Acorp 7KT400A Manuale utente

0-1

Contents Motherboard 7KT400A

Motherboard

7KT400A

1. 7KT400A Specifications....................4

1.1 Introduction ............................................................ 4

1.2 Package Contents .................................................. 5

1.3 Specifications and Features .................................. 6

CPU Processor ........................................................................... 6

Chipset ........................................................................................ 6

PCI .............................................................................................. 6

DDR SDRAM Memory ............................................................... 6

..................................................................................................... 6

Universal Serial Bus .................................................................. 6

AGP ............................................................................................. 6

WOL (Wake On LAN) ................................................................ 6

AwardBIOS ................................................................................ 7

ATA 133 On Board ..................................................................... 7

PC’99 Color-coded I/O Ports ...................................................... 7

Hardware Monitoring in Chip W83697HF ................................ 7

1.4 7KT400A Layout Diagram ................................... 8

1.5 CPU Installation ................................................... 10

CPU Installation Procedures for Socket 462 ........................... 10

1.6 DDR SDRAM Installation ................................. 11

1.7 Connectors & Jumpers Setting ........................... 12

1.7.1 Back Panel I/O Connectors ............................................. 12

1.7.1.1 PS/2 Mouse / Keyboard CONN: .............................................. 1 2

0-2

Contents Motherboard 7KT400A

1.7.1.2 USB0/1/2/3 ..................................................................................... 1 2

1.7.1.3 Serial Interface Port: COM1/2 ............................................... 1 3

1.7.1.4 Parallel Interface Port .............................................................. 1 3

1.7.1.5 Audio Ports ................................................................................... 1 3

1.7.2 ATX Main Power Connectors: ATXPWR ....................... 14

1.7.3 Floppy Disk Connector: FDD .......................................... 15

1.7.4 Hard Disk Connectors: IDE1/IDE2 ................................ 15

1.7.5 Fan Connectors: FAN1/CPUFAN/SYSFAN ..................... 15

1.7.6 CD Audio-In Connectors: CDIN1 .................................... 16

1.7.7 IR infrared module: IR/CIR Connector .......................... 16

1.7.8 USB Pin Header: USB4/5 ................................................ 17

1.7.9 Front Panel Connectors: PANEL1 .................................. 18

1.7.10 Wake On LAN Connector: WOL .................................. 20

1.7.11 Game/MIDI Connector: J1 ............................................. 20

1.7.12 Smart Panel Connectors (optional): .............................. 21

1.7.12.1 Front COM2 Header Connector: COM2 .......................... 2 1

1.7.12.2 Audio/Mic Auto Connector: JP1 .......................................... 2 1

1.7.12.3 SPII Printer Error LED Port: SP-J6 ..................................... 2 2

1.7.12.4 Second BIOS Connector: SP-J2 .......................................... 2 2

1.7.12.5 6-channel SP-DIF Audio Connector: J6 ............................ 2 3

1.7.13 CMOS Function Selector: Clear_CMOS ..................... 24

1.7.14 USB4/5 Wake-up Selector: J4 ...................................... 24

1.7.15 CPU Clock Frequency Selector: J3 & J5 ..................... 25

1.7.16 Ports USB0/1, 2/3 Wake-up Selector : J2 .................... 26

2. BIOS Setup ..................................... 27

2.1 BIOS Support ....................................................... 27

2.2 Main Menu .......................................................... 30

0-3

Contents Motherboard 7KT400A

