Acorp 6M810E Manuale utente
6M810E/6M810ECD
Micro-ATX Form Factor
Main Board
User' s Manual
( ver 2.0 )
Copyright
Copyright ©2001 by this company. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrievable system,
or translated into any natural or computer language, in any form or
by any means without prior written permission. This manual and the
information contained herein are protected by copyright. All rights
reserved.
Manual version: 2.0
Ref. No. 3053337
Published in 2001
Warning and disclaimer
This manual is designed to provide information about the Pentium®
III / Celeron & Cyrix III main board. Meticulous efforts have been
made to make this manual as accurate as possible, but no warranty
or fitness is implied. All the information is provided on an 'as is'
basis. The author and his corresponding publishing company shall
have neither liability nor responsibility to any person or entity with
respect to any loss or damages arising from the information
contained in this manual or from the use of the system board that
accompanies it.
Information contained in this manual is subject to change without
notice. The manufacturer of the system board will not be held
responsible for technical or editorial omissions made herein, nor for
the incidental or consequential damages resulting from its
furnishing, performance, functionality or use. Subsequent changes to
this manual will be incorporated into the next edition. We welcome
any suggestion regarding this manual or our computer products.
Trademarks
●Intel® and Pentium® are registered trademarks of Intel® Corporation.
●IBM® is a registered trademark of International Business Machines
Corporation.
●Microsoft is a registered trademark of Microsoft® Corporation.
●PCI is a registered trademark of PCI Special Interest Groups.
●AWARD® is a registered trademark of Award Software Inc.
All other trademarks are the property of their respective owners.
Table of contents
Chapter 1 Introduction…………………..….…..….…..1
1-1 Overview…………………………………………………………….1
1-2 Specifications………………………………………………………..3
1-3 Limitation……… ………………………………………………....5
1-4 Notice of Hardware Installation……..………………………….....6
1-5 Notice of CD Driver Installation…..………..….………….…..……….….7
Chapter 2 Installation…………………………………..8
2-1 Layout Reference……………………………………..…….……....8
2-2 Jumper Setting…………………………………………..….……....9
2-2-1 JP10 : Audio Function Selector……………………………………9
2-2-2 SMART: Smart Card Reader Connector…..……………..…….10
2-2-3 CMOS Status…………….………………………………………..11
2-3 Connectors..………………………………..…………………..….12
2-3-1 Front Panel……………….……………………..…..……………12
2-3-2 Back Panel Connectors…………………………………….14
COM 1/COM2…………………………………………….……..15
KBD/PS2 MOUSE………………………………………….…...15
LPT……………….……………………………………….…..…15
USB Connector……………………………………………….15
Midi/Game Port & External Audio Connectors….…..…….…15
2-3-3 ATX Power Supply Connector…………………………………16
2-3-4 Fan Connectors.………………………………………………....17
2-3-5 I.R. Connector……………..…….………….…..….……………18
2-3-6 Floppy Disk Connector………………………………………….19
2-3-7 IDE1 & IDE2…………………….…….…..……..…..………....20
2-3-8 CD1/CD2: CD-in………………………………….….……...…..21
2-4 DIMM Installation………………………………………...……22
Chapter 3 BIOS Setup………………………………..23
3-1 Award BIOS CMOS Setup………………………………………23
3-1-1 Standard CMOS Features…...……………….…………….……24
3-1-2 Advanced BIOS Features……………………………………....27
3-1-3 Advanced Chipset Features ………..…………...…….…..……32
3-1-4 Integrated Perpherals……………..…………………………....35
3-1-5 Power Management Setup………….…….…………….……....39
3-1-6 PNP/PCI Configuration Setup……………………………...…....42
3-1-7 Frequency/Voltage Control.……...……………………….……43
3-1-8 Supervisor/User Password…………….………………………….44
3-1-9 Load Optimized Defaults………....………………………….…47
3-1-10 Save and Exit Setup………..……...………..…………...………48
3-1-11 Quit Without Saving….…..…………………...………...………49
Chapter 4 Appendix…………………….………….....50
4-1 Memory Map………..………………….…………………….…50
4-2 I/O Map………….………………..………………..……...…..…51
4-3 Time & DMA Channels Map…………...…………………...….52
4-4 Interrupt Map…………….…………….…………………….…53
4-5 RTC & CMOS RAM Map……………………………………...54
4-6 ISA I/O Address Map……………….………………………….55
Chapter 5 Q & A……………….…………………..…57
6M810E Main Board
1
Chapter 1 Introduction
1-1 Overview
The main board utilizes Intel’s i810 chipset integrated with new architects such as
integrated graphic, sound, ULTRA DMA-66, USB & AMR is designed to FC-
PGA or PPGA Celeron / Coppermine P!!! / VIA Cyrix III Socket-370 CPUs.
