USB wireless network adapter for your computer. The N220 is compatible

with WPS (Wi-Fi Protected Setup).

A

B

The following table describes the N220

LABEL DESCRIPTION

ALED and also a WPS button

B USB connector

Step 2

Install the Software

1. Insert the included CD into the CD-ROM drive

on your computer

3. Follow the on-screen instructions to install

both the ZyXEL utility and the device driver.

Alternatively, install the driver only and use

Windows WLAN conguration tool to congure

the N220 with Windows XP, Windows Vista

or Windows 7. See the User's Guide for more

information.

4. You will need to restart your computer after

installing the ZyXEL utility and driver. Make sure

you have saved your work before continuing.

2. When the following screen displays, click Next

to install the ZyXEL utility and driver.

If the screen does not display, locate and double-

click an .exe le in the Setup folder on the CD.

Step 3

Install the Hardware

1. Locate an available USB port on the computer.

2. Insert the N220 into an available

USB port on the computer

The N220's Dual-function LED

and WPS activation button turns

on if it is properly inserted.

Never bend, twist or force the N220 into the port. If there is not

enough space to attach the N220, use the included USB cable.

when inserting indicate the LED/button goes up (in a system where

the USB port is horizontal) or toward the user (in a system where the

USB port is vertical)

Note:

Step 4

Connect with WPS

To connect wirelessly to an Access Point (AP) with the N220, use the WPS button.

1. Place a WPS-enabled AP within range of the N220.

2. Press the WPS activation button on both devices for

between one and three seconds. It doesn't matter

which button is pressed rst. You must press the

second button within two minutes of pressing the rst

one. The LED ashes steadily once they are connected.

See the User's Guide for information about how to manually connect to a wireless

device using the ZyXEL utility.