2.3 Standard CMOS Features .................................. 33

2.4 Advanced BIOS Features ................................... 37

2.5 Advanced Chipset Features ................................ 41

2.6 Integrated Peripherals ......................................... 48

2.7 Power Management Setup .................................. 55

2.8 PnP/PCI Configurations ....................................... 61

2.9 PC Health Status ................................................. 64

2.10 Frequency/Voltage Control ............................... 65

2.11 Load Fail-Safe Defaults ..................................... 66

2.12 Load Optimized Defaults ................................... 67

2.13 Set Supervisor / User Password ........................ 68

2.14 Save & Exit Setup ............................................. 69

2.15 Exit Without Saving ........................................... 70

3. Drivers & Utilities ........................... 71

3.1 Auto-run Menu .................................................... 71

3.2 Installing VIA Service Pack ................................ 72

3.3 Installing Audio Driver ........................................ 75

3.4 Installing USB 2.0 Driver .................................... 77

Appendices .......................................... 79

Appendix I Quick Jumper Setup ............................ 79

Appendix II Mainboard Test Report ..................... 80

1-4

Chapter 1 Motherboard 7KT400A

The 7KT400A motherboard is an integration of AMD

Athlon/Duron CPU in Socket 462 packaging and the North

Bridge VIA KT400A (VT8377A) supporting 100/133/166

MHz Front Side Bus.

North Bridge KT400A on board also supports DDR 200/

266/333/400 SDRAMs, while the South Bridge VT8235 pro-

vides stable supports of ULTRA ATA 133, 6-channel Audio

playback and USB 2.0/1.1 interface.

The resulting architecture will provide an ideal multi-task

environment to support operating systems such as MS-DOS,

Windows, Windows NT , Windows ME, Windows 2000, Novell,

OS/2, Windows 95/98, Windows 98SE, Windows XP, UNIX,

Liunx, SCO UNIX etc. This user-friendly manual is to de-

scribe in detail how to install, configure and use this

motherboard with drivers and BIOS setup illustrations.

Chapter 1

Motherboard 7KT400A

1.1 Introduction

1. 7KT400A Specifications

This manual is a general reference of the first release of this

motherboard which is subject to update without notice. If any differ-

ence is found between this manual and the motherboard you are

using, please visit our Web Site.

1-5

Chapter 1 Motherboard 7KT400A

HDD UDMA66/100 Cable x1.

FDD Cable.

Flash Memory with BIOS.

I/O Shielding

Fully Setup Driver CD with built in utilities.

User Manual.

1.2 Package Contents

1-6

Chapter 1 Motherboard 7KT400A

CPU Processor

| Support 100/133/166 MHz System Interface speed

| Single Socket 462 for AMD TM Athlon CPUs 700MHz~3000+

or higher*, and Duron CPUs 600 ~ 1400 MHz or higher*

Chipset

| VIA KT400A North Bridge

| VIA VT8235 South Bridge

PCI

| Supports 5 x PCI slots, 32-bit 33MHz PCI Bus speed.

DDR SDRAM Memory

| Supporting 64/128/256/512/1G....MB DDR module in 3 slots

| Supporting 400/333/266/200MHz DDR SDRAM

| Supporting a maximum memory size of 3GB of DDR SDRAM

Universal Serial Bus

| Supporting two on-board Universal Serial Bus(USB)Ports

and four external Universal serial Bus(USB)Ports.

| Supporting USB 2.0/1.1

AGP

| Supporting 1 x AGP8X slot, V3.0 compliant.

WOL (Wake On LAN)

| Supporting system power-on by LAN Ring-up signal.

1.3 Specifications and Features

* The higher frequency CPU should be compatible with AMD CPU

specificiation and the motherboard latest BIOS version which will

be released in our Web Site.

1-7

Chapter 1 Motherboard 7KT400A

Award BIOS

| Supporting Plug & Play specification which detects the

peripheral devices and expansion cards automatically

| Supporting CD-ROM, SCSI, LAN BOOT, Temperature sen-

sor, LAN, Alarm Bus CLK setup

| Supporting Desktop Management Interface (DMI) func-

tion for recording mainboard specification

ATA 133 On Board

| Supporting PIO Mode 5, Master Mode, high performance

hard disk drives.

| Supporting Ultra DMA 33/66/100/133 Bus Master Mode.

