Benefits

True dual networks optimize HD media and web surfing experiences

simultaneously

With three dual-band antennas featuring MIMO technology, the NBG5715 provides you the ultimate

visual experiences over the true dual networks at blazing data transfer rates of up to 450 Mbps*.You can

simultaneously surf the Web over the common 2.4 GHz band with fast speeds and watch HD video or

play online games over the interference-free 5 GHz band with smooth playback.

With four Gigabit Ethernet ports, the NBG5715 offers steadfast performance of video streaming with

speeds 10 times faster than typical Ethernet connections.

Advanced QoS offers smoother media streaming over fiber broadband service

For users who demands high bandwidth media streaming services over fiber broadband service,the

advanced QoS of ZyXEL NBG5715 enhances the stability of multiple HD video streams, gaming, voice

over IP, and web surfing.

• Compliant with 802.11n,wireless

speeds of up to 450 Mbps* over

concurrent dual-band

connectivity

• True dual networks optimize HD

media and web surfing

experiences simultaneously

• Advanced QoS offers smoother

media streaming over fiber

broadband service

• SmartRange technology** widely

extends the effective wireless

coverage

• Gigabit Ethernet for reliable

high-performance video

streaming

• 2 NetUSB™ ports for sharing

printers and USB mass storages

wirelessly

• 5 IPSec VPN tunnels secures data

transfer between home networks

and remote sites

• LED light on/off button provides

better environmental

compatibility

• Green product with wireless

on/off button and power on/off

switch to save energy

NBG5715

Simultaneous Dual-Band

Wireless N900 Media Router

Legacy RouterNBG5715

www

NBG5715

5 GHz

2.4 GHz

Multiple

Videos

Web Games

Single HD

Videos

Web Games

Stability

Good

Best

Gear Up for a New Era of HD Media Network! N

900

NBG5715

Simultaneous Dual-Band Wireless N900 Media Router

ZyXEL with

SmartRange Technology**

Room1

Room2

Other Products

without SmartRange

Technology**

Scanner

USB Mass

Storage

Device

Printer

NBG5715

Effective wireless coverage extension

Thanks to the SmartRange technology**, the

NBG5715 provides effective wireless coverage by

transmitting wireless signals directly to other

wireless network devices such as tablet PCs,

laptops and game consoles.You can enjoy digital

entertainment content without dead spots in

every room at home.

Easy to share wirelessly

The NBG5715 allows users to share USB devices

over the home network through the NetUSB™

support. With two built-in USB ports, the

NBG5715 can share printers or USB mass storage

devices as if the devices were connected directly

on the PC; just plug the USB devices to the

NBG5715, the family members everywhere at

home can use them wirelessly.

Application Diagram

Specifications

System Specifications

Wireless Standard

• 802.11 a/b/g/n

Wireless Transfer Rate

• Transmit: 450 Mbps* for dual bands

• Receive: 450 Mbps* for dual bands

Wireless Security

• WEP, WPA-PSK,WPA2-PSK,WPA,WPA2

Wireless Features

• Wi-Fi Protected Setup (WPS)

• Wi-Fi Multimedia (WMM)

• Wireless scheduling

• Wireless output power management

• MAC address filtering

• Multiple SSIDs

Routing

• NAT (NAT session: 16000)

• HW NAT

• DHCP server on LAN

• DHCP/PPPoE/PPTP client on WAN

• DDNS

• Advanced QoS

• Diagnostic logs

VPN Pass-through

• IPSec

• PPTP

• L2TP

VPN

• IPSec VPN with 5 tunnels

Firewall

• Deny of Service (DOS) Prevention

Others

• UPnP

• NTP client

• DNS proxy

• NetUSB™ support

Hardware Specifications

• WAN: One 10/100/1000 Mbps Ethernet RJ-45

port with auto MDI/MDIX support

• LAN: Four 10/100/1000 Mbps Ethernet RJ-45

ports with auto MDI/MDIX support

• Two USB 2.0 ports

• LED indicators:

Power

WAN

Internet

LAN (1 - 4)

Wireless 2.4 GHz

Wireless 5 GHz

WPS

USB1

USB2

• Three 2 dBi detachable dual-band antennas

• Button/Switch:

Power on/off switch

Wireless on/off button

LED light on/off button

Two USB eject buttons

WPS button

Reset button

• Power: 12 V DC, 2 A

• Power consumption: 21 Watt max

Physical Specifications

• Item dimensions (WxDxH):

214 x 74 x 165 mm (8.42”x 2.91” x 6.49”)

• Item weight: 490 g (1.08 lb.)

• Packing dimensions (WxDxH):

276 x 195 x 101 mm (10.86”x 7.68” x 3.98”)

• Packing weight: 1,040 g (2.3 lb.)

Environmental Specifications

Operating environment:

• Temperature: 0°C to 40°C (32°F to 104°F)

• Humidity: 20% to 90% (Non-condensing)

Storage environment:

• Temperature: -30°C to 70°C (-22°F to 158°F)

• Humidity: 20% to 95% (Non-condensing)

Certification

• Safety: CE LVD

• EMC: CE, FCC

• Others: Wi-Fi a/b/g/n,WMM,WPS

Package Contents

• Wireless router

• Three detachable dual-band antennas

• Power adapter

• Ethernet cable

• Quick start guide

• Warranty card

• Support CD

* The maximum wireless data transfer rate is derived from IEEE Standard

802.11 specifications.Actual data transfer rate will vary from network

environment including: distance, network traffic,building site

materials/construction, interference from other wireless devices,and

other adverse conditions.

** SmartRange works under 5 GHz radio band

NBG5715

Simultaneous Dual-Band Wireless N900 Media Router

NBG5715

Simultaneous

Dual-Band Wireless

N900 Media Router

NSA325

2-Bay Power Plus

Media Server

NWD2205

Wireless N

USB Adapter

Printer

USB Mass

Storage

Device

xDSL/Cable/

Fiber Modem

Game Console

WAP5605

5-GHz Wireless N

Media Streaming Box

Ethernet

USB Cable

5 GHz

2.4 GHz HDMI/RCA Cable

Internet

5-100-00112006 06/12

For more product information, visit us on the web at www.ZyXEL.com

trademarks of ZyXEL Communications Corp. All other brands, product names, or trademarks mentioned

are the property of their respective owners. All specifications are subject to change without notice.

NBG5715

Simultaneous Dual-Band Wireless N900 Media Router

Wireless on/off

button for

energy saving

LED light on/off

button fits better

in living room

environments

User-Friendly Design

Rear Panel

Four Gigabit Ethernet

LAN ports

Power

on/off

switch for

energy

saving Power

adapter

One-touch WPS

button for easy

security setup

Two USB

eject buttons

Gigabit

Ethernet

WAN port
