Advantech UNO-1140/F Manuale utente

UNO-1140/F

Advantech EVA x86 SoC Fanless

Box PC with 1 x LAN, 8 x Isolated

COM

User Manual

UNO-1140/F User Manual ii

The documentation and the software included with this product are copy-

righted 2009 by Advantech Co., Ltd. All rights are reserved. Advantech

Co., Ltd. reserves the right to make improvements in the products

described in this manual at any time without notice. No part of this man-

ual may be reproduced, copied, translated or transmitted in any form or

by any means without the prior written permission of Advantech Co., Ltd.

Information provided in this manual is intended to be accurate and reli-

able. However, Advantech Co., Ltd. assumes no responsibility for its use,

nor for any infringements of the rights of third parties, which may result

from its use.

Acknowledgements

IBM, PC/AT, PS/2 and VGA are trademarks of International Business

Machines Corporation.

Intel® and Pentium® are trademarks of Intel Corporation.

Microsoft Windows and MS-DOS are registered trademarks of

Microsoft Corp.

C&T is a trademark of Chips and Technologies, Inc.

All other product names or trademarks are properties of their respective

owners.

Part No. 2003114000 1st Edition

Printed in Taiwan November 2009

iii

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its prod-

ucts will be free from defects in materials and workmanship for two years

from the date of purchase.

This warranty does not apply to any products which have been repaired or

altered by persons other than repair personnel authorized by Advantech,

or which have been subject to misuse, abuse, accident or improper instal-

lation. Advantech assumes no liability under the terms of this warranty as

a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous test-

ing, most of our customers never need to use our repair service. If an

Advantech product is defective, it will be repaired or replaced at no

charge during the warranty period. For out-of-warranty repairs, you will

be billed according to the cost of replacement materials, service time and

freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For

example, CPU speed, Advantech products used, other hardware

and software used, etc.) Note anything abnormal and list any

onscreen messages you get when the problem occurs.

2. Call your dealer and describe the problem. Please have your man-

ual, product, and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return

merchandize authorization) number from your dealer. This allows

us to process your return more quickly.

4. Carefully pack the defective product, a fully-completed Repair and

Replacement Order Card and a photocopy proof of purchase date

(such as your sales receipt) in a shippable container. A product

returned without proof of the purchase date is not eligible for war-

ranty service.

5. Write the RMA number visibly on the outside of the package and

ship it prepaid to your dealer.

UNO-1140/F User Manual iv

This product has passed the CE test for environmental specifications

when shielded cables are used for external wiring.

FCC Class A

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interfer-

ence when the equipment is operated in a commercial environment. This

equipment generates, uses, and can radiate radio frequency energy and, if

not installed and used in accordance with the manual, may cause harmful

interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Technical Support and Assistance

Step 1. Visit the Advantech web site at www.advantech.com/support

where you can find the latest information about the product.

Step 2. Contact your distributor or Advantech's customer service center

if you need additional assistance. Have the following info ready:

- Product name and serial number

- Description of your software (OS, version, software, etc.)

- A complete description of the problem

- The exact wording of any error messages

Packing List

Before setting up the system, check that the items listed below are

included. If any item is not, please contact your dealer immediately.

• 3-pin connector for power wiring (Advantech P/N : 1652003206)

• 12-pin connector for COM5~8 RS-485

(UNO-1140F only, Advantech P/N : 1652012201)

• 10 PCS jumper (Advantech P/N : 1653302122)

• Keyboard/Mouse Y cable (Advantech P/N : 1700060202)

• DIN-rail & Wallmounting accessory

• Driver DVD

• Warranty card

Safety Instructions

1. Read these safety instructions carefully.

2. Keep this User's Manual for later reference.

3. Disconnect this equipment from any AC outlet before cleaning.

Use a damp cloth. Do not use liquid or spray detergents for clean-

ing.

4. For plug-in equipment, the power outlet socket must be located

near the equipment and must be easily accessible.

5. Keep this equipment away from humidity.

6. Put this equipment on a reliable surface during installation. Drop-

ping it or letting it fall may cause damage.

7. The openings on the enclosure are for air convection. Protect the

equipment from overheating. DO NOT COVER THE OPENINGS.

8. Make sure the voltage of the power source is correct before con-

necting the equipment to the power outlet.

9. Position the power cord so that people cannot step on it. Do not

place anything over the power cord.

10. All cautions and warnings on the equipment should be noted.

11. If the equipment is not used for a long time, disconnect it from the

power source to avoid damage by transient overvoltage.

12. Never pour any liquid into an opening. This may cause fire or elec-

trical shock.

13. Never open the equipment. For safety reasons, the equipment

should be opened only by qualified service personnel.

14. If one of the following situations arises, get the equipment checked

by service personnel:

a. The power cord or plug is damaged.

b. Liquid has penetrated into the equipment.

c. The equipment has been exposed to moisture.

d. The equipment does not work well, or you cannot get it to work

according to the user's manual.

e. The equipment has been dropped and damaged.

f. The equipment has obvious signs of breakage.

15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT

WHERE THE STORAGE TEMPERATURE MAY GO BELOW

UNO-1140/F User Manual vi

-20° C (-4° F) OR ABOVE 75° C (167° F). THIS COULD DAM-

AGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A

CONTROLLED ENVIRONMENT.

