www.agneovo.com

A value 19” surveillance display

with rapid response time, quick

signal-switching and robust video

support for security and control

centre environments.

For a cost-eective surveillance display solution, look no further

than the AG Neovo SC-19. A bright, high resolution full colour

screen with quick signal-switching and 3ms response time ensures

sharp, smooth video playback. Looping BNC video inputs and

NTSC/PAL support maximise exibility for system integration.

And with built-in speakers, stylishly slim prole and VESA

mountability, the SC-19 will look just as attractive as its amazingly

aordable price.

> High 1280 × 1024 SXGA resolution

> Anti-Burn-inTM technology

> Video inputs (BNC in x 1, BNC out x 1)

> Looping video inputs for multiple connections

> Quick signal-switching time ( ≤ 0.8 sec. )

> NTSC/PAL auto-detection

> Selectable signal source

> PC compatible

> Built-in speakers

> Key lock function

> Auto-adjustment for optimal setting

> Security socket

> VESA standard wall mount

SC-19

All specications are subject to change without prior notice.

All other trademarks are the property of their respective owners.

P/C: SC19C0 Version 6.1, 20140324

SC-19

Stylish and slim design ideal for

professional security environments

Video versatility, including VGA, DVI, S-Video,

and BNC In/Out

Looping video inputs allow multiple display

connections

Built-in speakers enable more rigorous

security monitoring

Specications SC-19

Panel Panel Type

Panel Size

Max. Resolution

Pixel Pitch

Brightness

Contrast Ratio

Viewing Angle (H/V)

Display Colour

Response Time

LED-Backlit TFT LCD

19.0” (483 mm)

SXGA 1280 x 1024

0.294 mm

250 cd/m2 (Typical)

1000:1 (Typical)

170°/160° (Typical)

16.7 M

3 ms (GTG)

Horizontal

Resolution

TV Lines 550TVL (NTSC), 550TVL (PAL)

Frequency (H/V) H: 31 kHz - 80 kHz

V: 50 Hz - 75 Hz

Input Analogue

Digital

CVBS

S-Video

15-Pin D-Sub

24-Pin DVI-D

BNC x 1

4-Pin mini DIN

Out CVBS BNC x 1

Audio Audio In

Audio Out

Speaker

3.5 mm Audio Line-in

1W x 2

Power Power Supply

Power Requirements

Consumption

External

DC 12V

< 25W (On)

< 1.5W (Stand-by)

< 1W (Off)

Plug & Play VESA DCC 2B

Operating

Conditions

Temperature

Humidity

0 °C ~ 40 °C

10% ~ 85%

Storage

Conditions

Temperature

Humidity

-20 °C ~ 60 °C

10% ~ 95%

Mounting VESA FPMPMI Yes (100 x 100mm)

Tilt Tilt -5° ~ +15°

Dimensions Product

(W x H x D)

Packaging

(W x H x D)

420 x 408 x 164mm

(16.5” x 16.1” x 6.5”)

461 x 489 x 164mm

(18.1” x 19.3” x 6.5”)

Weight Product Weight

Packaged Weight

5.5 kg (12.1 lbs)

5.7 kg (12.5 lbs)

Regulation

Approval

Certications &

Compliance

UL/CUL, CB, FCC, CE, BSMI,

GOST-R, WEEE, RoHS

Accessories Supplied User manual, power cord,

power adaptor, 15-Pin D-Sub

cable, audio cable, warranty

card
