Acer PD PD116PD Manuale utente
Acer PD116PD Digital projector
Available in South Africa
http://www.LaptopDirect.co.za
http://www.ComputerStore.co.za
Native SVGA resolution 800x600 (up to SXGA 1,280x1,024) guaranteeing images with perfect quality
and precision for ambitious Education, Home and Office Users.
2100 ANSI Lumens in normal mode (30db) allowing presentations in big class, seminar or conference
rooms with normal daylight.
Home Cinema applications made comfortable thanks to its Eco Mode still providing 1700 ANSI Lumens
with only 27db.
DVI-I connection (Digital, HDCP supported)
Amazing quality of image at minimized cost thanks to the latest DLP™ technology.
Incredible contrast ratio of 2000:1 providing a more consistent color imaging with smoother and crisper
results over a long-time period.
Keystone correction allows a very fast adjustment of the image
Fully compatible with NTSC, PAL, SECAM , HDTV as well as with all sophisticated notebooks installed
within any modern business environment today.
This Elegant bicolor design weighing only 2.4kgs will be your best companion for successful school or
business presentations and Home entertainments.
Remote control with laser pointer, page up and down function and an easy-to-use bag to simplify your
life.
The PD116PD is the digitalized version of the PD116 uniting native SVGA resolution, 2100 Lumens and a
DVI-I connection. With its high brightness, high contrast ratio, a DVI-I connection and all most practical
accessories, the PD116PD is the perfect SVGA tool for schools and seminars. Ambitious Home and Office
Users will also be impressed by this new Digital tool that is available for a minimum budget.
Technical specifications
Display Technology
DLP™, Digital Light Processor
Native Resolution
Native SVGA (800 x 600),
Compressed Resolutio
n
SXGA (1,280 x 1,024) compressed
Typical Colors
16.7 Million Colors
Brightness (ANSI lumens)
2,100 ANSI Lumens (standard) -
1,700 ANSI Lumens (ECO)
Contrast Ratio
2000:1
Noise Level
30 dB (standard mode), 27 dB (ECO mode)
Weight
2.4Kg (5.3 lbs)
Dimensions
277 x 237 x 107 mm (10.9" x 9.33" x 4.21")
Design Aesthetics
Robust Silver Magnesium Alloy Top, Black Front and Bottom Cover
Computer Compatibility:
IBM PC and Compatibles, Apple Macintosh, iMac, and VESA Standards SXGA, XGA, SVGA, VGA
(resizing)
Video Compatibility
NTSC (3.58/4.43), PAL (B/D/G/H/I/M/N), SECAM (B/D/G/K/K1/L), HDTV (720p, 1080i), EDTV (480p,
576p), SDTV (480i, 576i)
Aspect Ratio:
4:3 Native, 16:9 Compatible
Horizontal Scan Rate:
31.5 - 100
kHz
Vertical Scan Rate:
56 -
85 Hz
Projection Distance:
3.94’ (1.2m) ~ 40' (12.2m)
Projection Screen Size (Diagonal):
24.6” (0.625m) ~ 300” (7.62m)
Keystone Correction:
+/-16 Degrees
Audio
One Internal Speaker, 3 Watts
Lamp Life
2,000 Hours (standard) - 3,000 Hours (ECO)
Lamp Type
200 W User Replaceable UHP Lamp
Power Consumption:
265 Watts
I/O Connectors
1 HDB 15-Pin D-Sub (VGA/Component/HDTV), 1 3.5mm Audio Mini Jack, 1 RS232 Connector (For after
service purpose only), 1 29-pin DVI-I Connector (Digital, HDCP supported), 1 Composite Video RCA Jack,
1 S-Video Mini DIN, 1 15-Pin D-Sub for Monitor Loop Through, 1 USB Connector for Remote Computer
Control.
Bundled Accessories:
AC Power Cord, VGA Cable (15pin D-Sub), Composite Video Cable (RCA), S-Video Cable, VGA (D-Sub)
to Component / HDTV Adapter, USB Cable, Audio Cable (Mini to Mini Phone Jack), Remote Control with
Laser Pointer & PgUp/PgDn function, Batteries x 2 for Remote Controller, Quick Start Guide (CD-ROM),
Warranty card, Lens Cap, Carrying Case.
Up-grade Options
External TV tuner, Replacement lamp
