Spec Sheet

FlexWave™ WMX 100/105

WiMAX Subscriber Unit

The FlexWave™WMX 100 series subscriber unit allows service providers to take full advantage of

the growing WiMAX market. The FlexWave WMX 100 is economically deployed and delivers the

features required to address the underserved small business, home office, and residential markets.

With a FlexWave WMX 100 subscriber unit, end users can browse web pages, make voice calls,

view streaming video, and download files—simultaneously and at multi-megabit speeds over

a robust wireless link.

ADC offers FlexWave WMX 100 models operating in 2.5 GHz, 3.5 GHz, and 5 GHz bands

using spectrum efficient TDD scheduling. FlexWave WMX 100 units are compliant with the

802.16-2004 standard and offers software upgradeability to the 802.16e-2005 amended

standard in some models (WMX 105). The FlexWave WMX 100 system delivers superior link

performance, unsurpassed quality of service, and a broad range of networking features for

optimized WiMAX deployment.

Features:

• IEEE802.16-2004compliantandupgradeableto802.16e-2005(somemodels)

•SuperiorQoSformulti-servicesupportincludingpremiumvoiceservices

•2.5GHz,3.5GHzand5GHzfrequencybands

•LOS,OLOS,NLOSdeployments

FlexWave™ WMX 100/105

WiMAX Subscriber Unit

www.adc.com • +1-952-938-8080 • 1-800-366-3891

1/08•102579AEFlexWave ™WMX 100/105

Providers can install the FlexWave WMX 100 in minutes. The units do not require a direct line of sight

with the base station, and they support centralized WiMAX provisioning from the remote management

and monitoring station. The FlexWave WMX 100 subscriber unit consists of an outdoor unit with an

integral antenna that connects to a compact indoor unit via a standard outdoor-rated Cat-5 cable,

which carries ethernet traffic and system power between indoor and outdoor units. An optional external

antenna is available for even greater gain.

ADC offers two FlexWave WMX 100 models designed to meet a variety of subscribers and network

requirements:FlexWaveWMX100and120.Thechoiceofcapabilitiesincludes:IPnetworking,

integratedVoIPprocessing,extendedrangeantennas,andahostoffeaturesallowingsimultaneous

differentiated services for the small enterprise and home office user.

Typical Applications

• Economicallastmileaccesssolution

for small to medium enterprises, home

offices, consumers and remote sites

• QoSenabledwirelessT1/E1services

for enterprise voice and data

• “WirelessDSL”serviceoffering

greater bandwidth and lower cost

to the end user

• OfferVoiceoverIP-basedservices

with single integrated solution

• Create"hotzones"bybackhauling

Wi-Fi access used for municipal and

mesh network configurations

FlexWave™ WMX 100/105

WiMAX Subscriber Unit

www.adc.com • +1-952-938-8080 • 1-800-366-3891

1/08•102579AEFlexWave ™WMX 100/105

Specifications

RADIO AND SYSTEM SPECIFICATIONS

Compliance:

Duplexing Mode, PHY:

Frequency:

Channel Bandwidth

WMX100:

WMX 105:

Step Size:

Radio Output Power:

Receiver Sensitivity:

Modulation:

Forward Error Correction:

Integral Antenna Gain:

Optional External Antenna:

IP NETWORKING FEATURES/OPTIONS

IP Version:

Bridging Mode:

VLANs:

SECURITY/ENCRYPTION

Authentication:

Encryption:

MULTI-SERVICE/MULTI-USER SUPPORT

Traffic Classifier:

Scheduling/QoS:

Active Connected Hosts:

Uni-directional Service Flows:

MANAGEMENT

Remote Management and Monitoring:

Remote Management Access:

Provisioning:

SNMP:

MECHANICAL

Outdoor Unit Dimensions (WxHxD):

Weight:

Indoor Unit Dimensions (WxHxD):

Weight:

IDU-ODU Distance:

ELECTRICAL

Input DC Voltage:

Max Input Current:

ENVIRONMENTAL

Weather Protection:

Operating Temperature (Outdoor Unit):

Humidity (Outdoor Unit):

RoHS Compliance:

IEEE802.16d-2004(3.5T1,3.5T2),ETSIHiperMAN,

802.16e-2005 upgradeable (some models)

TDD,OFDM256FFT

3.3–3.4GHz,3.4–3.6GHz,5.725–5.925GHz

Future:2.5–2.7GHz,3.6–3.8GHz,5.15–5.35GHz,

5.475–5.725GHz

3.0MHz,3.5MHz,5.5MHz,7.0MHz

Future:1.75MHz,5MHz,10MHz

2.5 GHz ( 5.0 MHz, 10.0 MHz)

3.5GHz(5.0MHz,7.0MHz,10.0MHz)

250 KHz

20 dBm; all frequencies

-95.1dBm

BPSK,QPSK,16QAM,64QAM

Convolution coding 1/2, 2/3, 3/4

16 dBi @ 3.5 GHz

Yes

IPV4(RFC791)

IEEE802.3d

IEEE802.1P/Q

X.509certificates

3DES,AESCCM128,1024

MACDA/SA,802.1P/Q,IPSA/DA,IPProtection,IPTOS,

TCP/UDP Port

UGS, rtPS, nrtPS,BE,CIR,MIR

5 max

8 max

WaveCenterEMSPro

Telnet,SNMP,HTTP

CentralizedusingWaveCenterEMSPro

MIBII(RFC1213),EnterpriseMIB;IEEE802.16fMIB

20.5cmx20.5cmx6.7cm(8.0"x8.0"x2.4")

5.2 lbs (2.4 kg) (including pole mount)

6cmx3.1cmx14.5cm(2.4"x1.2"x5.7")

1 lbs

up to 100 m

DC36–57V(IEEE802.3afcompliant)

0.27A@48VDC

IP65/NEMA-4

-35ºto60ºC(-31ºto149ºF)

5–95%noncondensing

yes

Spec Sheet

Website: www.adc.com

FromNorthAmerica,CallTollFree:1-800-366-3891•OutsideofNorthAmerica:+1-952-938-8080

Fax:+1-952-917-3237•ForalistingofADC’sglobalsalesofficelocations,pleaserefertoourwebsite.

ADCTelecommunications,Inc.,P.O.Box1101,Minneapolis,MinnesotaUSA55440-1101

Specifications published here are current as of the date of publication of this document. Because we are continuously

improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may

verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.

views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products or features

containedhereinmaybecoveredbyoneormoreU.S.orforeignpatents.AnEqualOpportunityEmployer
