RS232

4

S-Video Output

VGA

Video Output

Y

Y

D-Sub

D-Sub

R

W

D-Sub

D-Sub

USB

USB

RS232

USB

USB

1

2

3

5

6

7

42

8

8

X1161 series

E62405SP

R

INSTALLATION

INTERFACE CONNECTOR

Note: Connector interface is subject to model’s specifications

molex

molex

繁體中文

 安裝

連接到電腦

1.請確認投影機和電腦已完全關閉電源。

2. 將 VGA訊號線的一端連接到投影機上標

示「VGA IN」連接埠，另一端連接到電

腦的VGA連接埠並且鎖緊螺絲。

3.

將電源線的一端連接到投影機上的AC電

源插孔，另一端連接到電源插座。

打開投影機電源

1.取下投影機鏡頭蓋。

2.先打開投影機電源，接著再打開電腦電

源。

3.調整投影機的位置、焦距和縮放比例。

4.開始進行簡報。

關閉投影機電源

1.按兩次電源按鈕。

2.請等到投影機風扇完全靜止後，再拔掉

電源線。

警語與注意事項

安全事項：

1.請勿直視投影燈源，以免強光傷害您的眼睛。

2.為預防火災及觸電意外，請勿將本產品淋到雨

或置於潮濕處。

正確使用方法：

1.如長期未使用本產品，請從AC插座拔掉電源插

頭。

 更多安全事項及正確使用方法，請參考隨附光

碟內之使用手冊。

 介面連接器

快速安裝卡

1. 電源線 (*)

2.VGA信號線 (*)

3. 複合視頻信號線

4.RS232信號線

5.S-Video信號線

6. 音頻信號線Jack/Jack

7. 音頻信號線Jack/RCA

8.USB信號線 (*)

備註: 接頭介面視機型規格而定

備註:“(*)”限 X1161N 系列

English

INSTALLATION

Connecting to a Computer

1. Ensure the projector and your

computer are turned off.

2. Connect one end of the VGA cable

to the “VGA IN” connector on the

projector; connect the other end to

the VGA connector on the computer

and tighten the screws.

3. Connect one end of the power cord

into the AC power socket on the

projector; connect the other end to an

electrical outlet.

Powering On the Projector

1. Remove the lens cap.

2. Turn on the projector first and then

the computer.

3. Adjust the position, focus and zoom.

4. Run you presentation.

Powering Off the Projector

1. Press the power button twice.

2. Do not remove AC power cord from

outlet until the projector fan shut

down.

INTERFACE CONNECTOR

Quick Start

1. Power Cord (*)

2. VGA Cable (*)

3. Composite Video Cable

4. RS232 Cable

5. S-Video Cable

6. Audio Cable Jack/Jack

7. Audio Cable Jack/RCA

8. USB Cable (*)

Note: Connector interface is subject to model’s specifications

Note: “(*)” Only for X1161N series.