16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS

INCORRECTLY REPLACED. REPLACE ONLY WITH THE

SAME OR EQUIVALENT TYPE RECOMMENDED BY THE

MANUFACTURER, DISCARD USED BATTERIES ACCORD-

ING TO THE MANUFACTURER'S INSTRUCTIONS.

The sound pressure level at the operator's position according to IEC 704-

1:1982 is no more than 70 dB (A).

DISCLAIMER: This set of instructions is given according to IEC 704-1.

Advantech disclaims all responsibility for the accuracy of any statements

contained herein.

Safety Precaution - Static Electricity

Follow these simple precautions to protect yourself from harm and the

products from damage.

1. To avoid electrical shock, always disconnect the power from your

PC chassis before you work on it. Don't touch any components on

the CPU card or other cards while the PC is on.

2. Disconnect power before making any configuration changes. The

sudden rush of power as you connect a jumper or install a card may

damage sensitive electronic components.

vii Table of Contents

Contents

Chapter 1 UNO-1140/F Overview.................................... 2

1.1 Introduction ....................................................................... 2

1.2 Hardware Specifications ................................................... 2

1.3 Safety Precautions ............................................................. 4

1.4 UNO-1140/F Series........................................................... 4

1.5 Chassis Dimensions........................................................... 5

Chapter 2 Hardware Functionality ................................. 8

2.1 UNO-1140/F Peripherals................................................... 8

2.2 COM1~COM4: RS-232/485 Interfaces ............................ 9

2.2.1 Automatic Data Flow Control Function for RS-485 ..... 9

2.2.2 RS-232/485 Selection .................................................. 10

2.2.3 Terminal Resistor Setup for RS-485 ............................ 11

2.3 COM5~COM8: RS-485 Interfaces (UNO-1140F) ......... 11

2.4 LAN: Ethernet Connector ............................................... 12

2.5 Power Connector ............................................................. 12

2.6 LED Indicators ................................................................ 12

2.7 PS/2 Keyboard and Mouse Connector ............................ 12

2.8 Universal Serial Bus Connectors..................................... 12

2.9 VGA: VGA Display Connector ...................................... 13

2.10 RESET: Reset Button...................................................... 13

Chapter 3 Initial Setup.................................................... 16

3.1 CompactFlash Installation............................................... 16

3.2 Chassis Grounding .......................................................... 16

3.3 Power Connection ........................................................... 16

3.4 BIOS Setup and System Assignments ............................ 17

3.5 DIN-rail Mounting Setup ................................................ 17

3.6 Wallmounting Setup........................................................ 18

Appendix A Pin Assignments ............................................ 20

A.1 Board Connectors and Jumpers....................................... 20

A.2 RS-232/485 Serial Port (COM1~COM4) ....................... 21

A.3 RS-485 Serial Port (COM5~COM8, UNO-1140F) ....... 22

A.4 Ethernet RJ-45 Connector ............................................... 22

A.5 Power Screw Terminal (CN8)......................................... 22

A.6 PS/2 Keyboard and Mouse Connector (CN10) ............... 23

A.7 USB Connector ............................................................... 23

A.8 VGA Display Connector ................................................. 24

A.9 Clear CMOS (CMOS1)................................................... 24

UNO-1140/F User Manual viii

UNO-1140/F Overview

Sections include:

• Introduction

• Hardware Specifications

• Safety Precautions

• UNO-1140/F Series

• Chassis Dimensions

CHAPTER

UNO-1140/F User Manual 2

Chapter 1 UNO-1140/F Overview

1.1 Introduction

UNO-1140/F is a DIN-rail mounted Fanless Box PC, which provides several

serial communication ports. With a compact size, small foot print and front

accessible I/Os, UNO-1140/F is very convenient for wiring and DIN-rail

installation in the control cabinet. The wide operation temperature and indus-

trial serial port design makes UNO-1140/F a perfect communication gateway

even in critical environments. With OS and driver support on WinCE, Linux,

users can integrate applications with an application ready platform.

1.2 Hardware Specifications

General

• Certifications CE, FCC Class A, UL, CCC

• Dimensions (WxHxD) 71 x 155 x 140 mm

• Enclosure Aluminum + SECC

• Mounting DIN-rail, Wallmount

• Industrial Grounding Isolation between chassis and power ground

• Power Consumption 18 W (Typical)

• Power Requirement 9 ~ 36 VDC (e.g +24 V @ 1 A) (Min. 24 W), AT

• Weight 1 kg

• OS Support DOS (UNO-1140), Windows CE 5.0, Linux

• System Design Fanless design with no internal cabling

System Hardware

• CPU Advantech EVA-X4150 SoC,486SX, 150MHz

• Memory Onboard 64 MB Industrial grade SDRAM

• Indicators LEDs for Power, CF, LAN (Active, Status)

and Serial (Tx, Rx)

• Keyboard/Mouse 1 x PS/2

• Storage CF: 1 x internal type I/II CompactFlash slot

• Display DB15 VGA, supports 1024 x 768 @ 60 Hz

• Watchdog Timer Programmable 256 interval, from 1 to 255 sec