| Supporting 4xIDE devices, including CD-ROM, CD-R, CD-RW,

LS-120 and high capacity hard disk drives with LBA mode

PCI-Based AC 97 Digital Audio Processor

| AC 97 2.2 compatible Codec, 6-channel Audio interface.

| 18-bit Stereo Full-Duplex Codec with up to 48 KHz samp-

ling rate

| 4 Analog Line-level Stereo inputs for connection from Line,

CD, Viedo and AUX

| 2 Analog Line-level Stereo inputs for speakerphone and PC

beep

PC’99 Color-coded I/O Ports

| 6 USB ports, USB 2.0 compliant.

| 2 COM ports; 1 Parallel port

| 1 PS/2 Mouse port; 1 PS/2 Keyboard port

| 1 Line-in; 1 Line-out; 1 Mic

Hardware Monitoring in Chip W83697HF

| Core voltage, CPU temperature and Fan speed monitoring

1-8

Chapter 1 Motherboard 7KT400A

VIA

VT8235

Socket 462

W83697

8100BL

RTL

VIA

KT400A

BIOS

15 16

13 1411

1.4 7KT400A Layout Diagram

24 2223

Battery

2627

AGP 8X Slot

PCI 1

1-9

Chapter 1 Motherboard 7KT400A

7. J6: Connector for 6-channel SP-DIF Audio (optional)

8. W83697HF: Winbond I/O chip

9. J1: Game Port/MIDI Connector

10. COM2 Header: Pin Header for an external COM Port

11. SP-J2: BIOS2 Connector

12. WOL: Wake-on LAN Connector

13. J4: USB4/5 Power Option

14. USB4/5: USB Header for 2 USB Ports

15. FDD: Floppy Drive Connector

16. SYSFAN1: System Cooling Fan Connector

17. Panel1: Front Panel Connector

18. Clear CMOS: Jumper for clearing CMOS

19. IDE2: IDE Connector

20. IDE1: IDE Connector

21. J5: CPU Clock Frequency Connector

22. DIM3: DDR SDRAM Slot

23. DIM2: DDR SDRAM Slot

24. DIM1: DDR SDRAM Slot

25. VIA KT400A: North Bridge

26. Socket 462: CPU socket for AMD CPUs

27. ATXPWR: ATX Main Power Connector

28. SP-J6: Printer Error LED Connector for Smart Panel Connection

29. J2: Jumper for USB0/1, 2/3 Power Option

30. JP1: Audio connector for Smart Panel connection

31. IR/CIR: IR/CIR Connector for Infrared Signal Transmission/Re

ception

1. Back Panel: Back Panel I/O Connectors ( Mouse, Keyboard, COM1,

COM2, Printer, Mic in, Line in, Speaker-out, USB0/1/2/3)

2. J3: CPU clock Frequency Connector

3. CPUFAN1: CPU Fan Connector

4. VOIN1: CD Audio In Connector

5. FAN1: Cooling Fan Connector

6. ALC650: AC’97 Audio Codec

7KT400A Component Layout :

1-10

Chapter 1 Motherboard 7KT400A

VIA

VT8235

Socket 462

W83697

8100BL

RTL

VIA

KT400A

BIOS

The motherboard operates with Socket 462 for AMD AthlonTM

and DuronTM processor. The CPU should always have a Heat Sink

and cooling fan attached to prevent overheating.

CPU Installation Procedures for Socket 462

1. Pull the lever sideways away from the socket then raise the

lever to a 90-degree angle.

2. Locate Pin 1 in the socket and look for the white dot or cut edge

in the CPU. Match Pin 1 with the white dot/cut edge then

insert the CPU.

3. Press the lever down to complete the installation.

4. Make sure the spec of the cooling fan is good enough.

5. Please lock the fan on CPU very carefully, or you will damage

the resistor array even circuit line on the mainboard.

Notch

1.5 CPU Installation

Indice

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

ASROCK

ASROCK ROMED8-2T Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente
