ADLINK Technology Com express Manuale utente

Express-BASE

User’s Manual

Manual Revision: 2.20

Revision Date: March 5, 2009

Part Number: 50-1J012-1010

Express-BASE User’s ManualPage 2

Revision History

Release Date Change

2.00 2006/9/15 Initial Release

2.10 2007/10/19 Updated ETXexpress/Express name changes

2.20 2009/03/05 Updated Engineering Specifications (B2)

Updated company contact information

Page 3Express-BASE User’s Manual

Table of Contents

Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

2 Special Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.1 Primary LPC based Super I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.2 Secondary LPC based BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.3 Integrated Debug Port with Single Step Execution . . . . . . . . . . . . . . . . . . . . . . . 8

2.4 Audio Codec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

2.5 Information LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

3 Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

4 Function Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

5 Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

6 Connectors and Pin-outs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.1 Carrier Board Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.2 Connector and Pin-out Compatibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

6.3 COM Express Board-to-Board Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

6.4 PCI Express and PCI Express Graphic (PEG) slots . . . . . . . . . . . . . . . . . . . . . 15

6.5 PCI slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

6.6 LPC Debug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

6.7 I2C and SMB Bus (for user access). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

6.8 USB and LAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

6.9 Audio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

6.10 CRTVGA, LVDS andTV-out. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

6.11 Keyboard & Mouse . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

6.12 Serial andIrDA Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6.13 Parallel Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

6.14 Storage: SATA, PATA, CF, FDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Express-BASE User’s ManualPage 4

6.15 Other Pin Headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

6.16 Power Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

6.17 Jumper Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

7 Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.1 On/Off and RESET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.2 Secondary BIOS (backup BIOS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

7.3 POST Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.4 Indicator LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

7.5 Digital I/O LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Getting Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Page 5Express-BASE User’s Manual

Preface

This document contains proprietary information protected by copyright.All rights are reserved. No

part of this manual may be reproduced by any mechanical, electronic, or other means in any form

without prior written permission of the manufacturer.

Disclaimer

The information in this document is subject to change without prior notice in order to improve

reliability, design, and function and does not represent a commitment on the part of the manufac-

turer.

In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential

damages arising out of the use or inability to use the product or documentation, even if advised

of the possibility of such damages.

Environmental Responsibility

ADLINK is committed to fulfill its social responsibility to global environmental preservation

through compliance with the European Union's Restriction of Hazardous Substances (RoHS)

directive and Waste Electrical and Electronic Equipment (WEEE) directive. Environmental

protection is a top priority forADLINK. We have enforced measures to ensure that our products,

manufacturing processes, components, and raw materials have as little impact on the

environment as possible. When products are at their end of life, our customers are encouraged to

dispose of them in accordance with the product disposal and/or recovery programs prescribed by

their nation or company.

Trademarks

COM Express™ and PICMG® are registered trademarks of the PCI Industrial Computer

Manufacturers Group.

Product names mentioned herein are used for identification purposes only and may be trade-

marks and/or registered trademarks of their respective companies.

Express-BASE User’s ManualPage 6

Conventions

Take note of the following conventions used throughout this manual to make sure that users

perform certain tasks and instructions properly.

Additional information, aids, and tips that help users perform tasks.

Information to prevent minor physical injury, component damage, data loss,

and/or program corruption when trying to complete a task.

Information to prevent serious physical injury, component damage, data

loss, and/or program corruption when trying to complete a specific task.

Page 7Express-BASE User’s Manual

1Introduction

The COM Express approach of custom carrier combined with off the shelf system cores is an

excellent solution when you need to customize but lack the time or quantity for a complete

redesign. It fits most system integration projects with production volumes from 500 to 10,000 pcs

per year. The COM Express concept has a great many advantages over full custom designs, it

reduces engineering complexity, lowers the threshold for total project quantity and last but not

least brings your product to the market in no time. The average time to design a carrier board is

less than half the time of a full custom OEM board.

