Dear Customer

Thank you for choosing one of our highquality products.

With this appliance you will experience the perfect combination of functional

design and cutting edge technology.

Convince yourself that our appliances are engineered to deliver the best per

formance and control  indeed we are setting the highest standards of excel

lence.

In addition to this you find environmental and energy saving aspects as an inte

gral part of our products.

To ensure optimal and regular performance of your appliance please read this

instruction manual carefully. It will enable you to navigate all processes perfect

ly and most efficiently.

To refer to this manual any time you need to, we recommend you to keep it in a

safe place. And please pass it to any future owner of the appliance.

We wish you much joy with your new appliance.

ng sym

s are use

n t

s user

ormat

on:

Warning! This must be read! Important advice for the safety of persons and

information on avoiding damage to the appliance

3General information and advice

2Information on environmental protection

zDangerous voltage

3Contents

Contents

Operating Instructions 4

Safety instructions 4

Description of the Appliance 6

Cooking surface layout 6

Control panel layout 6

Touch Control sensor fields 7

Displays 7

Residual heat indicator 7

Operating the appliance 8

Switching the appliance on and off 8

Selecting the heat setting 8

Switching the STOP+GO function on and off 9

Locking/unlocking the control panel 9

Using the automatic warmup function 10

Using the child safety device 11

Using the timer 12

Automatic switch off 15

Tips on cooking and frying 16

Cookware 16

Energy saving 16

Examples of cooking applications 17

Cleaning and care 18

What to do if … 19

Disposal 21

Installation Instructions 22

Safety instructions 22

Assembly 24

Rating Plate 27

Guarantee/Customer Service 28

Service and Spare Parts 31

Operating Instructions4

Operating Instructions

1Safety instructions

Please comply with these instructions. If you do not, any damage resulting is not

covered by the warranty.

Correct use

•This appliance is not intended for use by children or other persons whose

physical, sensory or mental capabilities or lack of experience and knowledge

prevents them from using the appliance safely without supervision or instruc

tion by a responsible person to ensure that they can use the appliance safely.

•Do not leave the appliance unattended during operation.

•This appliance should be used only for normal domestic cooking and frying of

food.

•The appliance must not be used as a work surface or as a storage surface.

•Additions or modifications to the appliance are not permitted.

•Do not place or store flammable liquids, highly inflammable materials or fusi

ble objects (e.g. plastic film, plastic, aluminium) on or near the appliance.

Child safety

•Small children must be kept away from the appliance.

•Only let bigger children work on the appliance under supervision.

•To avoid small children and pets unintentionally switching the appliance on,

we recommend activation of the child safety device.

General safety

•The appliance may only be installed and connected by trained, registered serv

ice engineers, or competent persons.

•Builtin appliances may only be used after they have been built in to suitable

builtin units and work surfaces that meet standards.

•In the event of faults with the appliance or damage to the glass ceramic

(cracks, scratches or splits), the appliance must be switched off and discon

nected from the electrical supply to prevent the possibility of an electric

shock.

•Repairs to the appliance must only be carried out by trained registered service

engineers.

5Safety instructions

Safety during use

•Overheated fats and oils can ignite very quickly. Warning! Fire hazard!

•There is the risk of burns from the appliance if used carelessly.

•Remove stickers and film from the glass ceramic.

•Cables from electrical appliances must not touch the hot surface of the appli

ance or hot cookware.

•Switch the cooking zones off after each use.

Safety when cleaning

•For cleaning, the appliance must be switched off and cooled down.

•For safety reasons, the cleaning of the appliance with steam jet or highpres

sure cleaning equipment is not permitted.

How to avoid damage to the appliance

•The ceramic glass can be damaged by objects falling onto it.

•The edge of the ceramic glass can be damaged by being knocked by the cook

ware.

•Cookware made of cast iron, cast aluminium or with damaged bottoms can

scratch the ceramic glass if pushed across the surface.

•Objects that melt and things that boil over can burn onto the ceramic glass

and should be removed straightaway.

•To avoid damaging cookware and glass ceramics, do not allow saucepans or

frying pans to boil dry.

•Do not use the cooking zones with empty cookware or without cookware.

Description of the Appliance6

Description of the Appliance

Cooking surface layout

Control panel layout

Single cooking zone

1800W

Control panel

Single cooking zone

1200W

Cooking zone indicators

Timer function

On/Off

with power indicator

Timer

Timer display

Heat setting selection

Display

STOP+GO

Lock

7Description of the Appliance

Touch Control sensor fields

The appliance is operated using Touch Control sensor fields. Functions are con

trolled by touching sensor fields and confirmed by displays and acoustic signals.

Touch the sensor fields from above, without covering other sensor fields.

Displays

Residual heat indicator

1Warning! Risk of burns from residual heat. After being switched off, the cook

ing zones need some time to cool down. Look at the residual heat indicator .

3Residual heat can be used for melting and keeping food warm.

Sensor field Function

On / Off Switches appliance on and off

Increase settings To increase heat settings

Reduce settings To reduce heat settings

Timer Timer selection

Stop+Go To switch the Keep Warm setting on/

off

Lock Locking/unlocking the control panel

Display Description

Cooking zone is switched off

Keep warm setting Keep warm setting/STOP+GO function

is set

 Heat settings Heat setting is set

 Heating setting plus

decimal point

Intermediate heat setting is set

Automatic warm up func

tion

Automatic warmup function is acti

vated

Fault Malfunction has occurred

Residual heat Cooking zone is still hot

Child safety device Lock/child safety device is set.

Automatic switch off Switch off is active.

Operating the appliance8

Operating the appliance

Switching the appliance on and off

3After switching on, within approx. 10 seconds a heat setting or a function must

be set, otherwise the appliance automatically switches itself off.

Selecting the heat setting

3The keep warm setting lies between and . It is used to keep food warm.

Control panel Display Pilot light

Switch on Touch for 2 seconds / lights up

Switch off Touch for 1 second / none goes out

Control panel Indicator

To increase Touch to

To decrease Touch to

To switch off Touch and at the same time

9Operating the appliance

Switching the STOP+GO function on and off

The STOP+GO function simultaneously switches all cooking zones that are

switched on to the keep warm setting and then back to the heat setting that

was previously set.

3Timer functions are not stopped by .

3locks the whole control panel except the sensor field .

Locking/unlocking the control panel

The control panel, with the exception of the “On/Off” sensor field, can be locked

at any time in order to prevent the settings being changed e.g. by wiping over

the panel with a cloth.

3When you switch the appliance off, the locking function is automatically

switched off.

Control panel Display

To switch on Touch

To switch off Touch heat setting that was previously

set (not automatic warm up func

tion)

Control panel Display

Switch on Touch (for 5 seconds)

Switch off Touch previously set heat setting

Operating the appliance10

Using the automatic warmup function

All cooking zones are equpped with an automatic warm up function When set

ting a heat setting using , when starting from , the cooking zone switches

to full power for a certain amount of time and then automatically switches back

to the heat setting set.

3If during the automatic warm up a higher heat setting is selected, e.g. from

to , the automatic warm up is adjusted.

3If there is still residual heat on the cooking zone (display ), the automatic

warm up is not performed.

The length of time that the automatic warm up function operates depends on

the heat setting selected.

Control

panel

possible heat

settings

Display

Switch on

(only when starting at

)

Touch to (after 5 seconds)

Switch off Touch to / to

Not used Touch to to

Heat setting Length of the automatic warm up

[min:sec]

v0:30

11:00

21:40

34:50

46:30

510:10

62:00

73:30

84:30

9
