ZyXEL Communications P-871M Manuale utente

High-Speed VDSL Point-to-Point Solution

Benefits

Ultra-high Data Rates of Up to 80/40 Mbps

With downstream bandwidths of up to 80 Mbps and 40 Mbps upstream,

ZyXEL P-871M offers higher data transfer rates and provides larger

bandwidths than traditional ADSL gateways.The expanded bandwidth

allows small-to-medium business users to enjoy quality symmetric and

asymmetric applications like video conventions and file exchange

services, etc. that were previously unavailable.

Operations over Existing Copper Wires and

Co-existence with POTS/ISDN Services

As VDSL provides much higher bandwidth than other DSL technologies,

it enables services providers to offer a variety of value-added services

ranging from broadband Internet access to bandwidth-consuming video

applications over the existing telephone wires.

The P-871M can be implemented quickly, even if there is only one phone

line; and users can also keep the current POTS or ISDN services while

adding new VDSL services.

Revenue Generation with Minimum Installation Cost

Most small business users need simple and quick connectivity with VDSL

technology to easily take advantage of the high speed. A pair of P-871M

allows service providers to offer point-to-point services such as building-

to-building or office-to-office connections,or to serve buildings

containing only a small number of subscribers easily with no additional

configuration required.

With just simple plug-and-play, users can set one P-871M in the pair as

the CO and the other as the CPE modem to support high-bandwidth

services as new revenues are generated with minimum installation time

and expense.

Ł

IP-based VDSL2 High-Speed Internet Access

Ł

High Date Rates of Up to 80/40 Mbps

Ł

Ethernet Distance Extension

Ł

Selectable CO/CPE Modes via a Hardware Switch

VDSL Point-to-Point Modem

P-871M

VDSL

System Specifications

DSL Compliance

•

ex Met

: DM

•

ernet over VDSL

•

ITU.T G.993.1 VDS

DSL1

•

ITU.T G.993.2 V

2 VDSL2 (Pr

12a)

Profile 8a, 12

•

Band Plan

n 997 and 9

d 998 support

•

upport 3/4

/4 ban

ands and U0 band

•

m and

pport Up t

Supp

p to

to 80 Mbps downstream

bps

40 Mbp

ps upstre

eam

•

ctab

Select

ble CO or C

CPE mode

etwork Pro

Net

rotocol

•

net

IEEE 802.3 10

0Base-T Et

therne

•

Ethernet

IEEE 802.3u 100

0Base-Tx E

•

rol

IEEE 802.3x Flow c

contro

•

rent bridging

IEEE 802.1D transpare

•

l duplex mode

Flow control in full

•

n half duplex mode

Back pressure in

Management

•

nd via console

CLI comman

•

ontrol VDSL line rate and status

System co

h CO mode

through

•

rade via console

FW upgra

Hardware Specifications

• WAN: one RJ-45 interface for VDSL (over

POTS/ISDN)

• LAN: one10/100 Auto MDI/MDI-X RJ-45 interface

• Power Switch: one Push type button

• External console port: one DB9 interface

• Selectable CO and CPE via Switch button

• Status LEDs indicator

Physical Specifications

• Dimensions: 189 (W) x132 (D) x 40 (H) mm

• Weight: 307 g

Power Requirements

• 9 V AC 1000 mA

• Power supply:120 V/230 V/240 V

Environmental Specifications

Operating Environment

• Temperature: 0ºC ~ 40ºC

• Humidity:20% ~ 85% (non-condensing)

Storage Environment

• Temperature: -20ºC ~ 60ºC

• Humidity:20% ~ 90% (non-condensing)

Certification

EMC

• EN55022 Class B

• EN61000-3-2: 2000

• EN61000-3-3: 1995+A1: 2001

• FCC Part 15 (Class B)

Safety

• CSA 60950-1

• UL 60950-1

• EN 60950-1: 2001+A11

• IEC 60950-1: 2001

Specifications

VDSL Point-to-Point Modem

P-871M

Application Diagram

Location A

Location B

VDSL

1.5 km

Server

Desktop

Laptop

IP CAM

Ethernet cable

DSL cable (Copper Wired)

For more product information, visit us on the web at www.ZyXEL.com

65-100-087103B 04/08

Communications Corp.All other brands,product names, or trademarks mentioned are the property of their respective

owners. All specifications are subject to change without notice.