Express-BASE is a standardATX size carrier board. Together with the COM Express module of

your choice and off the shelf add-on cards you can quickly emulate the functionality of your

desired end product for software development and hardware verification.

To build a functional prototype of your target system you will need:

fCOM Express module

fExpress-BASE carrier board

fPCI Express or PCI add on cards

fPATA/ SATAstorage or Flash disk solution

Express-BASE accommodates up to five PCI Express x1 slots, one PCI Express Graphics x16

slot, one ExpressCard slot and one PCI slot.

The board is based on PICMG’s COM Express specification and is compatible with:

Standard form factor Type 2 COM Express modules

Express-BASE User’s ManualPage 8

2Special Features

2.1 Primary LPC based Super I/O

Express modules do not contain any Super I/O because this is considered legacy. Therefore

Super I/O is placed on the carrier board as an optional item. The Express-BASE uses a Winbond

W83627HG-AW that supports FDD, LPT, COM and PS/2 Keyboard and Mouse.

2.2 Secondary LPC based BIOS

Express-BASE contains a socket for secondary LPC BIOS on board in addition to the soldered

BIOS on the Express module. Selection of active BIOS can be done by jumper settings

2.3 Integrated Debug Port with Single Step Execution

In addition to a two digit POST code display the board also provides four digits display for ad-

dress. By jumper selection the board can be switched into single step BIOS execution mode.

Steps are executed using a manually operated on board mini switch.

2.4 Audio Codec

The onboard stereo audio power amplifier contains two identical amplifiers capable of delivering

6 W per channel of continuous average power into a 4-W load at 10% THD+N or 5 W per channel

at 1% THD+N. The gain of each channel is fixed at 20 dB. The amplifier features a mute/standby

function for power-sensitive applications.

2.5 Information LEDs

General information is obtained through signalling LEDs for HDD, Power and Watchdog status.

Additionally the Express-BASE give information about module types being plug into the board.

Page 9Express-BASE User’s Manual

3Component Location

SW3 SW1

JP6

CN37

JP5

CN33

CN29

CN28

CN25

CN43

CN27

CN26 CN24 CN19 CN18

CN8CN10CN14

U14

JP2

CN15

CN13

CN12

CN11

CN17

CN9

PCIE7

PCI2

PCIE1

PCIE2

PCIE4

PCIE5

PCIE3

PCIE6

CN40

CN42 LED15

LED16

LED17

LED18

LED19

SW2

JP1

LED9 LED10 LED11 LED12

LED14LED13

CN30

CN31

CN32

JP8

JP7

JP4

JP3

CNY8

CNY5

CNY9

CN41

CN35

CN21

CN20

CN4

CN3

CN6

CN5

CN7

CN1

CN16

CNZ1

LED20

LED2

LED21

PWR_OK

JPY11

JPY3

JPY2

JPY5

JPY4

CNY1

JPY9

JPY10

CNY4

JPY13

JPY12

JPY14

JPY1

JPY8

CNY7

JPY7 JPY6

CNY2

CNY3

CNY11

CNY10

Winbond

W83627HG-AW

ALC

883

CN2

51-46604-0B20

ETXexpress-BASE

LEDX8 – X1

Express-BASE User’s ManualPage 10

4Function Block Diagram

LPC

W83627HG

Primary

Super I/O

LPT1

COM1

COM2

FDD

POST Code

Display

PCI Express

6x USB on Rear I/O

1x USB on header

ALC883

Codec

Audio on

Rear I/O

KB/MS

USB

Debug Header

SATA

4 onboard

SATA headers

Secondary

BIOS

Express

Card

CRT VGA

Rear I/O

TV-out

header

LVDS

headers

Gigabit

Ethernet

Rear I/O

PCI Express

Graphics x16

PCI Express x16

onboard slot

PATA

Onboard IDE

Connector

32-bit PCI

PCI