Intel’s i810 is a cost-effective yet high-performance chipset which has integrated
graphics controller (i752) with a 24 Bit 230MHz RAMDAC & software MPEG2
decoder. It supports UMA (unified memory architect) mode up to 64MB with
main memory or 4MB 3D texture memory (or called display cache, optional
function ) that can accelerate its 3D graphics performance. The on board AC-97
CODEC chip provides perfect 3D sound function.
The main board also employs ITE I/O LPC controller with full Plug and Play
device and keyboard password setup. It supports 2.88 MB Floppy, Dual 16550
compatible (with 16 bytes FIFO, up to 460K baud rate) serial Port, ECP
(Enhanced Capabilities Port), EPP (Enhanced Parallel Port) parallel port,
SPP(Standard Parallel Port), Infrared IrDA (HPSIR), and Amplitude Shift Keyed
IR. (ASKIR) port and hardware monitor functions too.
The main board contains 2*PCI for highest performance I/O add-on adapter cards.
The system board supports three Bus Mastering Slots for high-performance I/O
add-on cards. It supports Matrix Independent PCI routing for optimal multiple
PCI adapter operations and is PCI2.2 specification compliant. 133MB/s data
transfer rate can be compared to 33MB/s. It supports back to back sequential CPU
to PCI Memory writes to PCI Burst Write for full PCI throughput. The AMR Slot
is designed to fit low cost A(Audio) M(Modem) R(Riser) or MR card.
6M810E Main Board
2
The main board has 2 dual in-line memory modules (DIMM) which can be
installed with PC-100 SDRAM memory(PC-133 with i810E Chipset only). The
memory subsystem supports up to 512 MB SDRAM of non-buffered 3.3V using
standard 168-pin DIMM sockets.
The main board is strengthened with Power Management Wake up Event such as
“Modem ring on” which is the new invention to enable PCs to be turned on via
the network or modem function. These are also key benefits in PC operation, asset
management, new system setup and power conservation.
In addition to the above hardware features, this main board is Jumperless design
which allows user to set CPU frequency through BIOS. With this design, the
disadvantages of setting hardware CPU jumpers are improved to a better and
easier procedure through BIOS.
In conclusion, the system chipset and design make the main board a high
performance, cost-effective, and energy efficient main board which meets a
variety of price/performance levels. The main board is an ideal platform for the
increasing requirements of today’s and future’s desktop applications.
CPU Installation
This model is a jumperless main board, there is no selector needed for CPU
frequency selection,, Please load optiomized Defaults in the CMOS setting,.
The main board will automatically detect CPU frequency (66/100/133 MHz)
6M810E Main Board
3
1-2 Specifications
● Chipset : The board can apply either i810DC-100 or i810E chipsets listed
below:
Type 810-DC100 810-E
North GMCH GMCH-E
South ICH ICH
FSB 100MHz 133MHz
Display Cache Yes, 100MHz Yes, 100MHz
ATA ATA66 ATA66
PCI REQ/GNT 6 6
● CPU : can take current Socket-370 P!!! 66/100/133MHz (133 MHz with
i810E only) , Cyrix III & Celeron CPUs.
● Memory : accepts 2 * DIMM in PC-100/PC-133(with i810E only)
specification memory
● VGA : On chip 3D graphics function with shared 4MB 3D texture memory
(or called display cache) (shared 4MB display cache optional )
●Sound : Provides sound function with AC-97 3D sound CODEC.
● Expansion Slot : 2 x PCI slots, 1 x AMR(used for AMR card or MR card)
● IDE : support ULTRA DMA-66 mode
● PCB Board size : 17.0cm x 24.5cm, Micro ATX form factor
● Optional Items :
•TV-out (Chrontel CH7007 chip is needed)
Caution : System needs at least PC-100 memory & over 5VSB
≧
1 Ampere current
ATX power supply for this main board
6M810E Main Board
4
● Other features
•Modem ring on
•Windows 95/98 power off
•Keyboard wake-up
•Mouse wake-up
•DMI, ACPI supported BIOS
6M810E Main Board
5
1-3 Limitation
There are some limitations on i810 chipset shown as below:
1. Hardware:
∗Must use PC-100 specification DIMM (PC-133 for i810E only)
∗Must use over 5VSB ≧1 Ampere current.
2. Software (Driver or BIOS):
∗Windows 95 & 98 don’t provide driver (utilities) for i810 chipset. User
needs to install driver carefully before using this board
