AAXA Technologies P8 Manuale utente

aaxa

TECHNOLOGIES

User Guide

P8 Smart Mini Projector

Wi Bluetooth

Caution!

WARNING: Please use this product as instructed. Misuse may cause

injury or death.

DO NOT use while driving

DO NOT expose to water or wet surfaces. Electric shock may occur

DO NOT expose the projected LED image to your eyes or the eyes of others

DO NOT block or restrict airow from ventilation holes as this may cause the

projector to overheat

Keep the projector, battery, or

charger away from any heat sources

Table of Contents

Chapter 1: P8 at a Glance

P8 Introduction

Remote & KeypadRemote & Keypad

Accessories

Chapter 2: Getting Started

Powering On / O󰀨

Focus Adjustment / Throw Distance

Connecting to Speaker/ Headphone

Loading External Content

Chapter 3: Menu Screens

Main Menu

Brightness Menu

*Wi Menu

*Mirroring Menu

Streaming Services Menu

O󰀩ce Menu

Files Menu

Browser Menu

Apps Menu

*FAQ: Slideshow/ Zoom

Connecting to Digital Input

Chapter 4: Settings Menu

Advanced Settings

Language Settings

Display Settings

Keystone & Projection Direction

*Bluetooth Menu

Backup Reset

Chapter 5: Technical Details

Troubleshooting

Specications

Notes

P8 at a Glance

Chapter 1

Digital AV

(HDMI Compatible)

Main Unit

Focus Adjustment

Micro SD

TF Card

Headphone Out

Power On/O󰀨

12V D/C Power

Power Button

USB-C Mirroring

Type C Mirroring

Standard USB 2.0

Compatible

Remote & Keypad

Power On/O󰀨

Select Source

Menu Exit/Back

Direction Pad

Both the keypad and remote can be used to navigate through the menus. The Main Menu

Navigation on the remote functions exactly the same as the directional pad on the P8 unit.

Main Menu

Navigation

Media Player

Menu Navigation

Volume Up

Volume Down

Remote

Keystone

Adjustment

Keystone

Adjustment

Accessories

*Under various circumstances, the actual accessories may be dierent from

those shown in the pictures above.

Additional accessories are available for purchase at www.aaxatech.com

Power Adapter Remote

Tripod

Getting Started

1. Connect the power cord to the P8.

2. Connect the other end of the power cord into the wall power source.

3. Press the On/O󰀨 button at the back of the P8 for about 3 seconds, wait shortly and

the projector should automatically boot up and turn on.

Powering ON the projector

Chapter 2

Powering OFF the projector

1. To turn o󰀨 the projector, press the “On/O󰀨” button.This will fully turn o󰀨 the projector.

2. Unplug and disconnect the P8 from the power source

Focus Adjusment / Throw Distance

DIAGONAL SCREEN SIZE

16:9 Aspect Ratio

Throw Distance

Units: Inches

Diagonal Size

Units: Inches

• Spin the focus wheel up or down until the image becomes

clear.

Focus Adjustment

Throw Distance Chart

Throw Ratio 1.20

Projection Angle: 100% O󰀨set

*minimum throw distance: 16 inches

Connecting Speakers / Headphones

Connect your speakers/headphones to

the projector’s audio port.

Step 1:

Step 2:

*CAUTION: Prolonged use of headphones at a high

volume may impair hearing.

Ensure that the projector and/or the

headphones are powered on.

Step 3: Place the headphones on and enjoy!

Loading External Content

The P8 can read les directly from both

a TF Card and USB Drive.

Supported le types include:

MP3 / WMA / OGG / WAV / AVI / MP4 /

JPG / GIF

PDF / DOC / XLS / PPT

(up to 64 GB)
